Clipzz Backend - Video Processing Pipeline

Python-based video processing backend running on Modal serverless GPU infrastructure.

Overview

The backend is responsible for the entire video processing pipeline:

  1. Video transcription with WhisperX
  2. AI-powered moment identification with Google Gemini
  3. Active speaker detection with LR-ASD
  4. Vertical video creation with smart cropping
  5. Karaoke-style subtitle generation and burn-in

Technology Stack

  • Runtime: Python 3.12
  • Framework: FastAPI
  • Infrastructure: Modal (Serverless GPU - L40S)
  • AI Models:
    • WhisperX large-v2 (speech-to-text)
    • Google Gemini 2.5 Pro (content analysis)
    • LR-ASD (active speaker detection)
  • Video Processing:
    • FFmpeg / ffmpegcv (encoding/decoding)
    • OpenCV (image manipulation)
    • PyTorch 2.4.1 + CUDA 12.4
  • Storage: AWS S3 (boto3)

Quick Start

Prerequisites

  • Python 3.12+
  • Modal account (sign up)
  • Google Gemini API key
  • AWS S3 bucket and credentials

Installation

# Clone and navigate to backend
cd backend

# Create virtual environment
python -m venv venv
source venv/bin/activate  # Windows: venv\Scripts\activate

# Install dependencies
pip install -r requirements.txt

# Install Modal CLI
pip install modal

# Authenticate with Modal
modal token new

Initialize LR-ASD Submodule

# From root directory
git submodule update --init --recursive

Configuration

  1. Copy .env.example to .env:
cp .env.example .env

  1. Configure environment variables (see .env.example)

  2. Create Modal secrets:

modal secret create clipzz-secrets \
  AWS_ACCESS_KEY_ID="your-key" \
  AWS_SECRET_ACCESS_KEY="your-secret" \
  GEMINI_API_KEY="your-gemini-key" \
  AUTH_TOKEN="your-auth-token"

Running Locally

# Serve function locally (for development)
modal serve main.py

This will output a local endpoint URL you can test with:

curl -X POST "https://your-app--dev.modal.run/process_video" \
  -H "Authorization: Bearer your-auth-token" \
  -H "Content-Type: application/json" \
  -d '{"s3_key": "user-id/video-id/video.mp4", "num_clips": 3}'

Deploying to Production

modal deploy main.py

Copy the production endpoint URL to your frontend's .env:

PROCESS_VIDEO_ENDPOINT="https://your-app--clipzz-video-processor-process-video.modal.run"

Architecture

Modal App Structure

app = modal.App("clipzz-video-processor")

# Persistent volume for model caching
volume = modal.Volume.from_name("clipzz-models", create_if_missing=True)

# Custom CUDA image with all dependencies
image = (
    modal.Image.debian_slim(python_version="3.12")
    .apt_install(["ffmpeg", "git", "libsndfile1", ...])
    .pip_install(["torch==2.4.1+cu124", "whisperx", ...])
    .run_commands([...])
)

@app.function(
    gpu="L40S",           # NVIDIA L40S GPU
    timeout=900,          # 15 minutes
    image=image,
    volumes={"/root/.cache": volume}  # Cache models between runs
)
def process_video(request: ProcessVideoRequest, token: str):
    # Main processing logic
    ...

Processing Pipeline

┌──────────────────────────────────────────────────────────┐
│ 1. Download Video from S3                               │
└───────────────────┬──────────────────────────────────────┘
                    │
┌───────────────────▼──────────────────────────────────────┐
│ 2. Transcribe with WhisperX                             │
│    - Detect language (auto)                             │
│    - Transcribe audio → text                            │
│    - Align word-level timestamps                        │
│    - Transliterate Hindi (if detected)                  │
└───────────────────┬──────────────────────────────────────┘
                    │
┌───────────────────▼──────────────────────────────────────┐
│ 3. Identify Moments with Gemini                         │
│    - Analyze full transcript                            │
│    - Extract engaging Q&A segments                      │
│    - Return 30-60s clip boundaries                      │
└───────────────────┬──────────────────────────────────────┘
                    │
                    ▼
        ┌──────────────────────┐
        │   For Each Clip      │
        └──────────┬───────────┘
                   │
    ┌──────────────▼──────────────────┐
    │ 4. Extract Video Segment        │
    │    - Cut video based on timing  │
    │    - Extract audio track        │
    └──────────────┬──────────────────┘
                   │
    ┌──────────────▼──────────────────┐
    │ 5. Active Speaker Detection     │
    │    - Run LR-ASD model           │
    │    - Track faces across frames  │
    │    - Score speaking activity    │
    └──────────────┬──────────────────┘
                   │
    ┌──────────────▼──────────────────┐
    │ 6. Create Vertical Video        │
    │    - Target: 1080x1920          │
    │    - Crop to active speaker     │
    │    - Or blur background         │
    └──────────────┬──────────────────┘
                   │
    ┌──────────────▼──────────────────┐
    │ 7. Generate Subtitles           │
    │    - Group words (5 per line)   │
    │    - Calculate karaoke timing   │
    │    - Create ASS subtitle file   │
    └──────────────┬──────────────────┘
                   │
    ┌──────────────▼──────────────────┐
    │ 8. Burn Subtitles               │
    │    - Merge subtitle + video     │
    │    - Final encode               │
    └──────────────┬──────────────────┘
                   │
    ┌──────────────▼──────────────────┐
    │ 9. Upload to S3                 │
    │    - Save as clip_N.mp4         │
    └─────────────────────────────────┘

