Dynamic AI-Generated Software Flows

Transform natural language into executable software workflows

A Next.js application that demonstrates dynamic AI-generated software flows using XState state machines. This project showcases how AI can dynamically assemble software from task lists and execute them as state machines, applying dynamic programming principles to LLM reasoning tasks.

Table of Contents

• Overview
• Video Demo
• Features
• Getting Started
  • Prerequisites
  • Installation
  • Configuration
  • Running the Application
• Architecture
  • Core Components
  • AI Provider Integration
  • State Machine System
• How It Works
• Recent Enhancements
• API Documentation
• Contributing
• Development Status
• License

Overview

X-Reason is an innovative prototype that demonstrates how AI can dynamically assemble and execute software workflows. By converting AI-generated task lists into executable XState machines, it enables non-technical users to compose software through natural language descriptions.

Migration Notes

Recent architectural changes (as of v0.3.0):

Gateway-Only Authentication (NEW!)

• Unified Access: Now uses Vercel AI Gateway for all AI providers
• Single API Key: AI_GATEWAY_API_KEY replaces provider-specific keys
• Cost Control: Built-in rate limiting and usage monitoring
• Deprecated Keys: OPENAI_API_KEY, GOOGLE_GENERATIVE_AI_API_KEY, XAI_API_KEY no longer supported

Provider Consolidation

• Unified AI SDK: All AI provider interactions now use Vercel AI SDK (ai, @ai-sdk/openai, @ai-sdk/google)
• Three Providers: OpenAI, Google Gemini, and X.AI (Grok) supported
• Removed Routes: Legacy /api/openai/ and /api/gemini/ directories have been deleted
• New Endpoint: Use unified /api/ai/chat for all AI interactions
• Centralized Config: All provider setup in apps/x-reason-web/src/app/api/ai/providers.ts

Action Items for Existing Contributors

1. Remove old keys from .env.local: OPENAI_API_KEY, GOOGLE_GENERATIVE_AI_API_KEY
2. Add Gateway key: AI_GATEWAY_API_KEY=your_gateway_key_here
3. Clear browser localStorage to remove old client-side credentials
4. Update any custom integrations to use /api/ai/chat instead of legacy provider-specific routes
5. Run pnpm install to ensure Vercel AI SDK dependencies are installed

See AI_SDK_VERIFICATION.md for detailed migration instructions.

For detailed technical documentation, see:

• AGENTS.md - Updated agent interaction patterns
• apps/x-reason-web/src/app/api/reasoning/README.md - Reasoning engine documentation

Video Demo

Features

• Dynamic State Machine Generation: Convert AI-generated task lists into executable XState machines
• Multi-AI Provider Support: Seamlessly switch between OpenAI, Google Gemini, and X.AI (Grok)
• Real-time Streaming: Server-sent events for live AI response streaming
• Domain-Specific Workflows: Pre-built demos for chemical engineering (Chemli) and user registration (Regie)
• Modern UI: Tailwind CSS with shadcn/ui components for a clean, responsive interface
• Human-in-the-Loop: Support for pause/resume execution with user interaction
• Persistent Context: Maintain state across execution steps
• Visual Debugging: State machine visualizer for understanding workflow execution

Getting Started

Prerequisites

• Node.js 18+
• pnpm (recommended) or npm
• Vercel AI Gateway API key (recommended for unified access to all providers)
  • Get your key from: Vercel AI Gateway

Installation

1. Clone the repository:

git clone https://github.com/yourusername/x-reason.git
cd x-reason

2. Install dependencies:

pnpm install
# or
npm install

Configuration

Create a .env.local file in the apps/x-reason-web/ directory:

# Vercel AI Gateway Configuration (REQUIRED)
# Get your key from: https://vercel.com/docs/ai-gateway
AI_GATEWAY_API_KEY=your_gateway_api_key_here

# Optional: Custom Gateway Base URL
# AI_GATEWAY_BASE_URL=https://your-custom-gateway.vercel.app

Gateway Benefits:

• Single API key for OpenAI, Google Gemini, and X.AI
• Built-in rate limiting and cost monitoring
• Simplified credential management
• Server-side only (no client-side exposure)

See AI_SDK_VERIFICATION.md for verification steps and troubleshooting.

Running the Application

Start the development server:

pnpm run dev
# or
npm run dev

Open http://localhost:3000 in your browser.

