Fully open source configurable high speed CoreXY 3D printer. Inspired by HevORT, Voron, Annex Engineering and EVA2 design.
- Does not require any custom-machined parts or custom-cut panels.
- Can be selected one of the follwing kinematics.
- Standard : Traditional corexy kinematic.
- 4PR : High-performance machine with automatic squaring gantry capacity. This configuration uses custom Extended CoreXY kinematic (Mixed cartesian and corexy).
- IDEX : Hybrid corexy IDEX.
- CoreXY, IDEX, and Extended-CoreXY kinematics.
- Designed to last, parts under stress are embedded with long bolts to handle the load.
- And our industry-leading SnakeOil technology :3
- Add IDEX variant(by Charles)
- Add 4PR variant with new Extended CoreXY kinematic
- Add klicky probe support(by Charles)
- New bed coupling kinematic using silicon spacers
- Add side-blower aux fan module
- Add EBB can toolhead board support
- Remove outdated components
- Merge toolhead design(1515 and 2020 gantry now use the same toolhead front/back/bottom design) and some small improvements on geometry
| Feature | Credit/Inspiration by/Description |
|---|---|
| Selectable kinematic : CoreXY, Hibryd-CoreXY | Added on beta3 release |
| Selectable single or dual toolhead | Added on beta3 release |
| 3 Point auto bed tramming | HevORT, Wobble ring |
| Belted Z | Lulz bot, Voron |
| Din mounter | Voron |
| Cross belt corexy belt path | HevORT |
| Eva compatible toolhead | EVA |
| Filament spoll in side chamber | - |
| Quick release panels | Added on beta2 release |
| Built-in chamber air filter | Added on beta1 release |
| Auto build sheet detect and profile loader | Work in progress |
| AIO filament runout + jam detector + width sensor | Work in progress |
| Modular sensor add-on system | Work in progress |
| Probe(bed mesh) on print area only | Added on beta2 using klipper macro |
| Screwless belt mounter | VzBot |
| Bed fan | Qholia |
- Measure result provided by 株式会社グーテンベルク
- PLA, 0.4mm nozzle, sliced with Cura 4.12.1 using "CoreXY FAST" profile.
| Bed coupling | SpeedBoatRace | Slow benchy | |
|---|---|---|---|
| Video |
 |
 |
 |
| Hardware version | beta1 | beta2 | beta2 |
Both machines are practicaly identical, only difference is the build volume.
- Sherpa mini extruder is an original work of Annex Engineering, modified parts using their source code/design files are re-released under ANNEX Engineering License.
- EVA2 is an original work of EVA-3D, modified parts using their source code/design files are re-released under GNU General Public License v3.0
- This printer design(SnakeOil XY), it's document and software are released under GNU General Public License v3.0