Core Functions

transcribe_video(base_dir, video_path)

Transcribes video audio using WhisperX.

Features:

  • Automatic language detection
  • Word-level timestamp alignment
  • Hindi transliteration (Devanagari → Roman)
  • Handles missing timestamps with interpolation

Returns:

{
    "segments": [
        {
            "start": 10.5,
            "end": 15.2,
            "text": "This is an example",
            "words": [
                {"word": "This", "start": 10.5, "end": 10.8},
                {"word": "is", "start": 10.9, "end": 11.0}
            ]
        }
    ]
}

identify_moments(transcript)

Uses Google Gemini 2.5 Pro to identify engaging moments.

Input: Full transcript as text Output: List of clip boundaries

[
    {
        "clip_number": 1,
        "start_seconds": 125.0,
        "end_seconds": 178.0,
        "description": "Discussion about AI in education"
    }
]

Prompt Strategy:

  • Focus on Q&A format conversations
  • 30-60 second optimal length
  • No overlapping clips
  • Exclude greetings and intros

process_clip(...)

Processes a single clip from start to finish.

Steps:

  1. Extract video segment with ffmpeg
  2. Extract audio track
  3. Run LR-ASD active speaker detection
  4. Create vertical video with smart cropping
  5. Generate ASS subtitles with karaoke effect
  6. Burn subtitles into video
  7. Upload to S3

Parameters:

  • base_dir: Working directory for temp files
  • original_video_path: Path to source video
  • s3_key: S3 key of original video
  • start_time: Clip start timestamp (seconds)
  • end_time: Clip end timestamp (seconds)
  • clip_index: Clip number (1, 2, 3, ...)
  • transcript_segments: Word-level transcript data

create_vertical_video(...)

Converts horizontal video to vertical format with active speaker tracking.

Target Resolution: 1080x1920 (9:16 aspect ratio)

Algorithm:

  1. Load face tracks and speaking scores from LR-ASD
  2. For each frame:
    • Calculate average score over 60-frame window
    • Identify highest-scoring face (active speaker)
    • Crop Mode: If speaker detected, crop 1080px around face
    • Resize Mode: Otherwise, blur background and letterbox
  3. GPU-accelerated encoding with ffmpegcv

Window Size: 60 frames (~2.4 seconds at 25fps) for stable tracking

create_subtitles_with_ffmpeg(...)

Generates karaoke-style subtitles with word-level highlighting.

Format: ASS (Advanced SubStation Alpha)

Features:

  • Groups words into 5-word sentences
  • Yellow highlight on current word (&H00FFFF&)
  • White text with shadow and outline
  • Bottom-center positioning
  • Anton font, 140pt

Karaoke Timing:

{\k50}Word1 {\k30}Word2 {\k40}Word3

Numbers are centiseconds (50 = 0.5 seconds).

Burn-In: Uses ffmpeg subtitles filter (hardware-accelerated if available)

API Reference

POST /process_video

Processes a video and generates clips.

Authentication: Bearer token (required)

Authorization: Bearer your-auth-token

Request Body:

{
  "s3_key": "user-id/upload-id/original.mp4",
  "num_clips": 3
}

Response (Success):

{
  "status": "success",
  "clips_processed": 3
}

Response (Error):

{
  "status": "error",
  "message": "Error description"
}

Status Codes:

  • 200 OK: Processing successful
  • 401 Unauthorized: Invalid or missing auth token
  • 500 Internal Server Error: Processing failed

File Structure

backend/
├── main.py                # Main Modal app with processing logic
├── requirements.txt       # Python dependencies
├── .env.example          # Environment variable template
├── .env                  # Your local config (gitignored)
├── README.md             # This file
└── LR-ASD/               # Active speaker detection (git submodule)
    ├── Columbia_test.py  # ASD inference script
    ├── model/            # Model weights
    └── ...