Other available commands:

# Build for production
pnpm run build

# Run production server
pnpm start

# Run tests
pnpm test

# Lint code
pnpm run lint

Architecture

Core Components

1. State Machine Macro System (src/app/actions/statesMacros.ts)

   • Converts task maps to XState configurations
   • Supports pause/resume execution
   • Maintains context across execution steps
   • Enables real-time streaming support

2. AI Provider System (src/app/api/ai/)

   • Unified interface for multiple AI providers
   • Provider-specific adapters
   • Streaming response support
   • Automatic fallback handling

3. Domain-Specific Components

   • Chemli (src/app/components/chemli/): Chemical product engineering workflows
   • Regie (src/app/components/regie/): Dynamic user registration flows

AI Provider Integration

The application uses the Vercel AI SDK for unified multi-provider support:

• Architecture: Centralized provider configuration in src/app/api/ai/providers.ts
• Supported Providers (via Gateway):
  • OpenAI: GPT-5 Mini, GPT-5 Nano, GPT-OSS 120B, GPT-4o Mini, GPT-4.1 Nano
  • Google Gemini: Gemini 2.0 Flash, Gemini 2.5 Flash, Gemini 2.5 Flash Lite
  • X.AI (Grok): Grok 4 Fast (Non-Reasoning), Grok 4 Fast (Reasoning), Grok Code Fast 1
• Features:
  • Gateway-only authentication (AI_GATEWAY_API_KEY)
  • Streaming responses via streamText()
  • Server-side credential management
  • Runtime provider switching
  • Cost control through Gateway

All providers accessed through Vercel AI Gateway with a single API key.

State Machine System

Built on XState v5, the system provides:

• Dynamic state machine generation from task lists
• Error handling with retry mechanisms
• Context preservation across states
• Support for long-running async operations
• Human-in-the-loop interactions

How It Works

X-Reason transforms natural language descriptions into executable software flows:

1. Task Generation: AI analyzes user requirements and generates an optimized task list
2. State Machine Creation: The macro system converts tasks into XState configurations
3. Execution: The state machine executes tasks sequentially with support for:
   • User interactions
   • External system callbacks
   • Async operations (data persistence, notifications)
4. Adaptation: AI can modify flows based on context and user behavior

Example: Dynamic User Registration

The system can generate customized registration flows based on user context:

// AI analyzes user context (location, visit frequency, etc.)
// and generates an optimized task list:
[
  "Collect User Details",
  "Age Confirmation",    // Added for US/Canada users
  "Present Special Offers", // Added for frequent visitors
  "Select Plan",
  "TOS Acceptance",
  "Persist User Details",
  "Send Registration Event"
]

// The macro converts this to an executable state machine
const registrationMachine = machineMacro(taskMap);

Recent Updates

• Vercel AI SDK Integration: Migrated to unified AI SDK for all provider interactions
• Server-Side Credentials: Removed client credential prompts, all keys managed server-side
• Next.js 15: Upgraded from v14 with Turbopack support
• XState v5: Migrated from v4 with improved APIs
• Multi-AI Providers: Added Google Gemini alongside OpenAI
• Modern UI: Replaced Blueprint.js with Tailwind CSS + shadcn/ui
• Streaming: Real-time AI responses via Server-Sent Events
• Enhanced DX: Better TypeScript support and error handling

API Documentation

AI Endpoints

• POST /api/ai/chat - Unified streaming chat endpoint for all providers (powered by Vercel AI SDK)
• POST /api/reasoning/stream - Reasoning engine streaming endpoint

State Machine API

• POST /api/state-machine/create - Generate state machine from task list
• POST /api/state-machine/execute - Execute state machine with context
• GET /api/state-machine/status/:id - Get execution status

Contributing

Top Contributors @doriansmiley (Dorian Smiley) - Creator of core engine @anand-testcompare (Anand Pant) - Revamped UI/UX and expanded use cases We welcome contributions! Please see our Contributing Guide for details.

Development Status

⚠️ This is a prototype/demonstration application, not production-ready!

Expect bugs and breaking changes. The focus is on showcasing innovative AI-driven software composition patterns rather than production stability.

Known Issues

• Some TODO items remain in the codebase
• Limited error recovery in certain edge cases

License

This project is licensed under the MIT License - see the LICENSE file for details.
