title

M07 - Jupiter

author

Walker Leite

patat

eval

purescript

command
purs-eval \| node --experimental-network-imports --input-type module \| prettier --parser html

Introduction

Getting Started

In this module we'll see Row Types and Records, monad lifting, async computations (Aff) and we'll build a wallet webapp using Halogen.

To run this presentation type (you will need nix):

../../slide README.md

Community Support

LovelaceAcademy Discord
StackExchange (:bulb: use the tag lovelace-academy)
Plutonomicon Discord

What you should know

Nix (module 1)
Nix flakes (module 3)
PureScript (modules 2-5)

Row Types and Records

Remembering Kinds

module Main where

import Prelude (($), Unit, show, discard)
import Effect (Effect)
import Effect.Console (log)

-- concrete type
type Name :: Type
type Name = String

-- concrete type
data Dog :: Type
data Dog = Dog Name

-- high kinded type
data Maybe :: Type -> Type
data Maybe a = Nothing | Just a

type MaybeDog :: Type
type MaybeDog = Maybe Dog

mayShowDog :: MaybeDog -> String
mayShowDog Nothing = show "No dog :("
mayShowDog (Just (Dog name)) = show name

main :: Effect Unit
main = do
    log $ mayShowDog Nothing
    log $ mayShowDog $ Just (Dog "Max")

Problem

What if we need to have way more dog attributes beyond name?

We could use Sum Types:

module Main where

import Prelude (($), (<>), Unit, show)
import Effect (Effect)
import Effect.Console (log)

type Name = String
type Owner = Name
type Age = Int
data Dog = Dog Name Age Owner

showDog :: Dog -> String
showDog (Dog name age owner) =
     show name
  <> ", "
  <> show age
  <> ", "
  <> show owner

main :: Effect Unit
main = log $ showDog $ Dog "Max" 2 "John"

It's a bit clunky but it works, what would be a better alternative?

Row Kind

data Row :: a -> Type
data Row a = ( label :: a )

type Dog :: Row Type
type Dog = ( name :: String, age :: Int, owner :: String )

-- ( label :: a ) is the type constructor for Row at language level ;)
-- name, age and owner are so called "indexed-labels"
-- !! because `Row Type` we can only have concrete types in labels) !!

💡 You can see a Row Type like instructions on how to create a dog definition.

Great! But having a type that can't be used to build definitions is not so useful. How can I build a type and a value of Dog Type?

Records

data Record :: Row Type -> Type

Record constructor: Given a defined Row Type, give me a corresponding concrete Type

type Dog :: Type
type Dog = Record ( name :: String, age :: Int, owner :: String )

-- like Row Type, Record has a syntax suggar constructor { }
type Dog :: Type
type Dog = { name :: String, age :: Int, owner :: String }

module Main where

import Prelude (($), (<>), Unit, show)
import Effect (Effect)
import Effect.Console (log)

type Dog = { name :: String, age :: Int, owner :: String }

showDog :: Dog -> String
showDog dog@{ name, owner: ownerName } =
     show name
  <> ", "
  <> show dog.age
  <> ", "
  <> show ownerName

main :: Effect Unit
main = log $ showDog
  { name: "Max"
  , age: 2
  , owner: "John"
  }

Optional field problem 1

What if owner is optional?

main :: Effect Unit
main = do
  log $ showDog
    { name: "Max"
    , age: 2
    , owner: "John"
    }
  log $ showDog
    { name: "Lily"
    , age: 3
    }

  Type of expression lacks required label owner.

while checking that expression { name: "Lily"
                               , age: 3
                               }
  has type { age :: Int
           , name :: String
           , owner :: String
           }
while applying a function showDog
  of type { age :: Int
          , name :: String
          , owner :: String
          }
          -> String
  to argument { name: "Lily"
              , age: 3
              }
in value declaration main

Optional field problem 2

What if showOwner needs handle only owner?

type Dog = { name :: String, age :: Int, owner :: String }
type Ownership = { owner :: String }

--...

showOwner ::  Ownership -> String
showOwner { owner } = show owner

main :: Effect Unit
main = let
  dog = { name: "Max"
        , age: 2
        , owner: "John"
        }
  in do
    log $ showDog dog
    log $ showOwner dog

  Type of expression contains additional label age.

while checking that type { age :: Int
                         , name :: String
                         , owner :: String
                         }
  is at least as general as type { owner :: String
                                 }
while checking that expression dog
  has type { owner :: String
           }
in value declaration main

Open / Closed Rows

Closed Row:

type Dog :: Row Type
type Dog = ( name :: String, age :: Int, owner :: String )

Open Row:

type Dog :: Row Type -> Row Type
type Dog a = ( name :: String, age :: Int | a )

💡 Dog is a high kinded type, it needs a, which must have kind Row Type, to define its concrete Row Type.

type Ownership :: Row Type
type Ownership = ( owner :: String )

type Dog :: Row Type -> Row Type
type Dog a = ( name :: String, age :: Int | a )

type DogWithOwner :: Row Type
type DogWithOwner = Dog Ownership

💡 Remember that a Row Type is the instruction on how to build a Type using Record :: Row Type -> Type.

