visx-vue

Vue 3 visualization components, powered by visx primitives.
Low-level SVG building blocks. Composable. TypeScript-first. No opinions on styling.

Experimental — may be used in a future version of nuxt-charts.

Install - Packages - Usage - Development - Contributing - Examples

Warning

This project is currently experimental and under active development.

---

Install

Install individual packages as needed:

pnpm add @visx-vue/shape @visx-vue/scale @visx-vue/axis

Each package is standalone. Peer dependency: vue ^3.4.0.

Packages

40 packages organized by visualization concern.

Primitives

Package	Components
@visx-vue/shape	Arc, Area, AreaClosed, AreaStack, Bar, BarGroup, BarGroupHorizontal, BarRounded, BarStack, BarStackHorizontal, Circle, Line, LinePath, LineRadial, Pie, Polygon, SplitLinePath, Stack
@visx-vue/group	Group
@visx-vue/text	SVG text with word-wrap
@visx-vue/clip-path	ClipPath
@visx-vue/marker	SVG marker definitions
@visx-vue/glyph	Glyph shapes for scatterplots

Axes & Grids

Package	Components
@visx-vue/axis	Axis, AxisBottom, AxisTop, AxisLeft, AxisRight
@visx-vue/grid	Grid, GridRows, GridColumns, GridAngle, GridPolar, GridRadial

Scale

Package	Exports
@visx-vue/scale	createScale, scale operators, D3 scale wrappers
@visx-vue/curve	D3 curve presets

Chart Types

Package	Components
@visx-vue/xychart	Full XY chart system with context, hooks, themes
@visx-vue/hierarchy	Tree, Treemap, Pack, Cluster, Partition
@visx-vue/network	Graph, Nodes, Links
@visx-vue/heatmap	HeatmapRect, HeatmapCircle
@visx-vue/chord	Chord diagrams
@visx-vue/sankey	Sankey diagrams
@visx-vue/geo	Mercator, Albers, AlbersUsa, Orthographic, NaturalEarth, EqualEarth, CustomProjection, Graticule
@visx-vue/wordcloud	Wordcloud
@visx-vue/delaunay	Delaunay triangulation
@visx-vue/voronoi	Voronoi diagrams
@visx-vue/stats	Statistical charts
@visx-vue/threshold	Threshold areas

Interaction

Package	Exports
@visx-vue/tooltip	Tooltip, TooltipWithBounds, TooltipInPortal, useTooltip, useTooltipInPortal
@visx-vue/zoom	Zoom, useZoom
@visx-vue/brush	Brush, BaseBrush
@visx-vue/drag	Drag, useDrag
@visx-vue/event	Mouse/touch event utilities
@visx-vue/bounds	Element bounds composable
@visx-vue/responsive	Responsive container composable

Decoration

Package	Exports
@visx-vue/legend	Legend, Linear, Ordinal, Quantile, Size, Threshold
@visx-vue/gradient	SVG gradient definitions
@visx-vue/pattern	SVG pattern definitions
@visx-vue/annotation	Chart annotations

Utilities

Package	Exports
@visx-vue/point	Point math
@visx-vue/spring	Spring animation helpers
@visx-vue/mock-data	Sample datasets for development
@visx-vue/vendor	Vendored D3 internals

Usage

<script setup lang="ts">
import { BarStack } from '@visx-vue/shape'
import { AxisBottom, AxisLeft } from '@visx-vue/axis'
import { createScale } from '@visx-vue/scale'
import { Grid } from '@visx-vue/grid'
import { useTooltip, TooltipWithBounds } from '@visx-vue/tooltip'

const { tooltipData, tooltipLeft, tooltipTop, showTooltip, hideTooltip } = useTooltip()
</script>

<template>
  <svg
    :width="width"
    :height="height"
  >
    <Grid
      :x-scale="xScale"
      :y-scale="yScale"
      :width="innerWidth"
      :height="innerHeight"
    />
    <BarStack
      :data="data"
      :x-scale="xScale"
      :y-scale="yScale"
      :keys="keys"
      :color="colorScale"
    />
    <AxisBottom
      :scale="xScale"
      :top="innerHeight"
    />
    <AxisLeft :scale="yScale" />
  </svg>
  <TooltipWithBounds
    v-if="tooltipData"
    :top="tooltipTop"
    :left="tooltipLeft"
  >
    {{ tooltipData }}
  </TooltipWithBounds>
</template>

Development

Monorepo using pnpm + Turborepo + Vite+.

# install
pnpm install

# run demo app
pnpm dev

# build all packages
pnpm build

# test
pnpm test

# type check
pnpm typecheck

# lint + format + type check
pnpm check

Demo app lives in packages/visx-demo (Experimental).

Architecture

packages/
  visx-vue-shape/       - SVG shape primitives
  visx-vue-axis/        - Axis components
  visx-vue-scale/       - D3 scale wrappers
  visx-vue-xychart/     - Full XY chart system
  visx-vue-tooltip/     - Tooltip + portal
  visx-vue-zoom/        - Pan/zoom
  visx-vue-brush/       - Brush selection
  visx-demo/            - Interactive demo app (Experimental)
  ...

All packages: ES module + CJS dual output, full .d.ts types.

Contributing

Contributions welcome. Open an issue or PR.

• Each package is independent — changes are isolated
• Run vp check && vp test before submitting
• Follow existing component patterns (Vue 3 <script setup> + TSX for renderless logic)

License

MIT
