Empyrion Configuration Editor

An application to simplify the handling and customizing of the .ecf configuration files of Empyrion Galactic Survival

Content

• Motivation
• Installation
• Feature Overview
• Tool Overview
• Operations Overview
• Shortcuts and Functions
• File Content Definition
• File Content Recognition
• Planned Major Features

Motivation

Over a long time lightweight modding Empyrion Galactic Survival was really simple by adjusting the config_example.ecf. Due to the mechanic that the changes were added to the default settings, just the additional adjustments must be maintained. The decision of Eleon to remove these add adjustments feature simply felt like:

Now all the whole bunch of tons of settings must be maintained at once even if adjusting just one tiny value of one silly block. The awkward .ecf format makes this feel like:

You know what i'm talking about? Here comes the solution!

Installation

Just download the latest release and unzip the content wherever you might need to. Run the executeable file and have fun!

Feature Overview

Content Definition

For each .ecf file the tool needs a definition. These definitions are located in .xml files in the EcfFileDefinitions sub folder of the zip package. For creating or adjusting the definitions yourself refer to File Content Definition. After loading a .ecf file the definition is attached to it. To reinterprete a .ecf file with a different or changed definition the .ecf file must be closed and reopened. The actual version of the tool is shipped with definitions for:

• BlockGroupsConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• BlocksConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• BlockShapeWindow.ecf (Vanilla, Dark Faction)
• Containers.ecf (Vanilla, Dark Faction and Reforged Eden)
• DefReputation.ecf (Vanilla, Dark Faction and Reforged Eden)
• EClassConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• EGroupsConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• Factions.ecf (Vanilla, Dark Faction and Reforged Eden)
• FactionWarfare.ecf (Vanilla, Dark Faction and Reforged Eden)
• GalaxyConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• GlobalDefsConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• ItemsConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• LootGroups.ecf (Vanilla, Dark Faction and Reforged Eden)
• MaterialConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• StatusEffects.ecf (Vanilla, Dark Faction and Reforged Eden)
• Templates.ecf (Vanilla, Dark Faction and Reforged Eden)
• TokenConfig.ecf (Vanilla, Dark Faction and Reforged Eden)
• TraderNPCConfig.ecf (Vanilla, Dark Faction and Reforged Eden)

Content Recognition

At file loading the tool parses the file content according to the attached definition. The tool is balanced to the variety of the subtleties of the spellings in the .ecf files. Due to the design goal the output should match input in at much details as possible the tool in its release state will likely also report failures in the default .ecf files of the game. This is not a tool bug, but developer inaccuracies that may or may not be compensated for by a fallback. In order to achieve reliable behavior, I have chosen to report such bugs rather than legitimizing these inaccuracies by the definition. For details see File Content Recognition.

Content Creation

At saving a .ecf file the whole content in the file is wiped and recreated. At default setting elements with unsolved errors will not be written to the file. Instead the tool tries to recreate the data originially read from the file. Due to the nature of the .ecf syntax of consecutive specifications its recommended to

- solve errors from top to bottom

to not follow rabbits.

Language and Tool Support

The icons and controls have tooltips on mouse over. All labels and tootips are localised. At the moment de-DE and en-GB is supported. The language switches automaticly based on the local machine culture setting, defaulting to en-GB.

Add, Edit, Remove Content

The basic functionality of this tool is the alteration of any .ecf content.

Mass Changing

🔧 Not implemented yet 🔧

Compare and Merge

The tool is capable of comparing two .ecf files, listing the differences and offer several options to update the opposite file partly or completely.

Tech Tree Editor

The tool is capable of editing the "TechTree" which is based on several properties spreaded over different files and file elements.

Item Handling Support

The context menu provides several functions like adding, removing or listing linked elements of corresponding .ecf files depending on which element is clicked and to which file type the item belongs to.

Tool Overview

File Operation Area (1)

The standard file operations (new, open, reload, save, close) are located in this area. The cross-file functions (diff, merge, xml) are also arranged here.

Filter and File Selection Area (2)

In this area each opened file will get a tab containing the file name. The label in the tool line indicates the attached game mode and content definition, for example Vanilla and BlocksConfig. The remaining icons provide different filter options applied to all content view areas.

Content Operation Area (3)

The tools in this area provide content altering options like adding, editing or removing elements. The copy/paste function is located here, too.

Settings Area (4)

The label shows the actual selected game mode and grants a temporary quick change option on click. The gear button opens the persistent settings menu.

