Angular 2 (v15) beginner tutorial.

Introduction

We will build a tic-tac-toe game in this tutorial. The game will have a board of 3x3 squares. Two players will take turns to mark a square with their symbol (either X or O). The player who succeeds in placing three of their marks in a horizontal, vertical, or diagonal row wins the game.

Install Node.js

Download and install Node.js from here.

Install Angular CLI

Open a terminal and run the following command to install Angular CLI globally.

npm install -g angular-cli

Create a new project

Create a new project using the Angular CLI.

ng new ng-beginner

We'll be prompted to answer a few questions. The answers are as follows:

? Would you like to add Angular routing? Yes
? Which stylesheet format would you like to use? SCSS   [ https://sass-lang.com/documentation/syntax#scss                ]

If you are using Visual Studio Code

Install extensions :

Angular language service
Angular 2 TypeScript Snippets
Angular console

Startup the project

Open a terminal and navigate to the project folder. Run the following command to start the project.

ng serve

Open a browser and navigate to http://localhost:4200.

Application

Create first component

Create a new component called square using the Angular CLI.

 ng generate component square --inline-template --inline-style

or

 ng g c square -t -s

This component will have its HTML template and CSS styles inside. We will use this component to display a square in the board.

A neq folder called square will be created in the src/app folder. The following files will be created:

square.component.css
square.component.html

app
├── app-routing.module.ts
├── app.component.html
├── app.component.scss
├── app.component.spec.ts
├── app.component.ts
├── app.module.ts
└── square
    ├── square.component.spec.ts
    └── square.component.ts

Add the component in the app component template.

<app-square></app-square>
<router-outlet></router-outlet>

Just as an example, we could display a random number in the square component, updated every second.

import { Component } from '@angular/core';
@Component({
  selector: 'app-square',
  template: `
    <p>
      {{ random }}
    </p>
  `,
  styles: [
  ]
})
export class SquareComponent {
  random = Math.random();

  constructor() {
    setInterval(() => {
      this.random = Math.random();
    }, 1000);
  }
}

Pass data to a component

We want to pass the value of the square to the square component. We will use the @Input decorator to do that.

square.component.ts

import { Component, Input } from '@angular/core';

@Component({
  selector: 'app-square',
  template: `
    <p>
      {{ value }}
    </p>
  `,
  styles: [],
})
export class SquareComponent {
  @Input() value?: 'X' | 'O';
}

Note: The ? after value means that the value is optional, so that TypeScript won't complain if we don't pass a value to the component.

app.component.html

<app-square value='X'></app-square>
<app-square [value]="'O'"></app-square>
<router-outlet></router-outlet>

Note: The [value] syntax is called property binding. It is used to bind a property of a component to a value.

We just made our first UI (or dumb) component because it doesn't have any logic. Those components are called presentational components. They are used to display data, are easily testable and reusable.

Create the board component

Create a new component called board using the Angular CLI.

 ng g c board

Which will create a new folder called board in the src/app folder.

app/board
├── board.component.html
├── board.component.scss
├── board.component.spec.ts
└── board.component.ts

board.component.html is the template of the component.
board.component.scss is the CSS styles of the component.
board.component.spec.ts is the unit test of the component.
board.component.ts is the TypeScript code of the component.

board.component.ts

import { Component } from '@angular/core';

@Component({
  selector: 'app-board',
  templateUrl: './board.component.html',
  styleUrls: ['./board.component.scss']
})
export class BoardComponent {
  // representation of the nine squares on the board
  squares: any[];
  // help us track whose turn it is
  xIsNext: boolean;
  // will either be 'X', 'O', null or undefined
  winner: string | null | undefined;
}

We start by defining the properties of the board component.

squares is an array of nine elements. Each element will be either 'X', 'O' or null.
xIsNext is a boolean that will help us track whose turn it is.
winner will either be 'X', 'O', null or undefined
- If it is 'X', it means that X won the game.
- If it is 'O', it means that O won the game.
- If it is null, it means that the game is not finished yet.
- If it is undefined, it means that the game is finished and there is no winner.