Open / Closed Records

Closed Record:

type Dog :: Type
type Dog = { name :: String, age :: Int, owner :: String }

Open Record:

type Dog :: Row Type -> Type
type Dog a = { name :: String, age :: Int | a }

💡 Dog is a high kinded type, it needs a, which must have kind Row Type, to define its concrete Type

type Ownership :: Row Type
type Ownership = ( owner :: String )

type Dog :: Row Type -> Type
type Dog a = { name :: String, age :: Int | a }

type DogWithOwner :: Type
type DogWithOwner = Dog Ownership

DogWithOwner is the concrete Type of a dog, result of applying Ownership to the Dog HKT, which apply the received Ownership to Record :: Row Type -> Type as first argument.

In other words, we use the Ownership Row Type to tell Dog how to build a Type using Record type constructor.

Solution

module Main where

import Prelude (($), (<>), Unit, show, discard)
import Effect (Effect)
import Effect.Console (log)

type Ownership :: Row Type
type Ownership = ( owner :: String )

type Dog :: Row Type -> Type
type Dog a = { name :: String, age :: Int | a }

type DogWithOwner :: Type
type DogWithOwner = Dog Ownership

showDog :: forall a. Dog a -> String
showDog { name, age } = show name <> ", " <> show age

showOwner :: forall a. { owner :: String | a } -> String
showOwner { owner } = show owner

main :: Effect Unit
main = let
  dog1 = { name: "Max"
         , age: 2
         , owner: "John"
         }
  dog2 = { name: "Lily"
         , age: 3
         }
  in do
    log $ showDog dog1
    log $ showDog dog2
    log $ showOwner dog1
    -- uncomment to throw "lacks required label owner"
    -- log $ showOwner dog2

Lifting and async

Problem

Remember the Contract monad from module 5?

buildTx :: Inputs -> Outputs -> Redeemer -> Validator -> Contract Boolean

data Contract a = Contract a

What if we need to produce a side-effect in buildTx?

data Contract a = Contract (Effect a)

runContract :: forall a. Contract a -> Effect a
runContract (Contract eff) = log ">running effects" *> eff

So we could runContract buildTx, right? Well, we can't:

buildTx :: Contract Boolean
buildTx = do
  log ">building tx"
  pure true

Could not match type

    Effect

  with type

    Contract

It happens because log returns Effect, not Contract.

Solution

Solution - MonadEffect

module Main where

import Prelude
import Effect (Effect)
import Effect.Class (class MonadEffect, liftEffect)
import Effect.Console (log)

data Contract a = Contract (Effect a)

derive instance Functor Contract
instance Apply Contract where
  apply = ap
instance Bind Contract where
  --bind :: forall a b. m a -> (a -> m b) -> m b
  bind (Contract eff) f = Contract $ eff >>= \v -> case f v of
    Contract eff' -> eff'
instance Applicative Contract where
  pure value = Contract (pure value)
instance Monad Contract

instance MonadEffect (Contract) where
  --liftEffect :: forall m a. MonadEffect m => Effect a -> m a
  liftEffect = Contract

c1 :: Contract Boolean
c1 = do
  liftEffect $ log ">running contract c1"
  pure true

c2 :: Contract Boolean
c2 = do
  liftEffect $ log ">running contract c2"
  pure false

runContract :: forall a. Contract a -> Effect a
runContract (Contract eff) = log ">running effects" *> eff

main :: Effect Unit
main = do
  result1 <- runContract c1
  log $ ">result1: " <> show result1
  result2 <- runContract c2
  log $ ">result2: " <> show result2

Aff

Aff is used to represent asynchronous effects (similar to Promises, but with more features)

-- The computation may either error with an exception, or produce a result of type a.
data Aff a

