Creating Custom Payloads

This guide describes how to create custom DuckyScript keystroke injection payloads for the Digispark ATTiny85. Whether you're automating tasks, testing security, or learning about USB HID devices, this guide covers everything from basic to advanced payload development.

Understanding the Basics

What is a Payload?

A payload is the code that runs on your Digispark when it's plugged into a target computer. It simulates keyboard inputs to:

  • Execute commands
  • Open applications
  • Type text
  • Navigate menus
  • Automate tasks

rev3_board

DuckyScript for ATTiny85 Ducky

This directory contains DuckyScript payloads that are automatically compiled into C++ code for the Digispark ATTiny85 Rev.3.

How It Works

  1. Create your payload in payload.ducky (required filename)
  2. Optionally add ATTACKMODE command to spoof USB device identity
  3. Run PlatformIO build - the payload is automatically compiled to src/main.cpp
  4. Upload to your ATTiny85
  5. Payload executes on device startup

Quick Start: USB Spoofing

You can now configure USB device identity directly in your DuckyScript payload:

REM Configure USB identity
ATTACKMODE HID VID_16c0 PID_27db MAN_DigiKey PROD_ATTiny85_Ducky SERIAL_1337

REM Your payload here
DELAY 3000
GUI r
STRINGLN notepad

See docs/ATTACKMODE.md for complete documentation.

Supported DuckyScript Commands

The ATTiny85 Ducky compiler supports a subset of the full DuckyScript 3.0 specification. Only commands compatible with the DigiKeyboard library and ATTiny85 hardware constraints are supported.

✅ Supported Commands

Comments

REM This is a comment
REM Comments are ignored by the compiler

Language Configuration

DUCKY_LANG US
DUCKY_LANG DE
DUCKY_LANG FR

Supported languages: US, BE, BR, CA_FR, CH_DE, CH_FR, CZ, DE, DK, ES, FI, FR, GB, HR, IT, NO, PT, RU, SI, SK, SV, TR

USB Device Configuration (ATTACKMODE)

REM Spoof USB device identity
ATTACKMODE HID VID_046d PID_c31e MAN_Logitech PROD_K120_Keyboard SERIAL_13370001

REM Parameters (all optional):
REM   VID_xxxx     - Vendor ID (hex)
REM   PID_xxxx     - Product ID (hex)
REM   MAN_xxx      - Manufacturer name
REM   PROD_xxx     - Product name
REM   SERIAL_xxx   - Serial number (hex)

Note: ATTACKMODE is parsed at build time and generates USB configuration. The ATTiny85 cannot change USB MicronNcleus Bootloader identity at initial runtime. See docs/ATTACKMODE.md for details.

Constants (DEFINE)

DEFINE #SERVER example.com
DEFINE #WAIT 1000

STRING https://#SERVER
DELAY #WAIT

Delays

DELAY 1000          REM Wait 1000 milliseconds (1 second)
DELAY 500           REM Wait 500ms

Note: Minimum delay value is implementation-dependent. Use DELAY 100 or higher for reliability.

String Injection

STRING Hello World                    REM Type text (no newline)
STRINGLN Hello World                  REM Type text with ENTER at end

STRING https://github.com/3mrgnc3/attiny85_ducky
STRINGLN The quick brown fox jumps over the lazy dog

All strings are stored in PROGMEM to save precious RAM on the ATTiny85 (512 bytes total).

Special Keys

ENTER               REM Press Enter/Return key
ESCAPE              REM Press Escape key
TAB                 REM Press Tab key
SPACE               REM Press Space bar

UPARROW             REM Press Up arrow
DOWNARROW           REM Press Down arrow
LEFTARROW           REM Press Left arrow
RIGHTARROW          REM Press Right arrow

Modifier Key Combinations

GUI r               REM Windows Key + R (Run dialog)
GUI d               REM Windows Key + D (Show desktop)

CTRL c              REM Control + C (Copy)
CTRL v              REM Control + V (Paste)
CTRL ALT t          REM Control + Alt + T (Terminal on Linux)
CTRL ALT DELETE     REM Control + Alt + Delete

ALT F4              REM Alt + F4 (Close window)
ALT TAB             REM Alt + Tab (Switch windows)

SHIFT TAB           REM Shift + Tab

Available Modifiers: GUI, CTRL, ALT, SHIFT

Extra Commands Features

The ATTiny85 Ducky compiler includes custom extensions beyond standard DuckyScript for enhanced payload capabilities.

