🌊 Aqua-TTS: GPT-SoVITS Low-Latency Inference Runtime on GPU

Built for low-latency voice conversation with your LoRA characters

中文 | English

Aqua-TTS is a GPU-optimized inference runtime purpose-built for real-time voice conversation — specifically, low-latency streaming TTS with your own GPT-SoVITS v3 LoRA character voices. It does not replace model weights — it replaces the execution strategy: static KV cache buffers, bucketed CUDA Graph capture/replay, FlashAttention2 when compatible, and an ABI-keyed BigVGAN CUDA extension cache. On an RTX 4070 Ti SUPER, the current deterministic benchmark reaches 568–645 synchronized it/s with FA2 and 477–519 it/s through the automatic SDPA fallback. Warm model-side first-audio medians are 233 / 288 / 348 ms for the short, medium, and long cases below. In the full streaming player pipeline, practical first-audio latency is usually 0.4–0.7 s depending on chunk length, audio device startup, cache state, and scheduling overhead.

Highlights

_{Latency definitions: TTFP benchmark = model-side first audio latency under warm-cache (table below). E2E first-audio = full pipeline including audio buffer and playback startup, typically 0.4–0.7 s in practice. Cold start = init + model load + first inference, dominated by BigVGAN CUDA kernel compilation (~2 min on first run, then cached).}

	Upstream T2S execution*	Aqua Graph + SDPA	Aqua default (FA2 `valid`)
T2S short / bucket 448	145.5 it/s	490.0 it/s	568.5 it/s
T2S conversation / bucket 512	153.5 it/s	519.3 it/s	627.4 it/s
T2S long / bucket 768	156.0 it/s	476.9 it/s	644.9 it/s
TTFP short (3 chars)	416.8 ms	250.5 ms	233.1 ms
TTFP medium (19 chars)	692.7 ms	305.0 ms	287.7 ms
TTFP long (64 chars)	1135.2 ms	394.2 ms	348.3 ms
Model definition	Direct upstream module	Validated upstream + in-memory overlay	Validated upstream + in-memory overlay
Decode attention	Native PyTorch, dynamic KV	SDPA over static bucket	FA2 over true KV length
KV-cache writes	Per-token `torch.cat`	In-place `scatter_`	FA2 KV-cache update
KV allocation	Grows per token	Pre-allocated and bounded per bucket	Pre-allocated and bounded per bucket
CUDA Graph	None in the standard entry point	15 common graph keys / 6 configured buckets + lazy capture	15 common graph keys / 6 configured buckets + lazy capture
Replay synchronization	Eager launches	Stream-ordered; no per-token device sync	Stream-ordered; no per-token device sync
EOS host read	Native condition checks	Greedy + sampled EOS combined once	Greedy + sampled EOS combined once
Graph concurrency	N/A	Lock per `(bucket, initial_len)` key	Lock per `(bucket, initial_len)` key
Failure path	Dynamic decoder	Graph → static KV → dynamic	FA2 → SDPA; Graph → static KV → dynamic
BigVGAN activation	Runtime extension/JIT path	ABI-keyed CUDA cache → PyTorch fallback	ABI-keyed CUDA cache → PyTorch fallback
Streaming contract	Native upstream generators	Generators preserved; only direct `infer_panel()` patched	Generators preserved; only direct `infer_panel()` patched

Benchmark environment: RTX 4070 Ti SUPER (16 GB), PyTorch 2.5.1+cu124, fp16, upstream 08d627c. T2S throughput uses 15 warmups and seven synchronized repeats per fixed shape. TTFP uses the same Aqua text/SoVITS/BigVGAN pipeline for all three columns so the T2S execution mode is isolated; it uses two warmup utterances, five repeats, a matching cached BigVGAN CUDA extension, and 0.25 s chunks. The published v0.2.0 Aqua TTFP was ~257 / 301 / 404 ms; current FA2 medians are ~9% / 4% / 14% lower. FA2 is attempted automatically when importable and falls back to SDPA; set AQUATTS_T2S_FLASH_ATTN=0 to force SDPA. One-time long-text frontend initialization produced a ~3 s first repeat, retained in the raw evidence but excluded by the median. See benchmarks/README.md for commands and methodology.

