| Count | Part |
|---|---|
| 1 | ATmega32A 40 pin DIP (32L works too) |
| 1 | 40 pin DIP socket (optional but highly recommended) |
| 1 | USB4085-GF-A USB Type-C socket |
| 1 | 500 mA polyfuse |
| 2 | 6mm momentary push buttons |
| 1 | 16 MHz quarz crystal |
| 1 | 4.7 uF electrolytic capacitor |
| 2 | 100 nF ceramic disk capacitor |
| 2 | 22 pF ceramic disk capacitor |
| 1 | 10 kΩ resistor |
| 2 | 68 Ω resistor |
| 1 | 1.5 kΩ resistor |
| 2 | 5.1 kΩ resistor |
| 2 | 3.6 V zener diode (DO-35 BZX55C3V6) |
| 66 | universal switching diode (DO-35 1N4148) |