We now use the onInit lifecycle hook to initialize the board.

import { Component, OnInit } from '@angular/core';

@Component({
  selector: 'app-board',
  templateUrl: './board.component.html',
  styleUrls: ['./board.component.scss']
})
export class BoardComponent implements OnInit {
  // representation of the nine squares on the board
  squares: any[];
  // help us track whose turn it is
  xIsNext: boolean;
  // will either be 'X', 'O', null or undefined
  winner: string | null | undefined;

  ngOnInit() {
    this.newGame();
  }

  // we initialize the game
  //// we set the squares to an array of 9 nulls
  //// we set the winner to null
  //// we set xIsNext to true
  newGame() {
    this.squares = Array(9).fill(null);
    this.winner = null;
    // X is the first player
    this.xIsNext = true;
  }
}

We are going to use a javascript getter to identify the player.

// identify the current player
get player() {
  return this.xIsNext ? 'X' : 'O';
}

We then are going to simulate a move on the board.

// simulate a move
makeMove(idx: number) {
  if (!this.squares[idx]) {
    // if the square is falsy, we fill it with the current player
    this.squares.splice(idx, 1, this.player);
    // we switch the player
    this.xIsNext = !this.xIsNext;
  }
}

We then check if there is a winner.

  makeMove(idx: number) {
    if (!this.squares[idx]) {
      // if the square is falsy, we fill it with the current player
      this.squares.splice(idx, 1, this.player);
      // we switch the player
      this.xIsNext = !this.xIsNext;
    }

    // we check if there is a winner
    this.winner = this.calculateWinner();
  }

  // check if there is a winner
  // cf React tutorial: https://reactjs.org/tutorial/tutorial.html#declaring-a-winner
  calculateWinner() {
    // we define the winning combinations
    const lines = [
      [0, 1, 2],
      [3, 4, 5],
      [6, 7, 8],
      [0, 3, 6],
      [1, 4, 7],
      [2, 5, 8],
      [0, 4, 8],
      [2, 4, 6],
    ];
    // we loop through the winning combinations
    for (let i = 0; i < lines.length; i++) {
      // we destructure the winning combination
      const [a, b, c] = lines[i];
      // if the squares at the winning combination indexes are all equal and not falsy
      if (
        this.squares[a] &&
        this.squares[a] === this.squares[b] &&
        this.squares[a] === this.squares[c]
      ) {
        // we return the winner
        return this.squares[a];
      }
    }
    // if there is no winner, we return null
    return null;
  }

Now, let's take care of the User Interface

Create the board template

We first display the current player. board.component.html

<h1>Current Player: {{ player }} </h1>

We then display a button to start a new game.

<button (click)="newGame()">Start new game</button>

We then display the nine squares.

<main>
    <app-square
            *ngFor="let square of squares; let i = index"
            [value]="square"
            (click)="makeMove(i)">
    </app-square>
</main>

*ngFor is a structural directive that loops through the squares array and creates a new square component for each element.
[value]="square" is an attribute directive that passes the value of the square to the square component.
(click)="makeMove(i)" is an event binding that calls the makeMove method when the user clicks on a square.

We want to finally display the winner, if there is one.

<h2>
    <ng-container *ngIf="winner">Player {{ winner }} wins! </ng-container>
</h2>

*ngIf is a structural directive that displays the winner if there is one.
<ng-container> is a structural directive that does not create a new DOM element.
{{ winner }} is an interpolation that displays the winner.

The final template looks like this:

board.component.html

<h1>Current Player: {{ player }} </h1>

<button (click)="newGame()">Start new game</button>

<h2>
    <ng-container *ngIf="winner">Player {{ winner }} wins! </ng-container>
</h2>

<main>
    <app-square
            *ngFor="let square of squares; let i = index"
            [value]="square"
            (click)="makeMove(i)">
    </app-square>
</main>

We need some styling!

