CARLA Data Collection

A professional, extensible framework for generating and collecting scenario data from the CARLA autonomous driving simulator.
Developed for my supervisor's dataset during my internship at Google DeepMind Research, University of York.

---

Table of Contents

• Features
• Quick Start
• Requirements
• Setup
• Usage
• Example Output
• Download Initial Dataset
• Notes
• Contact
• Contributing
• Code Structure
• Example Scenario YAML
• Changelog
• License
• VS Code Dev Container

---

Features

• Scenario Generation: Easily generate diverse driving scenarios with customizable weather, traffic, and obstructions.
• YAML Configuration: All scenario parameters are defined in human-readable YAML files.
• Automated Data Logging: Collects sensor, vehicle, and environment data for each run.
• Traffic & Weather Simulation: Supports dynamic traffic and weather conditions.
• Unique Output Management: Automatically creates unique output directories for each run.
• Extensive Testing: Includes pytest-based unit tests for all major functions.
• Professional Documentation: Sphinx-generated API docs and usage guides.

---

Structure of the repository

File Structure:

• carla_data_collection/newscenariogenerator.py — Scenario YAML generator

• carla_data_collection/runscenariofromyaml.py — Scenario runner

• configs/ — Example scenario YAMLs

• data/ — Output data and logs

• tests/ — Unit tests for all major functions

• docs/ or _build/html/ — Sphinx-generated documentation

• .devcontainer/devcontainer.json — VS Code Dev Container config


---

Quick Start

1. Clone the repository:

   git clone https://github.com/yourusername/carla-data-collection.git
   cd carla-data-collection

2. Install Python dependencies:

   pip install -r requirements.txt

3. (Optional) Download the initial dataset: See Download Initial Dataset.

4. Run the CARLA server (see Setup).

5. Generate scenarios:

   python3 carla_data_collection/newscenariogenerator.py

6. Run a scenario:

   python3 carla_data_collection/runscenariofromyaml.py configs/example_scenario.yaml --data_collection

---

Requirements

• Python 3.7+
• CARLA simulator 0.9.10
• Python dependencies: carla, numpy, opencv-python, pyyaml, orjson, pygame

Install Python packages with:

pip install -r requirements.txt

---

Setup

Set up CARLA with Docker on Ubuntu 22.04+. This setup uses a packaged build inside a Docker container with NVIDIA support.

Prerequisites

• Ubuntu 22.04+, tested on Ubuntu 24.04
• Docker
• NVIDIA GPU with drivers installed
• Unreal Engine 4.x (from source, e.g. UE_4.26)

Configuration

Edit and export these paths based on your environment:

export UE4_ROOT=/home/your_user/UnrealEngine_4.26   # Path to your Unreal Engine build
export CARLA_DIR=$HOME/carla                        # Path where CARLA will be cloned

---

1. Install Docker and NVIDIA Container Toolkit

sudo apt update
sudo apt install -y docker.io curl git

distribution=$(. /etc/os-release;echo $ID$VERSION_ID)
curl -s -L https://nvidia.github.io/nvidia-docker/gpgkey | sudo apt-key add -
curl -s -L https://nvidia.github.io/nvidia-docker/$distribution/nvidia-docker.list \
  | sudo tee /etc/apt/sources.list.d/nvidia-docker.list
sudo apt update
sudo apt install -y nvidia-docker2
sudo systemctl restart docker

# Allow Docker GUI access (for CarlaUE4Editor)
xhost +local:docker || true

---

2. Clone the CARLA Repository

git clone -b dev https://github.com/carla-simulator/carla.git "$CARLA_DIR"

---

3. Export Unreal Engine Path

export UE4_ROOT=/home/your_user/UnrealEngine_4.26

---

4. Build CARLA Inside Docker

Run the CARLA container:

cd "$CARLA_DIR"
./Scripts/run_container.sh

Once inside the container, run the following:

cd /workspaces/carla
./Update.sh
make PythonAPI
make CarlaUE4Editor
make build.utils
make package

