Automated Sign Language Tutor Project

This is the official repository for the paper "Automated Sign Language Tutor: A Dual-Language Real-Time Approach for RSL and ASL".

Appearance and video of the stand operation:

Important Note: This repository contains a backend system for sign language recognition (Streaming Sign Recognition Engine and Controller Process components). The provided frontend (ws.html, ws.css, ws.js) serves as a basic example implementation to demonstrate backend functionality and is not a production-ready application. Developers should create their own frontend implementations tailored to specific use cases while using this backend as a recognition service.

It is also possible to use the backend with custom models.

Key Features

1. Two operating modes:
   • LIVE: Real-time gesture recognition
   • Training: Mode for teaching the model new gestures
2. Dual language support: Russian and English interface and recognition models
3. WebSocket interaction: Client sends video stream, server returns recognized gestures
4. Visual feedback: Notification system for users
5. Responsive interface: Modern design, user-friendly

Setup and Installation

Prerequisites

• Python 3.7+
• Node.js (optional for frontend)
• Web camera

Installing Dependencies

pip install -r requirements.txt

Models Downloading

Download the models

• https://rndml-team-cv.obs.ru-moscow-1.hc.sbercloud.ru/rsl/demostand_models/tsm/ru/mobilenet_demostand_ru.onnx
• https://rndml-team-cv.obs.ru-moscow-1.hc.sbercloud.ru/rsl/demostand_models/tsm/en/mobilenet_demostand_en.onnx

and place them in the folder models/checkpoints/.

Running the Server

python server_fapi.py

The server will run at localhost:3003.

Docker Deployment

docker build -t sign-tutor .
docker run -it -d -v $PWD:/app -p 3003:3003 sign-tutor

Using the Web Interface

1. Open ws.html in your browser
2. Click "Enable Camera" to access your webcam
3. After enabling the camera, the "Start Stream" button will become available
4. Select operating mode:
   • LIVE: Real-time gesture recognition
   • Training:
     • Enter gesture name in the text field
     • Click "Select Gesture"
     • Perform the gesture in front of the camera
     • The system will notify you when the gesture is recognized correctly
5. Switching interface and model language: Use the RU/EN buttons in the top right corner
6. The recognition result is displayed in the server console.

Working with custom models

1. Place ONNX models for Russian and English in the models/checkpoints/ folder

2. Update the configuration files:

• models/config_ru.yaml for the Russian model,
• models/config_en.yaml for the English model.

Use the available files as examples.

3. Update the sign class files:

• models/constants_ru.py with the `classes' variable for Russian,
  • models/constants_en.py with the `classes' variable for English.

Use the available files as examples.

System Architecture

Client-Server Interaction

1. Establishing connection:

   • Client opens WebSocket connection to ws://localhost:3003/
   • Server initializes the default language model (Russian)

2. Main workflow:

sequenceDiagram
    participant Client
    participant Server
    participant Model

    Client->>Server: {"type": "LANGUAGE", "lang": "ru"}
    Server->>Model: Initialize Russian model
    Model-->>Server: Model ready
    Server-->>Client: {"status": 200, "message": "Language changed to ru"}

    Client->>Server: {"type": "MODE", "mode": "TRAINING"}
    Server-->>Client: {"status": 200, "message": "New MODE TRAINING set correctly"}

    Client->>Server: {"type": "GLOSS", "gloss": "привет"}
    Server-->>Client: {"status": 200, "message": "New GLOSS привет set correctly"}

    loop Each frame (30 FPS)
        Server->>Model: Process frame
        Model-->>Server: Recognition result
        alt Gesture recognized
            Server-->>Client: {"text": "привет", "type": "WORD"}
        end
    end

Loading

Key Components

Client (Frontend):

• view/ws.html: Main HTML interface file
• view/ws.css: Interface styles
• view/ws.js: Camera and WebSocket logic

Server (Backend):

• server_fapi.py: Main server code (FastAPI)
• models/model.py: Recognition model logic
• Runner: Class for managing video processing flow
• RecognitionMP: Process for gesture recognition in a separate thread

Model:

• ONNX models for gesture recognition
• Configuration files for Russian and English versions
• Gesture class files for each language

Implementation Details

Client-Side

1. Camera management:

   • Webcam access via WebRTC
   • Frame capture and base64 encoding
   • Frame sending at specified frequency (30 FPS)

2. Mode management:

   • Smooth switching between LIVE and Training modes
   • Dynamic UI element display based on current mode

3. Localization:

   • Full support for Russian and English
   • Language preference persistence between sessions

4. Feedback:

   • Animated notification system
   • Visual confirmation of user actions
   • Error handling and display

Server-Side

1. Video processing:

   • Base64 decoding to OpenCV image
   • Frame preprocessing for neural network
   • Frame buffering for sequence analysis

2. Model management:

   • Dynamic model loading for different languages
   • Multithreaded processing to minimize latency
   • Proper resource cleanup when switching languages

3. Gesture recognition:

   • Sequence analysis for gesture recognition
   • Threshold filtering to reduce false positives

Configuration and Customization

Changing Parameters

1. Frame rate: Change the FPS value in ws.js
2. Video resolution: Change width and height attributes of the <video> element in ws.html
3. Recognition threshold: Change the threshold value in model configuration files

Adding New Languages

1. Create a new configuration file models/config_<language>.yaml
2. Add a gesture class file models/constants_<language>.py
3. Update translation dictionaries in ws.js:

const translations = {
    // ...
    <language>: {
        title: "...",
        startWebcam: "...",
        // ... other texts
    }
}

Troubleshooting

Common Issues

1. Camera not working:

   • Check browser permissions
   • Ensure no other applications are using the camera
   • Try reloading the page

2. No connection to server:

   • Ensure the server is running (python server_fapi.py)
   • Check WebSocket address in ws.js
   • Ensure no firewall blocking

3. Model not loading:

   • Check model paths in configuration files
   • Ensure model files exist
   • Verify content of gesture class files

Logging

1. Client: Open browser developer console (F12)
2. Server: Logs are printed in the server console

Authors

— Petr Surovtsev
— Alexander Nagaev
— Alexander Kapitanov
— Ilya Ovodov

License

This project is licensed under the APACHE License. See the LICENSE file for details.

For questions and suggestions, please use the project's Issues section.