Aqua_tts_e2e_demo1.mp4

Features

Static KV cache — pre-allocated scatter buffers eliminate per-step torch.cat overhead
Bucketed CUDA Graph — 15 common graph keys pre-captured across 6 configured bucket sizes, with lazy capture for uncommon shapes
Cached BigVGAN CUDA extension — NVIDIA kernel cached by GPU/Python/Torch/CUDA ABI, with torch fallback
Adaptive FlashAttention2 KV cache — flash_attn_with_kvcache valid mode is preferred automatically, with SDPA fallback
Streaming API — generator-based infer_stream() with early first-audio yield
Built-in presets — fast / balanced / quality generation presets; full / minimal / lazy / off CUDA Graph presets
Voice registry — map voice names to reference audio + prompt, with JSON persistence
HTTP server — lightweight FastAPI server with streaming TTS endpoint, voice management, and health check
PyPI install — pip install "aqua-tts[runtime]" → from aquatts import TTSInferencer

Scope notice — Aqua-TTS is an optimization layer for upstream GPT-SoVITS v3. It loads the selected upstream Text2SemanticDecoder, validates the required contract, and patches only the direct infer_panel() path. Upstream batching and streaming entry points remain intact; incompatible upstream changes fail closed. GPT-SoVITS v4 is not currently supported.

Known limitations — Windows + CUDA is the primary tested path. Linux passes unit tests but GPU-dependent paths (CUDA Graph, BigVGAN kernel) have not been validated on Linux hardware. macOS is not supported. TTFP varies with GPU model, audio device, chunk size, and model weights — numbers in this README are measured on an RTX 4070 Ti SUPER with specific v3 LoRA weights and should not be treated as universal. Only GPT-SoVITS v3 is supported.

Supported Languages

Aqua-TTS inherits GPT-SoVITS v3's language support. Pass the code to text_language / prompt_language — reference audio and target text can use different languages.

Language	Code
Japanese	`日文`
Chinese	`中文`
English	`英文`

How it works

Aqua-TTS loads model definitions and text/runtime modules from the checkout selected by GPT_SOVITS_HOME. After the checkpoint is loaded it applies the static-KV/CUDA-Graph optimization in place. The small namespace bridge under _vendor/ redirects only BigVGAN's CUDA activation to Aqua's canonical extension loader; it does not contain a forked t2s_model.py:

aqua-tts/
├── aquatts/                       # Pure Python package (pip-installable)
│   ├── __init__.py                # sys.path configuration + lazy exports
│   ├── upstream.py                # Upstream checkout validation and routing
│   ├── inferencer.py              # TTSInferencer — main entry point
│   ├── server.py                  # FastAPI HTTP server
│   ├── voice_registry.py          # Voice name → audio path mapping
│   ├── modeling/
│   │   ├── t2s_streaming.py       # T2SBlockWithStaticCache, CUDA Graph patch
│   │   └── t2s_flash_attn.py      # Adaptive FlashAttention2 KV-cache patch
│   ├── bigvgan/
│   │   ├── cuda/                  # Standalone CUDA kernel loader + sources
│   │   └── torch/                 # Pure-PyTorch fallback (resample, filter, act)
│   ├── inference/
│   │   ├── streaming.py           # Audio post-processing (fade, chunk finalization)
│   │   ├── params.py              # SoVITS parameter presets
│   │   └── presets.py             # Named presets (generation + CUDA Graph)
│   └── _vendor/
│       └── GPT_SoVITS/            # Namespace bridge; no model fork
│           └── BigVGAN/alias_free_activation/cuda/  # Thin Aqua loader adapters
├── benchmarks/                    # TTFP, T2S comparison, BigVGAN raw benchmarks
├── examples/                      # basic_usage.py, streaming_inference.py
└── tests/                         # Unit tests

See TECHNICAL.md for deep technical documentation.

