WireGuard VPN Demo In Android

A demo Android application showcasing how to integrate and control a WireGuard VPN tunnel on Android using Kotlin and Android’s native VpnService.

Read the full article on Medium.

---

📘 Overview

This project demonstrates how to build a simple VPN client that establishes a secure connection using WireGuard protocol.
It’s ideal for learning how to implement a WireGuard VPN, test configurations, or build production-ready VPN applications.

---

✨ Features

• Start and stop WireGuard VPN tunnel from Android app
• Setup WireGuard configuration
• Monitor connection status (Connected / Disconnected)
• Built with Kotlin, MVVM architecture, and Android VPN APIs
• Lightweight and easy to extend

---

🧰 Tech Stack

• Language: Kotlin
• Networking: WireGuard native implementation
• Android Components: VpnService, ViewModel
• Build System: Gradle (Kotlin DSL)

---

⚙️ Getting Started

1. Clone the repository

git clone https://github.com/satishnada/WireGuard-VPN-Demo.git
cd WireGuard-VPN-Demo

2. Open in Android Studio

• Open Android Studio (latest version)
• Select File → Open... and choose the cloned project folder
• Let Gradle sync dependencies automatically

3. Configure WireGuard

• Add your WireGuard .conf file in the app’s assets or define it directly in code
• Example configuration:

  [Interface]
  PrivateKey = <your_private_key>
  Address = 10.0.0.2/32
  DNS = 1.1.1.1

  [Peer]
  PublicKey = <peer_public_key>
  Endpoint = vpn.example.com:51820
  AllowedIPs = 0.0.0.0/0, ::/0

• Make sure your VPN endpoint is reachable.

4. Run the app

• Build and install the app on a real Android device
• Tap “Start VPN” to activate the WireGuard tunnel
• Accept the system VPN permission dialog

---

🧩 Project Structure

WireGuard-VPN-Demo/
│
├── app/
│   ├── src/main/
│   │   ├── java/com/example/wireguarddemo/
│   │   │   ├── MainActivity.kt
│   │   │   ├── WireGuardService.kt
│   │   │   └── utils/
│   │   └── res/
│   ├── AndroidManifest.xml
│   └── build.gradle.kts
│
├── gradle/
├── settings.gradle.kts
└── README.md

---

🚀 Future Enhancements

• Dynamic server selection
• Split tunneling and kill switch
• Real-time logs and connection analytics
• Multi-protocol support (WireGuard / OpenVPN)
• UI improvements with Compose

---

🤝 Contributing

Contributions are welcome!

1. Fork the repository
2. Create your feature branch (git checkout -b feature/my-feature)
3. Commit your changes (git commit -m 'Add feature')
4. Push to the branch (git push origin feature/my-feature)
5. Open a Pull Request

---

📄 License

This project is licensed under the Apache 2.0 License — see the LICENSE file for details.

---

⚡ Secure your network with WireGuard — fast, simple, and modern!
