Pipeline

A fast, concurrent go pipeline library for Go with support for complex DAGs, automatic retries, and circuit breakers.

It's an implementation for this original thought: How to design a pipeline in go.

Performance

Tested on Apple M1 Pro. Pretty happy with these numbers:

Pipeline	Latency	Throughput	Memory
Single Node	1.8 μs	547K ops/sec	792 B/op
Two Nodes	5.2 μs	192K ops/sec	1.4 KB/op
Three Nodes	8.8 μs	113K ops/sec	2.1 KB/op

The actual processing is around 40ns per node. Most of the overhead comes from Go's channels and scheduling, which honestly isn't much we can optimize further.

BenchmarkThroughput-8         2,824,549    6,878 ns/op    145,394 ops/sec
BenchmarkLatencyBreakdown:
  SingleNode-8                6,675,679    1,825 ns/op    792 B/op     13 allocs/op
  TwoNodes-8                  2,331,255    5,202 ns/op    1,464 B/op   26 allocs/op
  ThreeNodes-8                1,372,046    8,771 ns/op    2,136 B/op   39 allocs/op

Installation

go get github.com/huahuayu/pipeline

Basic Example

Here's the simplest case - a two-stage pipeline that converts strings to uppercase and then counts characters:

package main

import (
    "context"
    "fmt"
    "strings"
    "time"

    "github.com/huahuayu/pipeline"
)

func main() {
    // First node: convert to uppercase
    toUpper := pipeline.NewNode[string, string]("uppercase",
        func(ctx context.Context, input string) (string, error) {
            return strings.ToUpper(input), nil
        })

    // Second node: count characters
    counter := pipeline.NewNode[string, int]("counter",
        func(ctx context.Context, input string) (int, error) {
            return len(input), nil
        })

    // Wire them together
    toUpper.Connect(counter)

    // Create pipeline starting from the first node
    p, err := pipeline.NewPipeline(toUpper)
    if err != nil {
        panic(err)
    }

    // Start it up
    ctx := context.Background()
    if err := p.Start(ctx); err != nil {
        panic(err)
    }

    // Send some data
    if err := p.SendWithTimeout("hello world", 5*time.Second); err != nil {
        fmt.Printf("Failed: %v\n", err)
    }

    // Clean shutdown
    if err := p.Stop(10*time.Second); err != nil {
        fmt.Printf("Shutdown error: %v\n", err)
    }
}

Features

• Type-safe with generics - No interface{} shenanigans, full compile-time type checking
• DAG support - Not just linear pipelines, build any directed acyclic graph
• Context aware - Proper cancellation and timeout support throughout
• Panic recovery - Workers handle panics gracefully
• Built-in metrics - Track throughput, latency, queue sizes
• Circuit breakers - Prevent cascading failures (disabled by default)
• Retries with backoff - Configurable retry logic (disabled by default)
• Zero dependencies - Just standard library

Configuration

By default, the pipeline runs with minimal features enabled (fail-fast mode). You can enable more complex behavior when needed:

config := pipeline.NodeConfig{
    BufferSize: 100,    // Job queue size
    Workers:    8,      // Concurrent workers

    // Retries are disabled by default
    MaxRetries: 3,
    RetryDelay: 100 * time.Millisecond,

    // Circuit breaker is disabled by default
    CircuitBreaker: pipeline.CircuitBreakerConfig{
        Enabled:          true,
        FailureThreshold: 5,
        ResetTimeout:     30 * time.Second,
    },
}

node := pipeline.NewNode[Input, Output]("my-node", processFunc, config)

Building DAGs

You're not limited to linear pipelines. Here's a diamond pattern:

// Build this graph:
//     B -> D
//    /      \
//   A        F
//    \      /
//     C -> E

nodeA.Connect(nodeB)
nodeA.Connect(nodeC)
nodeB.Connect(nodeD)
nodeC.Connect(nodeE)
nodeD.Connect(nodeF)
nodeE.Connect(nodeF)

// The pipeline figures out the topology automatically
p, _ := pipeline.NewPipeline(nodeA)

Error Handling

Errors are collected and available after processing:

node := pipeline.NewNode[string, string]("validator",
    func(ctx context.Context, input string) (string, error) {
        if input == "" {
            return "", errors.New("empty input not allowed")
        }
        return input, nil
    }).WithErrorHandler(func(err error) {
        // Log it, send to metrics, whatever you need
        log.Printf("Validation failed: %v", err)
    })

// After processing, check for errors
errors := p.Errors()
for _, err := range errors {
    log.Printf("Pipeline error: %v", err)
}

Monitoring

Each node tracks its own metrics:

metrics := node.Metrics()
fmt.Printf("Processed: %d\n", metrics.ProcessedCount.Load())
fmt.Printf("Failed: %d\n", metrics.FailedCount.Load())
fmt.Printf("Queue size: %d\n", metrics.CurrentQueueSize.Load())
fmt.Printf("Avg latency: %v\n", metrics.GetAverageLatency())

Context and Cancellation

Everything respects context cancellation:

ctx, cancel := context.WithTimeout(context.Background(), 30*time.Second)
defer cancel()

// This will respect the timeout
err := p.Send(ctx, data)
if errors.Is(err, context.DeadlineExceeded) {
    // Handle timeout
}

Architecture Notes

The pipeline is built around a few core ideas:

1. Generic nodes - Each node is strongly typed with input/output types
2. Worker pools - Each node runs N workers processing jobs concurrently
3. Buffered channels - Used for job queues with configurable buffer sizes
4. Result channels - Synchronous handoff between nodes provides natural backpressure
5. State management - Atomic operations ensure thread safety without heavy locking

Latency Breakdown

For a typical two-node pipeline processing, here's where the ~5μs goes:

• Creating context: ~100ns
• Channel send/receive: ~2000ns (multiple hops)
• Goroutine scheduling: ~1000ns
• Actual work: ~80ns (40ns per node)
• Result propagation: ~2000ns

Most overhead is from Go's runtime, not the pipeline itself.

Testing

# Standard tests
go test ./...

# Race detection (always passes!)
go test -race ./...

# Benchmarks
go test -bench=. -benchmem

# Coverage
go test -cover ./...

Check out pipeline_test.go for more examples including stress tests, error scenarios, and complex DAG configurations.

Tips

1. Start simple - Use defaults first, add complexity only when needed
2. Size buffers appropriately - Too small causes backpressure, too large wastes memory
3. One pipeline per flow - Don't try to reuse pipelines for different data flows
4. Always call Stop() - Ensures graceful shutdown and cleanup
5. Monitor in production - The built-in metrics are there for a reason

Contributing

PRs welcome. Just make sure:

• Tests pass (including race detector)
• Benchmarks don't regress significantly
• New features include tests
• Public APIs have godoc comments

License

MIT