Requirements

	Entry	Recommended
GPU	RTX 3060 6 GB	RTX 4060 / 4070 8 GB+
CUDA	11.8+	12.x
RAM	8 GB	16 GB+
Python	3.10	3.11 / 3.12
OS	Windows 10+	Windows 11

Linux CI (Ubuntu) passes for all unit tests. GPU-dependent paths (CUDA Graph, BigVGAN kernel) have not been tested on Linux hardware. macOS is not supported — Aqua-TTS requires CUDA.

On 6 GB cards, use cuda_graph_preset="lazy" or "off" to reduce VRAM pressure from pre-captured graphs.

Installation

1. Install GPT-SoVITS

You need a working GPT-SoVITS v3 installation. Aqua-TTS imports from it.

git clone https://github.com/RVC-Boss/GPT-SoVITS.git
cd GPT-SoVITS
pip install -r requirements.txt

Aqua-TTS has been tested against GPT-SoVITS v3 (2025-04-01 release).

2. Install PyTorch

Install PyTorch matching your CUDA version before installing Aqua-TTS — it is not included in the package dependencies so you can pick the right CUDA wheel:

# Example for CUDA 12.1 — see https://pytorch.org/get-started/locally/ for other versions
pip install torch --index-url https://download.pytorch.org/whl/cu121

Aqua-TTS has been tested with PyTorch 2.5.1+cu121 on an RTX 4070 Ti SUPER.

3. Install Aqua-TTS

# Core + runtime dependencies from PyPI
pip install "aqua-tts[runtime]"

# Or with HTTP server support
pip install "aqua-tts[server]"

# Or with local playback support
pip install "aqua-tts[playback]"

For development or unreleased changes, install from source instead:

git clone https://github.com/Lucas1479/Aqua-TTS.git
cd Aqua-TTS
pip install -e ".[runtime]"

Extras:

[runtime] — soundfile, librosa, peft (needed by TTSInferencer)
[server] — FastAPI + uvicorn (includes [runtime] automatically)
[playback] — PyAudio (includes [runtime] automatically)

4. Configure GPT-SoVITS path

Set the GPT_SOVITS_HOME environment variable to your GPT-SoVITS repo root:

# Windows (PowerShell)
$env:GPT_SOVITS_HOME = "C:\path\to\GPT-SoVITS"

# Linux / macOS
export GPT_SOVITS_HOME=/path/to/GPT-SoVITS

5. Download pretrained models

Aqua-TTS needs BigVGAN v2 pretrained weights from Hugging Face. Download them directly into your GPT-SoVITS repo with huggingface_hub:

pip install huggingface_hub
python -c "
from huggingface_hub import snapshot_download
snapshot_download(
    repo_id='nvidia/bigvgan_v2_24khz_100band_256x',
    local_dir='GPT_SoVITS/pretrained_models/models--nvidia--bigvgan_v2_24khz_100band_256x',
)
"

The models--nvidia--bigvgan_v2_24khz_100band_256x directory name is the HuggingFace Hub cache format — use it exactly as shown.

6. Prepare model weights

GPT weights (T2S): A Text2SemanticLightningModule checkpoint (e.g., s1v3.ckpt or self-trained xxx-e15.ckpt).
SoVITS weights (vocoder): A SynthesizerTrn checkpoint with optional LoRA (e.g., xxx_e2_s174_l32.pth).
Reference audio: A 3-10 second 24 kHz WAV file with known transcript.

Quick sanity check

Once GPT_SOVITS_HOME is set and models are in place, verify the package loads correctly:

python -c "from aquatts import TTSInferencer; print('aquatts OK')"

If this prints aquatts OK, the install is good. If it errors, check that GPT_SOVITS_HOME points to the right directory and all pretrained models are downloaded.