Random String Generation

Generate random strings at compile-time for creating unique identifiers, session tokens, or randomized payloads.

RAND_HEX [length]

Generates random hexadecimal string (characters: 0-9a-f).

STRINGLN RAND_HEX          REM Generates 2 hex chars (e.g., "a3", "7f")
STRINGLN RAND_HEX 8        REM Generates 8 hex chars (e.g., "2f4a9c1b")
STRINGLN RAND_HEX 16       REM Generates 16 hex chars (e.g., "7eb423994619364f")

Default length: 2 characters

RAND_NUM [length]

Generates random numeric string (digits: 0-9).

STRINGLN RAND_NUM          REM Generates 1 digit (e.g., "7")
STRINGLN RAND_NUM 4        REM Generates 4 digits (e.g., "1829")
STRINGLN RAND_NUM 10       REM Generates 10 digits (e.g., "0712998453")

Default length: 1 character

RAND_ALPHA [length]

Generates random lowercase alphabetic string (letters: a-z).

STRINGLN RAND_ALPHA        REM Generates 1 lowercase letter (e.g., "k")
STRINGLN RAND_ALPHA 6      REM Generates 6 lowercase letters (e.g., "mowkph")
STRINGLN RAND_ALPHA 12     REM Generates 12 lowercase letters (e.g., "vrtxaoovrglm")

Default length: 1 character

RAND_ALPHA_UPPER [length]

Generates random uppercase alphabetic string (letters: A-Z).

STRINGLN RAND_ALPHA_UPPER     REM Generates 1 uppercase letter (e.g., "K")
STRINGLN RAND_ALPHA_UPPER 4   REM Generates 4 uppercase letters (e.g., "CXZG")
STRINGLN RAND_ALPHA_UPPER 8   REM Generates 8 uppercase letters (e.g., "MZPQWKRT")

Default length: 1 character

RAND_ALPHANUM [length]

Generates random alphanumeric string, lowercase (characters: a-z, 0-9).

STRINGLN RAND_ALPHANUM        REM Generates 2 chars (e.g., "4c", "p9")
STRINGLN RAND_ALPHANUM 8      REM Generates 8 chars (e.g., "xywz7la3")
STRINGLN RAND_ALPHANUM 16     REM Generates 16 chars (e.g., "k9w2f7m4p1v8s3x6")

Default length: 2 characters

RAND_ALPHANUM_UPPER [length]

Generates random alphanumeric string, uppercase (characters: A-Z, 0-9).

STRINGLN RAND_ALPHANUM_UPPER     REM Generates 2 chars (e.g., "ET", "K4")
STRINGLN RAND_ALPHANUM_UPPER 6   REM Generates 6 chars (e.g., "PNC1GK")
STRINGLN RAND_ALPHANUM_UPPER 12  REM Generates 12 chars (e.g., "A7K9M2W5F3P8")

Default length: 2 characters

Practical Examples

Generate unique session identifier:

DEFINE #SESSION_ID RAND_HEX 16
STRINGLN Session: #SESSION_ID

Create randomized filename:

STRINGLN log_RAND_ALPHANUM_8.txt

Generate temporary password:

STRINGLN TempPass_RAND_ALPHANUM_UPPER 12

Inline usage in complex strings:

STRINGLN curl -X POST https://api.example.com/data?token=RAND_HEX_32

PowerShell variable with random value:

STRINGLN $sessionToken="RAND_ALPHANUM_UPPER 16"; Write-Host "Token: $sessionToken"