In the file board.component.scss, we add the following styles:

main {
  display: grid;
  grid-template-columns: 200px 200px 200px;
}

h2 {
  height: 2rem;
}

app-square {
  display: flex;
  align-items: center;
  justify-content: center;
  border: 1px solid gray;
  background: lightgray;
  height: 200px;
  font-size: 5em;
}

The display property of the main element is set to grid. This allows us to display the squares in a grid.
The grid-template-columns property of the main element is set to 200px 200px 200px. This allows us to display the squares in a 3x3 grid.
The height property of the h2 element is set to 2rem. This allows us to fix the size.
The display property of the app-square element is set to flex. This allows us to display the value of the square in the center of the square.

Now, our application looks like this:

hhmmm... not very pretty, is it?

Let's be smart and use a library to make it look better.

Let's use Angular Material

There are many third party component libraries that we can use to make our application look better like Bootstrap, Ionic, Nebular, etc. But we are going to use Angular Material.

Install Angular Material

We are going to use the Angular CLI to install Angular Material.

ng add @angular/material

The CLI will ask us a few questions:

Choose a prebuilt theme name, or "custom" for a custom theme: Custom
Set up Global Angular Material typography styles? Yes
Include the Angular animations module? Do not include

? Choose a prebuilt theme name, or "custom" for a custom theme: Custom
? Set up global Angular Material typography styles? Yes
? Include the Angular animations module? Do not include
UPDATE package.json (1108 bytes)
✔ Packages installed successfully.
UPDATE src/styles.scss (1644 bytes)
UPDATE src/index.html (578 bytes)

The CLI updated the package.json file, the src/styles.scss file and the src/index.html file.

Let's see the changes in the UI.

Not much has changed aside from the font and the margin.

Let's checkout the generated code

src/styles.scss

// Custom Theming for Angular Material
// For more information: https://material.angular.io/guide/theming
@use '@angular/material' as mat;
// Plus imports for other components in your app.

// Include the common styles for Angular Material. We include this here so that you only
// have to load a single css file for Angular Material in your app.
// Be sure that you only ever include this mixin once!
@include mat.core();

// Define the palettes for your theme using the Material Design palettes available in palette.scss
// (imported above). For each palette, you can optionally specify a default, lighter, and darker
// hue. Available color palettes: https://material.io/design/color/
$ng-beginner-primary: mat.define-palette(mat.$indigo-palette);
$ng-beginner-accent: mat.define-palette(mat.$pink-palette, A200, A100, A400);

// The warn palette is optional (defaults to red).
$ng-beginner-warn: mat.define-palette(mat.$red-palette);

// Create the theme object. A theme consists of configurations for individual
// theming systems such as "color" or "typography".
$ng-beginner-theme: mat.define-light-theme((
  color: (
    primary: $ng-beginner-primary,
    accent: $ng-beginner-accent,
    warn: $ng-beginner-warn,
  )
));

// Include theme styles for core and each component used in your app.
// Alternatively, you can import and @include the theme mixins for each component
// that you are using.
@include mat.all-component-themes($ng-beginner-theme);

/* You can add global styles to this file, and also import other style files */

html, body { height: 100%; }
body { margin: 0; font-family: Roboto, "Helvetica Neue", sans-serif; }

The following only has impact for now:

The html and body elements have a height of 100%.
The body element has a margin of 0.
The body element has a font-family of Roboto.

We can see that a lot was added in terms of theming but by default not much will change unless we use material components and classes.