Tree View Area (5)

The tree view area brings the structural overview. The root elements, child elements, parameters and comments are displayed in this view. If an element has an error the entry in this view will turn red.

Parameter View Area (6)

The parameter view area shows the detail information of any parameter correlating to the selected tree element. Additionally the view analyzes and displays the inheritance dependancies to referenced elements to provide a overview over all parameters effecting the selected element. If an parameter has an error the entry in this view will turn red.

Info View Area (7)

The info area displays additional detail information for the selected tree element and the selected parameter. Especially the element attributes (e.g formatter) can be found here.

Error View Area (8)

In the error view all occured errors are listed. The view shows the error category and type together with additional information like line in file (if applicable) and the error producing data part.

Operations Overview

Changing settings

The gear button ( ) opens a settings panel with several settings. The abort button closes the panel and discarding all changes. The save button saves the settings persistent and closes the panel. The reset button reloads the default settings.

Opening a file

After selecting the file to open the tool tries to guess which definition fits to the file by examining the file name. If this is successful the guessed definition is automaticly selected in the following dialog. In this case the Dialog can be skipped with Ok. When the guessing fails or a new file is created the definition must be selected manually from the provided drop down list.

For especially big files like BlocksConfig.ecf (or especially lame PCs 🤪) a loading dialog is shown while parsing the file content.

Adding And Editing Content

At adding or editing (see Shortcuts and Functions) the editor dialog is shown. The dialog is designed to not produce elements with errors. To achive this support pre opening checks, pre filled selection lists and pre closing checks will be performed. These logics depends primary on the attached file definition and the present content data.

At multi selection the panel will normally open for the first selected element. If only parameters are selected (even across parent element borders) the panel will enter a matrix editing mode. This mode provides a table organized structure for matrix arranged parameters or to edit equal parameters of different parents in one view.

Comparing and Merging Files

In the compare and merge function ( ) the compare is started by selecting two of the opened files. Depending on file size a progress bar will be displayed until completion.

The two tree views will display all elements which differs between the two files. If no elements are displayed the two files are completely equal. The displayed elements belongs to the three categories:

• add / element will be created in opposite file
• unequal / element will be updated in opposite file
• remove / element will be deleted in opposite file

After clicking one of the merge buttons ( / ) all checked elements behind the arrow will be merged into the file the arrow points to.

With the buttons above the tree view its possible to check / uncheck all elements of the corresponding category. In the tree view itself single elements can be checked / unchecked. The buttons above the tree view will display an indeterminated state to indicate the mixed state across pages of elements.

To maintain a suitable performance only a limited amount of diff elements will be displayed at once. If this limit is exceeded all additional elements will be moved to a second (or more) page. The two page select buttons ( / ) change the displayed page.

Clicking an element in the tree view will trigger the detail difference display at the lower window. The two text boxes again will only display differences. If this boxes are empty the selected element has no difference to the opposite element. If an element is marked as unequal but the details boxes shows no difference only a structural sub element contains a difference.

Tech Tree Editing

At clicking the Tech Tree Editor function ( ) the tool parses the content of all opened files and shows the computed resulting Tech Trees as tabs. The parameters used for the computation can be altered within the new settings section Tech Tree found in the settings window. If new Tech Trees are added the localized name must be added manually to the localisation file of Empyrion. The Editor just uses the .ecf internal names. The tool can add, remove, rename and copy Tech Trees. Additionally it can add, remove, change and copy element details and element structures.

The element order question is a difficult one. Empyrion uses a ordering logic for the ingame display of the Tech Trees which is not predictable. This tool orders the elements as they appear in the .ecf files. The ingame order may vary but the tree element dependencies are not effected from this.

New elements can only be added if they are not already used in a Tech Tree. Elements which are already in a Tech Tree can only be copied to align with the mirrowing behaviour of Empyrion. A element must have the exact equal parent element structure in all containing Tech Trees. To preserve the integrity across the Tech Trees changes violating this rule will automaticly be spreaded to all Tech Trees the copied element belongs to.

All changes done in the Tech Tree Editor will directly effect the corresponding opened files. After closing the Tech Tree Editor window the files need just to be saved.

Using Item Handling Support

Item Handling Support provides functions to manipulate elements across the border of .ecf files. The function will be shown context sensitive for elements and files for which a specific function is valid. All remove functions check and report warnings for possible dependency breaks before a specific function is performed. If the warning is confirmed the function will be performed anyway. The possibly resulting error will not be listed in the error view since the tool cannot determime if an error is logically located in the source file or linked file. The dependency checks are integrated in the generic remove and change function too.