Important Notes

  • Compile-time generation: Random strings are generated during compilation, not at runtime
  • Deterministic per build: Each build generates new random values, but values are fixed in the compiled binary
  • Multiple instances: Each RAND command in your payload generates a separate random string
  • No repetition guarantee: While unlikely with sufficient length, duplicate values are possible across different RAND calls

Example demonstrating multiple independent random values:

REM Each RAND generates different value
STRINGLN ID1: RAND_HEX 8
STRINGLN ID2: RAND_HEX 8
STRINGLN ID3: RAND_HEX 8

REM Compiled output example:
REM   keyboard.println(F("ID1: a3f7c2d9"));
REM   keyboard.println(F("ID2: 8b4e1f6a"));
REM   keyboard.println(F("ID3: 5c9d2a7f"));

❌ NOT Supported (ATTiny85 Limitations)

The following DuckyScript features are not supported currently on the ATTiny85 Ducky due to hardware and memory constraints:

Advanced Language Features

REM_BLOCK / END_REM            ❌ Block comments

Attack Mode Features

ATTACKMODE STORAGE              ❌ ATTiny85 has no storage capability
ATTACKMODE OFF                  ❌ No power control
Runtime USB switching           ❌ USB identity set at compile-time only

Note: ATTACKMODE HID with USB parameters (VID/PID/MAN/PROD/SERIAL) IS supported for compile-time USB configuration. See docs/ATTACKMODE.md.

Variables & Operators

VAR $FOO = 42                   ❌ Variables
$FOO = ($FOO + 1)              ❌ Math operators
IF / ELSE / END_IF             ❌ Conditional statements
WHILE / END_WHILE              ❌ Loops
FUNCTION / END_FUNCTION        ❌ Functions
RETURN                         ❌ Return values

Randomization

RANDOM_CHAR                     ❌ Random character injection
$_RANDOM_INT                    ❌ Random integers
VID_RANDOM / PID_RANDOM        ❌ Random USB identifiers

Lock Keys & Detection

CAPSLOCK / NUMLOCK             ❌ Lock key toggle
WAIT_FOR_CAPS_ON               ❌ Lock key detection
$_CAPSLOCK_ON                  ❌ Lock key state variables
SAVE_HOST_KEYBOARD_LOCK_STATE  ❌ Lock state save/restore

Button Control

WAIT_FOR_BUTTON_PRESS          ❌ No physical button on ATTiny85
BUTTON_DEF / END_BUTTON        ❌ Button event handlers
ENABLE_BUTTON / DISABLE_BUTTON ❌ Button control

LED Control

LED_OFF / LED_R / LED_G        ❌ Specific LED commands

(The ATTiny85 has one built-in LED which lights during payload execution)

Attack Modes & Advanced Features

ATTACKMODE HID STORAGE         ❌ USB mode switching
SAVE_ATTACKMODE                ❌ Attack mode state management
HIDE_PAYLOAD / RESTORE_PAYLOAD ❌ Payload hiding
EXFIL / $_EXFIL_MODE_ENABLED  ❌ Keystroke reflection exfiltration

Key Hold/Release

HOLD a / RELEASE a             ❌ Holding keys
INJECT_MOD WINDOWS             ❌ Standalone modifier injection

Payload Control

RESTART_PAYLOAD                ❌ Payload restart
STOP_PAYLOAD                   ❌ Payload stop
RESET                          ❌ Keystroke buffer reset

Jitter & Timing

$_JITTER_ENABLED               ❌ Randomized typing delay
$_JITTER_MAX                   ❌ Jitter configuration

Example Payloads

Basic Example - Open GitHub Repository

REM Open GitHub repository in browser
DELAY 1000
GUI r
DELAY 500
STRINGLN https://github.com/3mrgnc3/attiny85_ducky
DELAY 100
ENTER

Using DEFINE for Reusable Values

REM Example with constants
DEFINE #WAIT 500
DEFINE #URL github.com/3mrgnc3

DELAY 1000
GUI r
DELAY #WAIT
STRING https://#URL
ENTER

Multi-Language Support

REM German keyboard layout
DUCKY_LANG DE

DELAY 1000
GUI r
DELAY 500
STRINGLN notepad
DELAY 800
STRINGLN Hallo Welt! Dies ist ein deutscher Text.