Usage

Python API

import os
os.environ["GPT_SOVITS_HOME"] = "/path/to/GPT-SoVITS"
os.environ["ENABLE_CUDA_GRAPH"] = "1"

from aquatts import TTSInferencer

tts = TTSInferencer(
    device="cuda",
    gpt_path="GPT_weights_v3/s1v3.ckpt",
    sovits_path="SoVITS_weights_v3/your_model.pth",
    cuda_graph_preset="full",  # "full", "minimal", "lazy", or "off"
)

# Streaming generation — yields (sample_rate, audio_chunk, text) tuples
for sr, chunk, text in tts.infer_stream(
    text="こんにちは、世界！",
    ref_audio_path="reference audio/ref_audio.wav",
    prompt_text="こんにちは。今日はいい天気ですね。",
    text_language="日文",
    prompt_language="日文",
    preset="fast",  # "fast", "balanced", or "quality"
):
    # chunk is float32 numpy array at `sr` Hz
    # text is the text segment being spoken
    pass

See examples/basic_usage.py and examples/streaming_inference.py for runnable examples.

Presets

Two layers of presets control quality/speed trade-offs:

Generation presets (per-request, via infer_stream(preset=...)):

Preset	Speed	Sample Steps	Top-K	Temperature
`fast`	1.3x	4	3	0.6
`balanced`	1.1x	4	5	0.6
`quality`	1.0x	16	8	0.8

CUDA Graph presets (system-level, via TTSInferencer(cuda_graph_preset=...)):

Preset	Pre-capture	Buckets	Description
`full`	Yes	128, 256, 448, 512, 768, 1024	All lengths covered
`minimal`	Yes	256, 512, 1024	Common lengths only
`lazy`	No	on-the-fly	Lower memory, slower TTFP
`off`	Disabled	none	Static KV only, no graphs

Adaptive FlashAttention2 T2S path (preferred automatically when available):

Aqua-TTS can replace the q_len=1 T2S static-KV attention step with flash_attn_with_kvcache. The valid mode attends over the true KV length rather than the full zero-padded bucket and is now the default whenever a compatible FlashAttention2 installation can be imported. If FA2 is absent or a kernel rejects the active shape/device, Aqua falls back to SDPA.

No environment variable is required. Override the automatic choice when needed:

export AQUATTS_T2S_FLASH_ATTN=0  # force SDPA
# export AQUATTS_T2S_FLASH_ATTN=1  # explicitly request FA2
export AQUATTS_T2S_FLASH_ATTN_MODE=valid  # valid | bucket

or from Python with use_flash_attn=False / True:

tts = TTSInferencer(..., use_flash_attn=True, flash_attn_mode="valid")

The old June 2026 guidance that FA2 had no short-case benefit and only about 8% long-case benefit was measured before CUDA Graph replay synchronization became diagnostic-only, so it is no longer the current performance conclusion.

Deterministic A/B after removing the per-token replay synchronization (RTX 4070 Ti SUPER, PyTorch 2.5.1+cu124, flash-attn 2.7.0.post2, 15 warmups, seven synchronized repeats):

Case	SDPA fallback	Default FA2 (`valid`)	Directional gain
T2S short / bucket 448	490.0 it/s	568.5 it/s	~16%
T2S conversation / bucket 512	519.3 it/s	627.4 it/s	~21%
T2S long / bucket 768	476.9 it/s	644.9 it/s	~35%

The shared device-wide synchronization previously hid part of the attention kernel difference. With one EOS synchronization per step, FA2's valid-length KV reads are much more visible, especially at bucket 768. Treat the percentages as hardware-specific and reproduce them on the deployment GPU before changing the automatic policy or requiring bit-for-bit continuity with the SDPA path.

from aquatts import apply_preset, list_presets

print(list_presets())  # ["balanced", "fast", "quality"]
params = apply_preset("fast", overrides={"top_k": 5})

HTTP Server

Start a lightweight inference server:

python -m aquatts.server \
    --gpt-model GPT_weights_v3/s1v3.ckpt \
    --sovits-model SoVITS_weights_v3/model.pth \
    --cuda-graph-preset full \
    --host 127.0.0.1 --port 8000

# With authentication (required when binding to a non-loopback address)
python -m aquatts.server ... --host 0.0.0.0 --api-key mysecrettoken
# or: export AQUA_API_KEY=mysecrettoken

Endpoints:

Method	Path	Description
`GET`	`/health`	Model load status
`GET`	`/presets`	List available presets
`POST`	`/tts`	Streaming TTS (float32 PCM chunks)
`POST`	`/tts/file`	One-shot TTS (downloadable .wav)
`GET`	`/voices`	List registered voices
`POST`	`/voices/add`	Register a new voice
`DELETE`	`/voices/{name}`	Remove a registered voice