Dependencies

Core Libraries

  • fastapi[standard] - Web framework
  • modal - Serverless platform
  • boto3 - AWS S3 client

AI/ML

  • torch==2.4.1+cu124 - PyTorch with CUDA 12.4
  • torchvision==0.19.1+cu124 - Vision models
  • transformers - Hugging Face models
  • accelerate - Model optimization
  • whisperx - Speech recognition
  • google-generativeai - Gemini API

Video Processing

  • ffmpegcv - GPU-accelerated video I/O
  • opencv-python - Image processing
  • scenedetect[opencv] - Scene detection
  • pysubs2 - Subtitle manipulation

Audio Processing

  • python_speech_features - Audio features
  • scipy - Scientific computing

Utilities

  • pandas - Data manipulation
  • tqdm - Progress bars
  • gdown - Google Drive downloads
  • indic-transliteration - Hindi transliteration

Configuration

Environment Variables

See .env.example for detailed setup.

Required:

  • AWS_ACCESS_KEY_ID - S3 access key
  • AWS_SECRET_ACCESS_KEY - S3 secret key
  • AWS_REGION - S3 bucket region
  • S3_BUCKET_NAME - S3 bucket name
  • GEMINI_API_KEY - Google Gemini API key
  • AUTH_TOKEN - API authentication token

Modal Configuration

Adjust resources in main.py:

@app.function(
    gpu="L40S",           # GPU type (L4, A10G, A100, L40S, H100)
    timeout=900,          # Max execution time (seconds)
    memory=16384,         # RAM in MB
    cpu=4,                # CPU cores
)

GPU Options:

  • L4 - Cheapest, slower ($0.50/hr)
  • A10G - Good balance ($1.10/hr)
  • L40S - Fast, good value ($2.50/hr) ← Current
  • A100 - Very fast ($4.00/hr)
  • H100 - Fastest ($8.00/hr)

Troubleshooting

"Model download failed"

Cause: First run downloads models (WhisperX, LR-ASD weights) Solution: Wait for download to complete. Models are cached in persistent volume.

"CUDA out of memory"

Cause: GPU memory exhausted Solution:

  • Reduce batch size in WhisperX: batch_size=8
  • Use smaller GPU (A10G) or larger (A100)
  • Process shorter videos

"ffmpeg not found"

Cause: ffmpeg not in container image Solution: Ensure .apt_install(["ffmpeg"]) in image definition

"S3 upload failed"

Cause: Invalid credentials or permissions Solution:

  • Verify AWS credentials in Modal secrets
  • Check S3 bucket permissions
  • Ensure bucket exists in specified region

"Timeout error"

Cause: Processing exceeds 900s limit Solution:

  • Increase timeout: timeout=1800 (30 minutes)
  • Process fewer clips per request
  • Use faster GPU (L40S → A100)

"LR-ASD submodule missing"

Cause: Submodule not initialized Solution:

git submodule update --init --recursive

Performance

Processing Times (Approximate)

On L40S GPU for 1-hour podcast:

  • Transcription: ~3-5 minutes
  • Moment identification: ~10 seconds
  • Per clip (60s):
    • ASD: ~2 minutes
    • Vertical video: ~1 minute
    • Subtitles: ~30 seconds
  • Total for 3 clips: ~12-15 minutes

Cost Estimation

L40S GPU @ $2.50/hour:

  • 15-minute job = $0.625
  • 100 jobs/month = $62.50

Optimization Tips:

  • Use persistent volumes to cache models
  • Batch multiple clips in single request
  • Consider L4 GPU for non-urgent processing

Security

  • API Authentication: Bearer token required for all requests
  • S3 Access: Use IAM user with minimal permissions (S3 only)
  • Secrets: Store in Modal Secrets, never hardcode
  • Temporary Files: Cleaned up after processing
  • No Data Retention: Videos not stored on Modal infrastructure

Development

Local Testing

# Serve locally
modal serve main.py

# Test with curl
curl -X POST "http://localhost:8000/process_video" \
  -H "Authorization: Bearer test-token" \
  -H "Content-Type: application/json" \
  -d '{"s3_key": "test/video.mp4", "num_clips": 1}'

Debugging

Add print statements (they appear in Modal logs):

print(f"Processing clip {clip_index}...")

View logs:

modal logs clipzz-video-processor

Testing Changes

# Test locally first
modal serve main.py

# Deploy to production
modal deploy main.py

Future Improvements

  • Support more video formats (AVI, MOV, MKV)
  • Add configurable subtitle styles
  • Implement progress callbacks (webhooks)
  • Add video quality options (720p, 1080p, 4K)
  • Support multiple languages in subtitles
  • Optimize batch processing (multiple videos at once)
  • Add face recognition for consistent speaker labeling
  • Implement chapter detection for long videos

For more information:
