LFF Spatial ERC

Overview

Welcome to the LFF_spatial_ERC project! 🧠

In this work we built a transcriptional profile of the human entorhinal cortex (ERC) with single nucleus RNA sequencing (snRNA-seq) and spatially resolved transcriptomics (SRT) from 31 neurotypical post-mortem donors with diverse risk for Alzheimer's disease (AD). SRT data was generated with 10x Genomics Visium, snRNA-seq was generated with 10x Genomics Chromium.

We then assessed changes in gene expression associated with risk of AD by APOE carrier status (E2+ vs. E4+), as well as APOE changes specific to ancestry groups (African ancestry or European ancestry), and sex.

This work is being was performed by members of Leonardo Collado-Torres, Kristen Maynard, and Keri Martinowich, teams at the Lieber Institute for Brain Development as well as Mina Ryten's group from UK DRI Cambridge.

Thank you for your interest in our work!

Study Design

Schematic depicting cohort composition stratified across APOE genotype, sex, and ancestry as well as experimental design for generation of snRNA-seq and SRT data from postmortem human ERC tissue.

Interactive Websites

We provide the following interactive websites to explore the ERC data:

• 🔭 LFF_ERC_Visium: Visium data for 31 samples post-QC w/ clustering and modeling results

• 🔭 LFF_ERC_Visium_QC: Visium data for 31 samples pre-QC drops (including out-tissue spots)

• 👀 iSEE: snRNA-seq data for 31 samples

All of these interactive websites are powered by open source software, namely:

• 🔭 spatialLIBD See spatialLIBD website for more information
• 👀 iSEE

Citing our work

Please cite our pre-print 10.1101/2025.11.20.689483 if you use data from this project.

Huuki-Myers, L. A., Divecha, H. R., Bach, S. V., Valentine, M. R., Eagles, N. J., Mulvey, B., Bharadwaj, R. A., Zhang, R., Evans, J. R., Grant-Peters, M., Miller, R. A., Kleinman, J. E., Han, S., Hyde, T. M., Page, S. C., Weinberger, D. R., Martinowich, K., Ryten, M., Maynard, K. R. & Collado-Torres, L. apoe E4 alzheimer’s risk converges on an oligodendrocyte subtype in the human entorhinal cortex. BioRxiv (2025). doi:10.1101/2025.11.20.689483

Below is the citation in BibTeX format.

@article{Huuki-Myers_Divecha_Bach_Valentine_Eagles_Mulvey_Bharadwaj_Zhang_Evans_Grant-Peters_et al._2025,
title={apoe E4 alzheimer’s risk converges on an oligodendrocyte subtype in the human entorhinal cortex},
DOI={10.1101/2025.11.20.689483},
abstractNote={<p>The entorhinal cortex (ERC) is implicated in early
    progression of Alzheimer’s disease (AD). Here we investigated the impact of
    established biological risk factors for AD, including APOE genotype
    (E2 versus E4 alleles), sex, and ancestry, on gene expression in the human
    ERC. We generated paired spatially-resolved transcriptomics (SRT) and
    single-nucleus RNA sequencing data (snRNA-seq) in postmortem human ERC
    tissue from middle aged brain donors with no history of AD. APOE-dependent
    changes in gene expression predominantly mapped to a
    transcriptionally-defined oligodendrocyte subtype, which varied
    substantially with ancestry, and suggested differences in oligodendrocyte
    differentiation and myelination. Integration of SRT and snRNA-seq data
    identified a common gene expression signature associated with APOE genotype,
    which we localized to the same oligodendrocyte subtype and a white matter
    spatial domain. This suggests that AD risk in ERC may be associated with
    disrupted oligodendrocyte function, potentially contributing to future
    neurodegeneration.</p>},
journal={BioRxiv},
author={Huuki-Myers, Louise A. and Divecha, Heena R. and Bach, Svitlana V.
and Valentine, Madeline R. and Eagles, Nicholas J. and Mulvey, Bernard and
Bharadwaj, Rahul A. and Zhang, Ruth and Evans, James R. and Grant-Peters,
Melissa and et al.},
year={2025},
month={Nov}}

Data & Code avalibility

Data and code for this project are available on Github.

Organization of code, data, and plots follows our team's project template.

Raw data generated as a part of this study have been deposited on the Gene Expression Omnibus (GEO) with accession numbers GSE307990 (SRT data) and GSE308007 (snRNA-seq data).

Processed data files (R objects) used to make the interactive apps (logcounts only) can be found on our Globus Endpoints under the heading jhpce#LFF_ERC.

R objects with both the counts and logcounts can be downloaded through the fetch_data() function from spatialLIBD website v1.23.1 or newer.

Source code is under the MIT License and permanently archived on Zenodo. The GitHub repository includes log files with specific software versions used for each analysis.

Funding

This project was supported thanks to the Carol and Gene Ludwig Award for Neurodegeneration Research (DRW) from the Ludwig Famiy Foundation and the Lieber Institute for Brain Development.

Main Data

snRNA-seq

SingleCellExperiment

• project path: "processed-data/sce_objects/sce_ERC_subcluster" (Not on github due to large file size: 36G)

## Load HD5F sce
sce <- HDF5Array::loadHDF5SummarizedExperiment(here::here("processed-data", "sce_objects", "sce_ERC_subcluster"))
# class: SingleCellExperiment
# dim: 38606 122004

Input files

• FASTQ: raw-data/FASTQ_snRNAseq

• Sample ID table: processed-data/04_snRNA-seq/erc_sn_sample_info.csv

Pseudobulked snRNA-seq & modeling data

• cell type subcluster pseudobulk: processed-data/04_snRNA-seq/29_sn_subcluster_model_pseudobulk/sce_subcluster_pseudobulk-cell_type_anno.rds

• cell type subcluster modeling: processed-data/04_snRNA-seq/29_sn_subcluster_model_pseudobulk/sce_subcluster_modeling_results-cell_type_anno.rds"

• cell type broad pseudobulk: processed-data/04_snRNA-seq/29_sn_subcluster_model_pseudobulk/sce_subcluster_pseudobulk-cell_type_broad.rds

• cell type broad modeling: processed-data/04_snRNA-seq/29_sn_subcluster_model_pseudobulk/sce_subcluster_modeling_results-cell_type_broad.rds

SRT/Visium

SpatialExperiment

• project path: "processed-data/spe_objects/spe_ERC_annotated"

• pre-QC version: processed-data/spe_objects/spe_raw.rds (Not on github due to large file size: 4G)

## Load HD5F spe
spe <- HDF5Array::loadHDF5SummarizedExperiment(here::here("processed-data", "spe_objects", "spe_ERC_annotated"))
# class: SpatialExperiment
# dim: 30494 122202

Input files

• FASTQ: raw-data/FASTQ

• Images: raw-data/FASTQ/Images

• SAMPLE ID table: processed-data/02_build_spe/sample_info.csv

Pseudobulked Visium & Modeling data

• pseudobulk: processed-data/05_spe_correct_cluster/20_model_pseudobulk_anno/spe_pseudobulk-SpD.rds

• modeling data: processed-data/05_spe_correct_cluster/20_model_pseudobulk_anno/modeling_results-SpD.rds

Internal

JHPCE location: /dcs05/lieber/marmaypag/LFF_spatialERC_LIBD4140/LFF_spatial_ERC/

snRNA-seq main data JHPCE path: "/dcs05/lieber/marmaypag/LFF_spatialERC_LIBD4140/LFF_spatial_ERC/processed-data/sce_objects/sce_ERC_subcluster"

SRT main data JHPCE path: /dcs05/lieber/marmaypag/LFF_spatialERC_LIBD4140/LFF_spatial_ERC/processed-data/spe_objects/spe_ERC_annotated