To launch it we use launchAff_ :: forall a. Aff a -> Effect Unit

module Main where

import Prelude

import Data.Time.Duration (Milliseconds (Milliseconds))
import Effect (Effect)
import Effect.Aff (launchAff_, delay)
import Effect.Console (log, logShow)
import Effect.Class (liftEffect)
import Fetch (fetch)

main :: Effect Unit
main = do
  log "This is an Effect computation (Effect monadic context)"

  launchAff_ do
    { text } <- fetch "https://httpbin.org/uuid" {}
    uuid <- text
    liftEffect $ logShow uuid

  launchAff_ do
    liftEffect $ log "[other aff] start"
    delay $ Milliseconds 1000.0
    liftEffect $ log "[other aff] done"

  log "Program finished before async stuff ;)"

Aff instances

-- Relevant instances, beyond Functor, Apply, Applicative, Bind and Monad

MonadThrow Error Aff
-- so it can throwError
MonadError Error Aff
-- so we can catchError
MonadEffect Aff
-- so we can liftEffect

-- MonadAff, like MonadEffect, allows one yo lift from Aff to m
class (MonadEffect m) <= MonadAff m
  liftAff :: Aff ~> m

Halogen

Why

We need to build simple user interfaces using the knowledge acquired so far.

Halogen is a type-safe library for building user interfaces in PureScript, it rely on both a well known architecture (Elm) and PureScript features like Row Types and Monad Transformers.

Some alternatives:

react-basic core types and tools for React;
deku FRP UI framework for games and web apps;
jelly framework for building web applications based on Signal;

HTML

Hello World

In the module 3 we've created types and functions to help us render HTML, Halogen does the same, in the Halogen.HTML:

module Main where

import Prelude
import Data.Newtype (unwrap)
import Effect.Console (log)
import Halogen.HTML as HH
import Halogen.VDom.DOM.StringRenderer as HVDS

html = HH.h1 [ ] [ HH.text "Hello, world" ]

logRender = log <<< HVDS.render (const mempty) <<< unwrap
main = logRender html

Form Name

module Main where

import Prelude ((<<<), const, mempty)
import Data.Newtype (unwrap)
import Effect.Console (log)
import Halogen.HTML as HH
import Halogen.HTML.Properties as HP
import Halogen.VDom.DOM.StringRenderer (render)

html :: forall w i. HH.HTML w i
html = HH.div
    [ HP.id "root" ]
    [ HH.input
        [ HP.placeholder "Name" ]
    , HH.button
        [ HP.classes [ HH.ClassName "btn-primary" ]
        , HP.type_ HP.ButtonSubmit
        ]
        [ HH.text "Submit" ]
    ]

logRender = log <<< render (const mempty) <<< unwrap
main = logRender html

Components

Halogen HTML is one basic building block of Halogen applications. But pure functions that produce HTML lack many essential features that a real world application needs: state that represents values over time, effects for things like network requests, and the ability to respond to DOM events (for example, when a user clicks a button).

module Main where

import Prelude

import Halogen as H
import Halogen.Aff as HA
import Halogen.HTML as HH
import Halogen.HTML.Events as HE
import Halogen.VDom.Driver as HD

data Action = Increment | Decrement

component =
  H.mkComponent
    { initialState
    , render
    , eval: H.mkEval H.defaultEval { handleAction = handleAction }
    }
  where
  initialState _ = 0

  render state =
    HH.div_
      [ HH.button [ HE.onClick \_ -> Decrement ] [ HH.text "-" ]
      , HH.text (show state)
      , HH.button [ HE.onClick \_ -> Increment ] [ HH.text "+" ]
      ]

  handleAction = case _ of
    Decrement ->
      H.modify_ \state -> state - 1

    Increment ->
      H.modify_ \state -> state + 1

main = HA.runHalogenAff do
  body <- HA.awaitBody
  HD.runUI component unit body

Components - Zooming in

Main

HA.runHalogenAff :: forall x. Aff x -> Effect Unit
HA.awaitBody :: Aff HTMLElement