# Streaming TTS — returns raw float32 PCM (24kHz, mono, little-endian)
curl -X POST "http://127.0.0.1:8000/tts?text=Hello&voice=alice" --output - \
  | play -t raw -r 24k -e floating-point -b 32 -c 1 -

# Download WAV file
curl -X POST "http://127.0.0.1:8000/tts/file?text=Hello&voice=alice" -o output.wav

Voice Registry

Manage multiple characters/voices without repeating paths:

from aquatts import Voice, VoiceRegistry

registry = VoiceRegistry(json_path="./voices.json")

registry.add(Voice(
    name="alice",
    ref_audio_path="./voices/alice_ref.wav",
    prompt_text="こんにちは。今日はいい天気ですね。",
    prompt_language="日文",
))

voice = registry.get("alice")
for sr, chunk, text in tts.infer_stream(
    text="Hello world",
    ref_audio_path=voice.ref_audio_path,
    prompt_text=voice.prompt_text,
    prompt_language=voice.prompt_language,
):
    pass

On the HTTP server, pass voice instead of ref_audio_path:

curl -X POST "http://127.0.0.1:8000/tts?text=Hello&voice=alice"

For production deployments, pass an explicit registry path:

python -m aquatts.server ... --voice-registry /data/voices.json
# or
export AQUA_VOICE_JSON=/data/voices.json

Configuration

Env variable	Default	Description
`GPT_SOVITS_HOME`	(required)	Path to GPT-SoVITS repo root
`BIGVGAN_CACHE_ROOT`	package cache	Optional writable/product-owned compiled extension cache root
`AQUA_API_KEY`	(unset)	Bearer token for all server endpoints; unset = no auth
`AQUA_VOICE_JSON`	`./voices.json`	Path to voice registry JSON file. Always set this — default is relative to process CWD and will be lost on directory change
`AQUA_SESSION_CACHE_MAX`	`8`	Max number of cached reference audio sessions
`ENABLE_CUDA_GRAPH`	`1`	Enable CUDA Graph replay
`ENABLE_CUDA_GRAPH_PRECAPTURE`	`1`	Pre-capture all bucket graphs at startup
`AQUATTS_T2S_FLASH_ATTN`	`auto` / unset	`0` forces SDPA; `1` explicitly requests FlashAttention2; `auto`, empty, or unset prefers FA2 when importable
`AQUATTS_T2S_FLASH_ATTN_MODE`	`valid`	FlashAttention mode: `valid` uses true KV length; `bucket` preserves zero-padded bucket length
`TTS_OUTPUT_LANGUAGE`	`日文`	Default output language. Change to `中文` or `英文` if not using Japanese
`TTS_REF_TEXT_JA`	`こんにちは。今日はいい天気ですね。`	Default Japanese reference text
`TTS_REF_TEXT_EN`	(empty)	Default English reference text
`TTS_STREAM_SYNC_TIMING`	`0`	Enable per-step CFM timing (adds GPU sync overhead)

Benchmarks

# T2S comparison (official vs official+CUDA Graph vs Aqua-TTS)
# Replace with your own GPT checkpoint (s1v3.ckpt or a self-trained .ckpt)
python benchmarks/t2s_comparison_bench.py \
  --upstream-home /path/to/GPT-SoVITS \
  --gpt-model /path/to/xxx-e15.ckpt \
  --flash-ab

# TTFP benchmark (streaming end-to-end)
python benchmarks/aqua_ttfp.py \
    --gpt-model GPT_weights_v3/xxx-e15.ckpt \
    --sovits-model SoVITS_weights_v3/xxx_e2_s174_l32.pth \
    --ref-audio "reference audio/ref_audio.wav" \
    --ref-text "transcript of reference audio"

# BigVGAN raw kernel timing
python benchmarks/bigvgan_raw_bench.py

See benchmarks/README.md for full methodology and results.