Linux Terminal Commands

REM Open terminal and run commands (Linux)
DELAY 1000
CTRL ALT t
DELAY 1000
STRINGLN uname -a
DELAY 500
STRINGLN whoami
DELAY 500
STRINGLN exit

Windows PowerShell Example

REM Windows PowerShell payload
DELAY 1000
GUI r
DELAY 500
STRINGLN powershell
DELAY 1500
STRINGLN Write-Host "System Information:" -ForegroundColor Cyan
DELAY 300
STRINGLN Get-ComputerInfo | Select-Object CsName, WindowsVersion, OsArchitecture
DELAY 300
STRINGLN exit

Memory Constraints

The ATTiny85 has very limited resources:

  • Flash: 6,012 bytes usable (8KB total)
  • RAM: 512 bytes
  • EEPROM: 512 bytes (unused by this project)

String Storage Strategy

All payload strings are automatically stored in PROGMEM (Flash memory) instead of RAM using the F() macro:

Generated Code Example:

// Strings stored in Flash using F() macro
keyboard.println(F("https://github.com/3mrgnc3/attiny85_ducky"));

This saves RAM for the keyboard library and system stack.

Payload Size Guidelines

  • Short payloads (< 20 commands): ✅ Always work
  • Medium payloads (20-50 commands): ✅ Usually work
  • Large payloads (50+ commands): ⚠️ May exceed flash capacity

Tip: Keep payloads focused on a single task. For complex operations, use multiple smaller payloads.

Language Support

The compiler uses the ATTinyDuckyKeyboard library with support for 30+ international keyboard layouts.

Available Languages

Code Language Layout
US English US QWERTY
BE Belgian Belgian AZERTY
BR Brazilian ABNT2
CA_FR Canadian French Canadian Multilingual
CH_DE Swiss German Swiss QWERTZ
CH_FR Swiss French Swiss French
CZ Czech Czech QWERTY
DE German German QWERTZ
DK Danish Danish QWERTY
ES Spanish Spanish QWERTY
FI Finnish Finnish QWERTY
FR French French AZERTY
GB English UK UK QWERTY
HR Croatian Croatian QWERTZ
IT Italian Italian QWERTY
NO Norwegian Norwegian QWERTY
PT Portuguese Portuguese QWERTY
RU Russian Russian ЙЦУКЕН
SI Slovenian Slovenian QWERTZ
SK Slovak Slovak QWERTY
SV Swedish Swedish QWERTY
TR Turkish Turkish F-keyboard

Default: US (if no DUCKY_LANG specified)

Using International Layouts

REM French keyboard layout
DUCKY_LANG FR

STRING Bonjour le monde!
STRINGLN Voici un message en français.

REM German keyboard layout
DUCKY_LANG DE

STRING Über den Wolken
STRINGLN ÄÖÜ äöü ß

Compilation Process

Automatic Compilation (Recommended)

The build system automatically compiles payload.ducky when you build your project:

platformio run

Build Process:

  1. PlatformIO pre-build hook runs pre_build_duckyscript.py
  2. Script checks for ducky_scripts/payload.ducky
  3. If found: compiles to src/main.cpp using tools/duckyscript_compiler.py
  4. If missing: build fails with colored error message
  5. PlatformIO compiles generated C++ code
  6. Upload to ATTiny85

Manual Compilation (Advanced)

You can manually compile any DuckyScript file:

python tools/duckyscript_compiler.py ducky_scripts/my_payload.ducky src/main.cpp

This overwrites src/main.cpp with the compiled payload.

Creating Your First Payload

  1. Create payload.ducky in this directory:

    REM My first payload
DELAY 1000
GUI r
DELAY 500
STRINGLN notepad
DELAY 1000
STRINGLN Hello from ATTiny85 Ducky!