-- q: query, i: input, o: output

HD.runUI :: forall q i o. Component q i o Aff -> i -> HTMLElement -> Aff (HalogenIO q o Aff)

type HalogenIO q o m =
  { dispose :: m Unit
  , messages :: Emitter o
  , query :: forall a. q a -> m (Maybe a)
  }

main :: Effect Unit
main = HA.runHalogenAff do
  body <- HA.awaitBody
  HD.runUI component unit body

mkComponent

-- s: state, q: query, a: action, sl: slot, i: input, o: output, m: monad

mkComponent :: forall s q a sl i o m. ComponentSpec s q a sl i o m -> Component q i o m

type ComponentSpec s q a sl i o m =
  { eval :: (HalogenQ q a i) ~> (HalogenM s a sl o m)
  , initialState :: i -> s
  , render :: s -> HTML (ComponentSlot sl m a) a
  }

mkEval and defaultEval

-- s: state, q: query, a: action, sl: slot, i: input, o: output, m: monad


-- ~> is a Natural Transformation, don't worry about it
--    you can safely read it as a normal arrow (->).
mkEval :: forall s q a sl i o m. EvalSpec s q a sl i o m -> (HalogenQ q a i) ~> (HalogenM s a sl o m)

type EvalSpec s q a s i o m =
  { finalize :: Maybe a
  , handleAction :: a -> HalogenM s a sl o m Unit
  , handleQuery :: forall a. q a -> HalogenM s a sl o m (Maybe a)
  , initialize :: Maybe a
  , receive :: i -> Maybe a
  }

defaultEval :: forall s q a sl i o m. EvalSpec s q a sl i o m

H.mkComponent
  { initialState
  , render
  , eval: H.mkEval (H.defaultEval { handleAction = ?handleAction })
  }

💡 Looking in mkEval source code might help you understand what is happening behind the scene, but you don't need to understand it to use Halogen

HalogenM

-- s: state, q: query, a: action, sl: slot, i: input, o: output, m: monad

newtype HalogenM s a sl o m a = HalogenM (Free (HalogenF s a sl o m) a)

-- In links section there is a long video about Halogen and the Free type
-- not required to use Halogen, but still very interesting

-- Relevant instances, beyond Functor, Apply, Applicative, Bind and Monad

(Monoid a) => Monoid (HalogenM s a sl o m a)
-- so we can append many handleActions/handleQueries

(MonadEffect m) => MonadEffect (HalogenM s a sl o m)
-- so we can liftEffect to perform computations and side-effects

(MonadAff m) => MonadAff (HalogenM s a sl o m)
-- so we can liftAff to perform async computations and side-effects

MonadState s (HalogenM s a sl o m)
-- so we can get/put/modify s

Aff Example

handleAction :: forall o m. MonadAff m => Action -> H.HalogenM State Action () o m Unit
handleAction = case _ of
  SetUsername username -> do
    H.modify_ _ { username = username, result = Nothing }

  MakeRequest event -> do
    username <- H.gets _.username
    H.modify_ _ { loading = true }
    response <- H.liftAff $ AX.get AXRF.string ("https://api.github.com/users/" <> username)
    H.modify_ _ { loading = false, result = map _.body (hush response) }

render :: forall m. State -> H.ComponentHTML Action () m
render st =
  HH.form
    [ HE.onSubmit \ev -> MakeRequest ev ]
    [ HH.h1_ [ HH.text "Look up GitHub user" ]
    , HH.label_
        [ HH.div_ [ HH.text "Enter username:" ]
        , HH.input
            [ HP.value st.username
            , HE.onValueInput \str -> SetUsername str
            ]
        ]
    , HH.button
        [ HP.disabled st.loading
        , HP.type_ HP.ButtonSubmit
        ]
        [ HH.text "Fetch info" ]
    , HH.p_
        [ HH.text $ if st.loading then "Working..." else "" ]
    , HH.div_
        case st.result of
          Nothing -> []
          Just res ->
            [ HH.h2_
                [ HH.text "Response:" ]
            , HH.pre_
                [ HH.code_ [ HH.text res ] ]
            ]
    ]

References and Links

Breakthrough

Exercise

User Story: As a cardano user I want to see all my available funds in my browser wallet

Bootstrap

nix flake init -t github:LovelaceAcademy/nix-templates#pix

Uh oh!

FilesExpand file tree

M07-jupiter

Directory actions

More options

Directory actions

More options

Latest commit

History

M07-jupiter

Folders and files

parent directory

README.md

Introduction

Getting Started

Community Support

What you should know

Row Types and Records

Remembering Kinds

Problem

Row Kind

Records

Optional field problem 1

Optional field problem 2

Open / Closed Rows

Open / Closed Records

Solution

Links

Lifting and async

Problem

Solution

Solution - MonadEffect

Aff

Aff instances

Links

Halogen

Why

HTML

Hello World

Form Name

Components

Components - Zooming in

Main

mkComponent

mkEval and defaultEval

HalogenM

Aff Example

References and Links

Breakthrough

Exercise

Bootstrap

References and Links