Speaker Demo

pip install -e ".[playback]"
python examples/play_ete.py --gpt-sovits-home /path/to/GPT-SoVITS-v3lora

The demo plays three Kurisu-style Japanese utterances (short, medium, long) through PyAudio and prints TTFP plus live T2S throughput for each scripted line. Pass --show-total to also print audio duration, wall time, and RTF. Playback demos default to the low-latency live profile (--top-p 1 --speed 1.1 --sample-steps 4 --how-to-cut 按标点符号切) with queue-based playback, chunk merging, short fades, and padding to reduce chunk-boundary artifacts. To inspect whole-utterance T2S throughput without punctuation splitting, pass --how-to-cut 不切.

For recording an interactive demo, load the voice once and type any Japanese text:

python examples/live_talk.py --gpt-sovits-home /path/to/GPT-SoVITS-v3lora

Acknowledgements

Aqua-TTS was inspired by GENIE-TTS, which demonstrated that a focused, self-contained inference runtime could meaningfully close the latency gap in GPT-SoVITS. That framing — optimise the runtime, not the model — shaped the direction of this project.

License

MIT — see LICENSE.

Third-party code:

GPT-SoVITS: supplied as a separate upstream checkout and consumed under its own MIT license; Aqua does not redistribute its T2S model source.
NVIDIA BigVGAN: CUDA kernel sources under Apache 2.0 — see NOTICE.
alias-free-torch: aquatts/bigvgan/torch/ adapted under Apache 2.0 — see NOTICE.

Development

git clone https://github.com/Lucas1479/Aqua-TTS.git
cd Aqua-TTS
pip install -e ".[runtime]"
pip install -r requirements-dev.txt

export GPT_SOVITS_HOME=/path/to/GPT-SoVITS
python -m pytest tests/ -v

See CONTRIBUTING.md for contribution guidelines and CHANGELOG.md for release history. Release maintainers should follow PUBLISHING.md.

Navigation Menu

Repository files navigation

🌊 Aqua-TTS: GPT-SoVITS Low-Latency Inference Runtime on GPU

Highlights

Features

Supported Languages

How it works

Requirements

Installation

1. Install GPT-SoVITS

2. Install PyTorch

3. Install Aqua-TTS

4. Configure GPT-SoVITS path

5. Download pretrained models

6. Prepare model weights

Quick sanity check

Usage

Python API

Presets

HTTP Server

Voice Registry

Configuration

Benchmarks

Speaker Demo

Acknowledgements

License

Development

About

Releases

Packages

Contributors

Languages

Name		Name	Last commit message	Last commit date
.github/workflows		.github/workflows
aquatts		aquatts
assets		assets
benchmarks		benchmarks
examples		examples
tests		tests
tools		tools
.gitignore		.gitignore
Aqua_tts_e2e_demo.gif		Aqua_tts_e2e_demo.gif
Aqua_tts_e2e_demo.mp4		Aqua_tts_e2e_demo.mp4
CHANGELOG.md		CHANGELOG.md
CONTRIBUTING.md		CONTRIBUTING.md
LICENSE		LICENSE
MANIFEST.in		MANIFEST.in
NOTICE		NOTICE
PUBLISHING.md		PUBLISHING.md
README.md		README.md
README.zh.md		README.zh.md
TECHNICAL.md		TECHNICAL.md
TEST_REPORT.md		TEST_REPORT.md
pyproject.toml		pyproject.toml
requirements-dev.txt		requirements-dev.txt
requirements.txt		requirements.txt

Latest commit

History

Folders and files

Repository files navigation

🌊 Aqua-TTS: GPT-SoVITS Low-Latency Inference Runtime on GPU

Highlights

Features

Supported Languages

How it works

Requirements

Installation

1. Install GPT-SoVITS

2. Install PyTorch

3. Install Aqua-TTS

4. Configure GPT-SoVITS path

5. Download pretrained models

6. Prepare model weights

Quick sanity check

Usage

Python API

Presets

HTTP Server

Voice Registry

Configuration

Benchmarks

Speaker Demo

Acknowledgements

License

Development

About

Resources

Contributing

Stars

Watchers

Forks

Releases

Packages

Contributors

Languages