  2. Build the project:

    platformio run

  3. Upload to ATTiny85:

    platformio run --target upload

    After running the command, Insert Digispark when prompted (within 60 seconds)

  4. Test the payload:

    • Unplug and replug the ATTiny85
    • Payload executes automatically
    • Built-in LED lights during execution

  5. Optionally install USBDeview from NirSoft

Troubleshooting

Build fails: "payload.ducky not found"

Solution: Create ducky_scripts/payload.ducky with your payload code.

The build system displays:

================================================================================
FAILURE: payload.ducky not found!
================================================================================

To fix this:

  1. Create the required payload file:
     ducky_scripts/payload.ducky

  2. Add your DuckyScript payload code

  3. Run the build again

"Unsupported command" warning

The compiler ignores unsupported commands silently. Check this README for supported commands.

String contains special characters (quotes, backslashes)

The compiler automatically escapes " and \ in strings. You can use them normally:

STRINGLN He said "Hello!"
STRINGLN Path: C:\Windows\System32

Generated code:

const char str_0[] PROGMEM = "He said \"Hello!\"";
const char str_1[] PROGMEM = "Path: C:\\Windows\\System32";

Payload doesn't work on target OS

  1. Check keyboard layout: Use DUCKY_LANG to match target system
  2. Increase delays: Slower systems need longer DELAY values
  3. Test manually: Type the same key sequence to verify it works

Compilation successful but upload fails

  1. Install Micronucleus drivers (Windows)
  2. Check USB port and try a different cable
  3. Insert device within 60 seconds when prompted
  4. Try a powered USB hub if using USB-C adapters

Payload Development Tips

1. Start with Delays

Always add initial delay to let the target system enumerate the USB device:

DELAY 1000
REM Your payload here

2. Add Delays Between Commands

Give the OS time to process each command:

GUI r
DELAY 500          REM Wait for Run dialog to open
STRINGLN notepad
DELAY 800          REM Wait for Notepad to launch

3. Test Incrementally

Build your payload step-by-step and test frequently. Don't write 100 lines before testing!

4. Use Comments

Document your payload so you remember what it does:

REM ======================================
REM Payload: System Info Grabber
REM Target: Windows 10/11
REM Author: Your Name
REM ======================================

5. Check Flash Usage

After building, check memory usage:

RAM:   [===       ]  31.2% (used 160 bytes from 512 bytes)
Flash: [=====     ]  52.3% (used 3144 bytes from 6012 bytes)

Stay under 90% flash to avoid issues.

Additional Resources

Official DuckyScript Documentation

ATTiny85 Resources

This Project

Example Payloads Included

Check the examples/ subdirectory for complete payload examples:

  • YTRoll/ScattRoll.ducky - YouTube auto-fullscreen prank
  • WiFiCredsDemo/wifi_creds.ducky - WiFi credential dumper for Windows
  • PopupsPrank/popups_prank.ducky - Downloads and executes popup prank script from GitHub
  • And More...

Each example includes the .ducky payload file and any supporting scripts.

Security & Legal Notice

⚠️ This tool is for authorized security testing and educational purposes only.

  • Only test on systems you own or have explicit permission to test
  • Unauthorized access to computer systems is illegal in most jurisdictions
  • The authors assume no liability for misuse of this tool

Responsible Disclosure: If you discover vulnerabilities using this tool, follow responsible disclosure practices and report to the vendor.

Contributing

Found a bug in the compiler? Want to add support for more DuckyScript commands?

  1. Fork the repository
  2. Create a feature branch
  3. Test your changes thoroughly
  4. Submit a pull request

Wishlist for Future Versions:

  • REPEAT command support
  • Basic IF/ELSE for simple conditions (if memory allows)
  • MENU, PAGEUP, PAGEDOWN keys
  • More comprehensive error checking

Happy Ducking! 🦆

Other Resources

Clone this wiki locally
