Mixed Precision Quantization in Graph Neural Networks (MixQ-GNN)

---

This is the official repository for the paper "Efficient Mixed Precision Quantization in Graph Neural Networks".

Getting Started

1. Clone or download the repository.

   git clone https://github.com/SamirMoustafa/MixQ.git
   cd MixQ


2. To get started with the project, there are two ways:
   • Use the provided Docker image.

   docker build -t mixq .
   docker run --gpus all --rm -ti --ipc=host --name mixq_instance mixq /bin/bash

   • Or, install the required dependencies manually through anaconda.

   conda create -n mixq python=3.11.5
   conda activate mixq
   # Install PyTorch depending on the current machine setup.
   pip install numpy==1.26.4
   command -v nvidia-smi > /dev/null && conda install pytorch==2.2.1 torchvision==0.17.1 pytorch-cuda=12.1 -c pytorch -c nvidia || conda install pytorch==2.2.1 torchvision==0.17.1 torchaudio==2.2.1 cpuonly -c pytorch
   # Install PyG dependencies based on the current PyTorch setup
   pip install pyg_lib torch_scatter torch_sparse torch_cluster torch_spline_conv -f $(python -c "import torch; print('https://data.pyg.org/whl/torch-2.2.1+cu121.html' if torch.cuda.is_available() else 'https://data.pyg.org/whl/torch-2.2.1+cpu.html')")
   export PYTHONPATH="${PYTHONPATH}:./"
   pip install -r requirements.txt

3. (Optional) Verify the installation by running the following command:

   python -m unittest discover ./test

4. (Optional) Verify Quantized Message Passing Schema theorem only for GCN and GIN examples by running the following commands:

   cd test/
   export PYTHONPATH="${PYTHONPATH}:../"
   python -m unittest ./test_graph_conv_module.py
   python -m unittest ./test_graph_iso_module.py

Logs Directories of the Experiments

./
├── tasks_per_node/
│   ├── planetoid/
│   │   ├── explore_all_logs/
│   │   │   └── Cora/ (📈📉 Figure 2 and Figure 3)
│   │   ├── ablation_study/
│   │   │   ├── CiteSeer/ (📈📉 Figure 16)
│   │   │   ├── Cora/ (📈📉 Figure 6)
│   │   │   └── PubMed/ (📈📉 Figure 17)
│   │   ├── experimental_plus_DQ_logs/
│   │   │   ├── CiteSeer/ (📄📝 Table 6)
│   │   │   ├── Cora/ (📄📝 Table 2)
│   │   │   └── PubMed/ (📄📝 Table 6)
│   │   └── experimental_logs/
│   │       ├── CiteSeer/ (📄📝 Table 1 and Table 4)
│   │       ├── Cora/ (📄📝 Table 1 and Table 4)
│   │       └── PubMed/ (📄📝 Table 1 and Table 4)
│   └── ogbn/
│       └── experimental_logs/
│           └── ogbn-arxiv/ (📄📝 Table 1)
├── tasks_per_graph/
│   ├── synthetic/
│   │   └── logs/ (📄📝 Table 8)
│   └── tudataset/
│       ├── a2q_logs/ (📄📝 A^2Q results for TUDataset in Table 3 and Table 7)
│       ├── dq_logs/ (📄📝 DQ results for TUDataset in Table 3 and Table 7)
│       └── logs/ (📄📝 MixQ results for TUDataset in Table 3 and Table 7)
├── examples/
│   └── logs/ (📄📝 FP32 results for TUDataset in Table 3)
└── hardware_speedup/
    ├── bitBLAS_layout_nt_NVIDIA_A100_80GB_PCIe.csv (📈📉 Figure 14)
    ├── message_passing_speedup_AMD_EPYC_9534.csv (📈📉 Figure 13(b) and Figure 15)
    ├── message_passing_speedup_AppleM1-8-CoreGPU.csv (📈📉 Figure 13(c) and Figure 15)
    └── message_passing_speedup_IntelXeon-GoogleColabTPUv2.csv (📈📉 Figure 13(a) and Figure 15)

Citation

@inproceedings{Moustafa2025EfficientMP,
    author={Samir Moustafa and Nils M. Kriege and Wilfried N. Gansterer},
    booktitle = { 2025 IEEE 41st International Conference on Data Engineering (ICDE) },
    title = {{ Efficient Mixed Precision Quantization in Graph Neural Networks }},
    year = {2025},
    ISSN = {2375-026X},
    pages = {4038-4052},
    doi = {10.1109/ICDE65448.2025.00301},
    url = {https://doi.ieeecomputersociety.org/10.1109/ICDE65448.2025.00301},
    publisher = {IEEE Computer Society}
}