The support functions only consider .ecf files which are opened in the tool. If a function reports that nothing could be found first check if the corresponding file is opened. Available are generic 'list' functions like 'list parameter user' or 'list parameter value user' and type specific functions like 'list template', 'show template', 'add template' or 'remove template'. For the first approach of this contextual dependencies the functions are implemented for:

• BlockGroupsConfig.ecf
• GlobalDefsConfig.ecf
• Templates.ecf

The settings menu has a new page for the item handling support functions options. Along with several options for parameter keys and presettings the dependency check for generic item operations (change, remove) can be disabled.

With the Item Handling Support the definition file handling is extended too. A item can be added to a definition from within the tool. This can be the own definition (missing definition error) or the definition of another 'ecf' file (needed for dependency) if the context requires it. The 'online' changeability of definitions comes together with the function to reinterprete (reload) already opened files with the changed definition. After adding a parameter to a definition the tool asks to reinterprete corresponding files. The reinterpretation can be performed manually too. For example after changing the game mode.

Shortcuts and Functions

Shortcuts

• double-click opens the edit panel for the clicked item
• right-click opens the context panel for the clicked item
• delete key removes the selected items
• strg + c key copies the selected items to the clipboard
• strg + v key pastes the copied items into the selected item, or after it if insertion is not allowed for the item

Context Panel

Tree View Context Panel

The context panel of the tree view provides access to the content operations suitable for tree items.

Parameter View Context Panel

The context panel of the parameter view provides access to the content operations suitable for parameter items.

Error View Context Panel

The context panel of the error view has support functions for error tracking.

Sorting

The three listing views Tree View Area, Parameter View Area and Error View Area have a sorting panel each. The sort panel provides settings for concurrent items and various sorting options.

Icons

Settings

• opens the settings panel

File Operations

• create new file
• open existing file
• reload content from selected file
• save selected file
• save selected file with new name
• save all opened files
• close selected file
• close all open files
• compares two files, displays differences and offer merge options (see Compare and Merge)
• displays the tech tree editor (see Tech Tree Editor)
• reloads the .xml definitions (see File Content Definition)
• replaces the .xml definition in selected file (see Item Handling Support)
• checks the .xml definitions (see File Content Definition)

Filter and Sorting Operations

• apply filter
• clear filter
• show item with / without error
• switch the sort direction
• sets sorting to the origin (file) order
• sets sorting to alphabetic order

Content Operations

• add item to / after selection
• editing first selected item
• editing items with logics (see Mass Changing)
• removing selected items
• copy selected items
• paste copied items to / after selection
• undo last change
• redo last undo
• move selected items up
• move selected items down
• add value slot after selection
• add value group after selection
• remove selected value slot
• remove selected value group

Error Operations

• show error in tool
• show error in file

Compare and Merge

• change checkmark of all "add" items
• change checkmark of all "unequal" items
• change checkmark of all "remove" items
• process all checked items to the opposite file
• switch displayed page

Item Handling Support

• list linked items (for example templates)
• show linked item (for example template)
• add item of linked type (for example template)
• remove item of linked type (for example template)
• add item to linked definition (for example template)

File Content Definition

The file content definition is the basic information for the tool which content is viable in the loaded .ecf file and which is not. To achive the design goal to be reliable able to load and interprete .ecf files from any source (default files, text editor tool files, manually edited files and so on) the definition provides several options.

The definitions will be read from the EcfFileDefinitions sub folder from the tool root directory. The file name doesn't matter. Each file in this directory will be read, even in sub directories. The first entry in each file must contain the game mode and the definition name, both also shown in the tool. The definition name is the link to the corresponding .ecf file (for guessing) and must be unique. Every further .xml file with the same mode and type setting will be ignored.

If the EcfFileDefinitions sub folder is missing or empty the tool will create a simple template .xml file for BlocksConfig.ecf. This file can be used as starting point for creation of own files and is structural complete, but will likely be incomplete compared to the expected .ecf content.

After starting the tool the present .xml files are loaded and prepared for use. Changing the .xml files after running the tool will not be recognized by the tool. If you want the tool to reload the definitions just hit the respective button ( ). Due to the intended behaviour to not alter the definitions of opened .ecf files, reloading the '.xml' definitions or changing the game mode setting not effecting already opened .ecf files.

After bigger patches of Empyrion Galactic Survival a definition maybe can partly went deprecated. In this case a backwards check of the definition is recommended. This can be done (if I'm too lame to release an update 😴) by hitting the respective button ( ). This function compares the actual selected .ecf file against the latest loaded .xml definition of the same type and lists the .xml content definition for which no content is found in the .ecf file.