As for the src/index.html file, the following was added:

<!doctype html>
<html lang="en">
<head>
  <meta charset="utf-8">
  <title>NgBeginner</title>
  <base href="/">
  <meta name="viewport" content="width=device-width, initial-scale=1">
  <link rel="icon" type="image/x-icon" href="favicon.ico">
  <link rel="preconnect" href="https://fonts.gstatic.com">
  <link href="https://fonts.googleapis.com/css2?family=Roboto:wght@300;400;500&display=swap" rel="stylesheet">
  <link href="https://fonts.googleapis.com/icon?family=Material+Icons" rel="stylesheet">
</head>
<body class="mat-typography">
  <app-root></app-root>
</body>
</html>

It added the following:

The link element with the href attribute set to https://fonts.googleapis.com/css2?family=Roboto:wght@300;400;500&display=swap was added. This allows us to use the Roboto font.
The link element with the href attribute set to https://fonts.googleapis.com/icon?family=Material+Icons was added. This allows us to use the Material Icons.
The body element has the mat-typography class. This allows us to use the typography styles of Angular Material.

Now it's time to make it pretty!

The button

Let's start with the button.

First, we need to import the MatButtonModule in the app.module.ts file.

import {MatButtonModule} from '@angular/material/button';

@NgModule({
  declarations: [
    AppComponent,
    SquareComponent,
    BoardComponent
  ],
  imports: [
    BrowserModule,
    AppRoutingModule,
    MatButtonModule
  ],
  providers: [],
  bootstrap: [AppComponent]
})
export class AppModule { }

Then, we can use the mat-raised-button directive in the board.component.html file and color it with the color attribute.

<h1>Current Player: {{ player }} </h1>

<button mat-raised-button color="primary" (click)="newGame()">NEW GAME</button>

<h2>
    <ng-container *ngIf="winner">Player {{ winner }} wins! </ng-container>
</h2>

<main>
    <app-square
            *ngFor="let square of squares; let i = index"
            [value]="square"
            (click)="makeMove(i)">
    </app-square>
</main>

Let's take a look at the UI.

Cool button, right?

Next Level

We are going to use the MatCardModule to make the board look better.

<mat-card>
    <mat-card-header>
        <h1>Current Player : {{ player }} </h1>
    </mat-card-header>
    <mat-card-content>
        <button mat-flat-button color="primary" (click)="newGame()">
            NEW GAME
        </button>

        <h2>
            <ng-container *ngIf="winner">Player {{ winner }} wins ! </ng-container>
        </h2>

        <main>
            <app-square
                    *ngFor="let square of squares; let i = index"
                    [value]="square"
                    (click)="makeMove(i)">
            </app-square>
        </main>
    </mat-card-content>
</mat-card>

And modify the board.component.scss file to clean, center it and make it responsive.

$square-size: 8rem;

:host {
  display: flex;
  justify-content: center;
}

mat-card {
  display: flex;
  text-align: center;
  flex-direction: column;
  align-items: center;
  margin-top: 2em;
}

main {
  display: grid;
  grid-template-columns: $square-size $square-size $square-size;
}

h2 {
  height: 2rem;
}

app-square {
  display: flex;
  align-items: center;
  justify-content: center;
  border: 1px solid;
  height: $square-size;
}

Some explanations:

The $square-size variable is used to define the dimensions of the grid.
For the grid, we changed the unit to rem to make it responsive.
The :host selector is used to select the host element of the component. In this case, it is the board.component.html file.
We use display: flex and justify-content: center to center the mat-card element.
Inside the mat-card element, we use display: flex, text-align: center, flex-direction: column and align-items: center to center the content.

Also tweaked the square.component.ts file to be responsible for the font-size and change the cursor on hover.

import { Component, Input } from '@angular/core';

@Component({
  selector: 'app-square',
  template: `
      {{ value }}
  `,
  styles: [`
    :host {
      font-size: 4rem;
      &:hover {
        cursor: pointer;
      }
    }
  `],
})
export class SquareComponent {
  @Input() value?: 'X' | 'O';
}

AND Voilà!

Going further in theming

I want to make improvement in theming:

Define my custom palette
Handle dark / light mode depending on the user's system preferences

After a few changes it looks like this on my System :

Definitely better!

Plus, if I were to change my system preferences to light, the theme would change automatically. You wouldn't even need to refresh the page.