Packaged build will be available in:

/workspaces/carla/Dist/

---

Run CARLA

I used Visual Studio's Dev container and loaded the main carla folder after:

nano .devcontainer/devcontainer.json

Then I used this:

{
  "name": "CARLA UE4 Dev (jammy)",
  "image": "carla-ue4-jammy-dev",
  "updateRemoteUserUID": false,
  "customizations": {
    "vscode": {
      "settings": {
        "terminal.integrated.shell.linux": "bash"
      },
      "extensions": [
        "ms-vscode.cpptools"
      ]
    }
  },
  "postStartCommand": "bash",
  "runArgs": [
    "--rm",
    "--name", "carla-ue4-jammy-devcontainer",
    "--hostname", "carla-devcontainer",
    "--env", "DISPLAY=${localEnv:DISPLAY}",
    "--volume", "/tmp/.X11-unix:/tmp/.X11-unix",
    "--volume", "/usr/share/vulkan/icd.d/nvidia_icd.json:/usr/share/vulkan/icd.d/nvidia_icd.json",
    "--volume", "${localEnv:UE4_ROOT}:/opt/UE4.26",
    "--gpus", "all",
    "-p", "2000:2000"
  ]
}

Start the packaged CARLA server:

./Dist/CARLA_Shipping_*/LinuxNoEditor/CarlaUE4.sh

Or run headlessly with epic quality:

./CarlaUE4.sh -RenderOffScreen -quality-level=Epic

---

Python Client Setup

Clone this repository in carla/PythonAPI. Then while in the workspace:

sudo apt update
sudo apt install python3-pip -y
pip3 install pyyaml numpy orjson opencv-python pygame

---

Usage

Running a Scenario from YAML

python3 carla_data_collection/runscenariofromyaml.py configs/example_scenario.yaml --data_collection

Generating a set of scenarios

python3 carla_data_collection/newscenariogenerator.py

---

Example Output

After running a scenario, you will find output data (JSON logs, images) in a uniquely named directory under data/.
Example:

data/
  scenario_20250811_1530/
    frame_00001.json.gz
    frame_00002.json.gz
    ...
    ...
    config.yaml

---

Download Initial Dataset

You can download the zipped dataset, configs and data, (~50GB, unzipped ~500GB) from the following link:
https://drive.google.com/file/d/1SQbpy4k_7yYwmBDxhFngg4_YWA4a26Hn/view?usp=sharing

Once downloaded, extract it in the root of the project:

tar -xvzf initialdataset.tar.gz

---

Notes

• Ensure CARLA server is running on localhost port 2000 before running scripts.
• Output data and images will be saved in uniquely named output directories under the configured output folder.
• Modify the YAML configs in configs/ to customize weather, traffic, sensors, and other settings.

---

Contact

I'll be active on the email: [email protected] till 22nd August

---

Contributing

• Please use Black for code formatting.
• Add type hints and docstrings to all new functions.
• Use the logging module instead of print statements.
• Submit pull requests with clear descriptions.

---

Code Structure

• carla_data_collection/newscenariogenerator.py — Generates scenario YAMLs and launches runs.
• carla_data_collection/runscenariofromyaml.py — Runs a scenario from a YAML config.
• configs/ — Example scenario YAMLs.
• data/ — Output data and logs.
• tests/ — Unit tests for all major functions.
• docs/ or _build/html/ — Sphinx-generated documentation.

---

Example Scenario YAML

weather:
  rain: 20.0
  fog: 10.0
  cloudiness: 50.0
  sun_altitude_angle: 45.0
  sun_azimuth_angle: 90.0
traffic:
  traffic_needed: true
  use_sumo: false
  number_of_vehicles: 5
sensors:
  lane_distance: 2.0
  vehicle_distance_radius: 50.0
obstructions:
  enabled: false
  tile_percentage: 0
output_dir: data/example_run
max_frames: 100

---

Changelog

See CHANGELOG.md for version history and updates.

---

License

This project is licensed under the MIT License.