Xml File Content

The definition uses often the terminology Block. Don't missinterprete this with an Empyrion ingame block. In Xml-speaking Block stands for a .ecf data block.

The ContentLinking chapter of the .xml files provides settings for the file content in relation to other .ecf files and for referencing within the file.

The formatting chapter of the .xml files provides settings for the basic .ecf syntax. This chapter should mostly be similar for all .ecf files.

After the formatting follow the sub chapters for the different elements of the .ecf files. This chapter contains the expected .ecf content.

The available chapters are:

• BlockTypePreMarks the expected pre marks after the block opener (e.g. +)
• BlockTypePostMarks the expected seperators to define the end of the block type (e.g. )
• RootBlockTypes the expected data types of blocks in the root level (e.g. Block)
• RootBlockAttributes the expected attributes for blocks in the root level (e.g. Id)
• ChildBlockTypes the expected data types of blocks not in the root level (e.g. Child)
• ChildBlockAttributes the expected attributes for blocks not in the root level (e.g. DropOnDestroy)
• BlockParameters the expected parameters for the data blocks (e.g. Material)
• ParameterAttributes the expected attributes for the parameters (e.g. formatter)

Each .xml Param line item can hold different switches to control the behaviour of the error checking while parsing and editing the .ecf content. The chapters are allowed to be empty, but remind that the respective functions in the Editor Panel will be switched off without the definition set.

• name the name of the .ecf element (e.g. Material)
• optional determines if this element is optional, non-optional elements will be treated as mandatory and can in some cases overwrite optional ones
• hasValue determines if this element has (reading) / should have (creation) a value
• allowBlank determines if for this element a empty value is allowed
• forceEscape determines if at creation this element must be escaped, useful for text references like TechTreeParent
• info a free text to preserv designer infos for the element, shown in the tool, not written to the file

File Content Recognition

The Parsing of the .ecf tries to interprete the whole variety of spellings present in the different files. To minimize result validation efforts and to preserv the readability of the files by Empyrion Galactic Survival, the tool reproduces nearly the same spelling as the original file.

The exceptions are the white spaces, the empty lines and the comments. All the function-irrelevant white spaces and empty lines will be remove. All the different varieties of comment spellings will be streamlined to appended inline comments.

The tool parses the .ecf file content line by line and seperates the line content item by item according to the definition and chronologic. A fault can depending on its severity lead to a whole bunch of follower errors. This is the reason of solving errors from top to bottom.

In the settings are several behaviour adjustments possible how the tool should handle errors at writing content to the file:

• Write only valid items to file Unchecking this option activates the behaviour that all elements will be written in its current state from within the tool. Notice that the file is the persistent storage. After loading a file written with this option unchecked several informations and the resulting errors will be gone.
• Invalidate parent of invalid item Checking this option activates the behaviour that error states will be inherited structure upwards. A error of a sub element invalidates its containing element upto the root element.
• Allow fallback to original data Unchecking this option activates the behaviour that elements with errors has no permission to try to use the data from the original file. In this case a creation error will be reported. Notice that even with this option checked the error could occur for newly created elements which have no original data available.

The default setting will not write elements with errors to the resulting file and the tool will try to recreate the data read from the original file. In the error view all occured errors will be listed. The errors belong to the four categories structural, interpretation, editing or creation:

Structural Error

This errors occur during the parsing of the content at the loading of the .ecf file. The corresponding line in the file violates the syntax in a manner which makes it impossible to attach this data to the managed structure within the tool. Such an error must be corrected in the original file if the data content is needed.

Interpretation Error

This errors occur during the parsing of the content at the loading of the .ecf file. It means that the found data basically fits to the .ecf syntax but the content is unknown or contains invalid data compared to the definition. It can in mostly all cases be corrected in the tool.

Editing error

This errors occur during content editing in the tool at operations which would consume too much performance to prevent it by a pre check (or similar). It has the same meaning as Interpretation errors and can in all cases be corrected in the tool.

Creation error

This errors occur during content writing at hitting save. This error depends on the error handling settings. It only reports elements that should be written but according to the settings no writeable data is available/permitted. It states if an element is not written because it contains an error and no fallback data from parsing could be found.

Planned Major Features

• "Custom changed" Property for ecf items (storage, handling, display and usage)
• Item Handling Support roll out for Entities, Loot/Containers, Factions
• Element, Parameter, Attribute, Comment mass changing (base on filter/types)
• Element, Parameter, Comment moving
• Undo / Redo