I won't go into implementation details since it is not that complicated and I created a Pull Request intentionally, so you can check the code diff:

PR
Diff

Pipes

I just noticed in my code that I was repeating the same logic in the same or different templates.

In square.component.html

<h1>
    Next Player :
    <b [class]="player === 'X' ? 'primary' : 'accent'">{{ player }}</b>
</h1>
...
<ng-container *ngIf="winner">
    Player
    <b [class]="winner === 'X' ? 'primary' : 'accent'">{{ winner }}</b>
    wins !
</ng-container>

And in board.component.ts

template: `
    <span [class]="value === 'X' ? 'primary' : 'accent'" >
      {{ value }}
    </span>
  `,

If you were to re-use some code in the same template, then it's easy, you can create a function in the component and call it in the template.

What if you want to re-use some code in different templates?

That's where the pipes come in. Pipes are a way to transform data in the template. There are pre-defined pipes in Angular, for example, the uppercase pipe.

{{ 'hello' | uppercase }}

See https://angular.io/guide/pipes for more information.

Here, we need to create a custom pipe. Let's create a getClass pipe that will return the class depending on the player.

You can generate a pipe with the Angular CLI:

ng generate pipe pipes/getClass

Angular will generate a file getClass.pipe.ts in the src/app/pipes folder.

import { Pipe, PipeTransform } from '@angular/core';

@Pipe({
  name: 'getClass'
})
export class GetClassPipe implements PipeTransform {

  transform(value: unknown, ...args: unknown[]): unknown {
    return null;
  }

}

Let's modify it to fit our needs.

import { Pipe, PipeTransform } from '@angular/core';
@Pipe({
  name: 'getClass'
})
export class GetClassPipe implements PipeTransform {
  transform(player: 'X' | 'O' | undefined | null): string {
    return player === 'X' ? 'primary' : 'accent';
  }
}

Then we can use it in our templates.

<h1>
    Next Player :
    <b class="{{ player | getClass }}">{{ player }}</b>
</h1>
<ng-container *ngIf="winner">
    Player
    <b class="{{ winner | getClass }}">{{ winner }}</b>
    wins !
</ng-container>

  template: `
    <span class="{{ value | getClass }}" >
      {{ value }}
    </span>
  `,

That's it!

Name		Name	Last commit message	Last commit date
Latest commit History 21 Commits
src		src
.editorconfig		.editorconfig
.gitignore		.gitignore
LICENSE		LICENSE
README-default.md		README-default.md
README.md		README.md
angular.json		angular.json
package-lock.json		package-lock.json
package.json		package.json
tsconfig.app.json		tsconfig.app.json
tsconfig.json		tsconfig.json
tsconfig.spec.json		tsconfig.spec.json

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Uh oh!

Repository files navigation

ng-beginner

Introduction

Install Node.js

Install Angular CLI

Create a new project

If you are using Visual Studio Code

Startup the project

Application

Create first component

Pass data to a component

Create the board component

Now, let's take care of the User Interface

Create the board template

We need some styling!

Now, our application looks like this:

Let's use Angular Material

Install Angular Material

Let's checkout the generated code

Now it's time to make it pretty!

The button

Next Level

Going further in theming

Pipes

Inspired by

About

Uh oh!

Releases

Packages

Uh oh!

Languages

License

gaetanBloch/ng-beginner

Folders and files

Latest commit

History

Repository files navigation

ng-beginner

Introduction

Install Node.js

Install Angular CLI

Create a new project

If you are using Visual Studio Code

Startup the project

Application

Create first component

Pass data to a component

Create the board component

Now, let's take care of the User Interface

Create the board template

We need some styling!

Now, our application looks like this:

Let's use Angular Material

Install Angular Material

Let's checkout the generated code

Now it's time to make it pretty!

The button

Next Level

Going further in theming

Pipes

Inspired by

About

Topics

Resources

License

Uh oh!

Stars

Watchers

Forks

Releases

Packages 0

Uh oh!

Languages

Packages
