WA-Notify

Self-hosted WhatsApp Notification Microservice — send WhatsApp notifications from any system via REST API.

---

📖 About the Project

WA-Notify is a self-hosted WhatsApp notification microservice. This project allows you to send WhatsApp messages automatically via a REST API — perfect for integration with monitoring systems (Grafana, Uptime Kuma, Netdata), CI/CD pipelines, IoT devices, cron jobs, or any application that can perform an HTTP request.

This microservice uses the WhatsApp Multi-Device protocol via the Baileys library, so it does not require a paid WhatsApp Business API. Simply scan the QR code with a personal WhatsApp account, and the microservice is ready to use.

Key Features

• 🔗 WhatsApp Multi-Device — Connect to WhatsApp without needing your phone to stay online.
• 📡 REST API — Send messages via POST (JSON body) or GET (query string).
• 🪝 Webhook Receiver — Receive alerts from Grafana, Uptime Kuma, Netdata, etc. automatically.
• 🖥️ Web Dashboard — Manage connections, scan QR codes, send test messages, and view API docs directly from the browser.
• 🔄 Auto-Reconnect — Connection automatically restores if disconnected.
• 💾 Persistent Session — Session is saved on disk, no need to rescan the QR code on every restart.
• 📱 Smart Number Format — Automatically formats local numbers to international format.

🎥 Video Guide & Demo

---

🛠️ Tech Stack

Component	Technology	Description
Runtime	Node.js ≥ 18	JavaScript runtime
Framework	NestJS v11	Modular & scalable backend framework
Language	TypeScript 5.x	Static typing for JavaScript
WhatsApp Client	@whiskeysockets/baileys v7	WhatsApp Web API (Multi-Device)
QR Code	qrcode	Generate QR codes as base64 Data URLs
Logger	Pino	High-performance JSON logger
Validation	class-validator + class-transformer	DTO request validation
Config	@nestjs/config	Environment variable management
Static Files	@nestjs/serve-static	Serve the web dashboard
Linting	ESLint + Prettier	Code formatting & linting
Testing	Jest + Supertest	Unit & e2e testing

---

🚀 Installation

Prerequisites

• Node.js ≥ 18 (download)
• npm ≥ 9 (bundled with Node.js)
• Active WhatsApp account on your smartphone

1. Clone the Repository

git clone https://github.com/jojixyz666/WhatsappNotify-API.git
cd WhatsappNotify-API

2. Install Dependencies

npm install

3. Configure the Environment

Copy the .env.example file or create a .env file in the project root:

PORT=3000
WHATSAPP_SESSION_DIR=sessions
DEFAULT_COUNTRY_CODE=62
DEFAULT_RECIPIENT=

Variable	Default	Description
PORT	3000	Server port
WHATSAPP_SESSION_DIR	sessions	Directory where WhatsApp sessions are stored
DEFAULT_COUNTRY_CODE	62	Default country code (62 = Indonesia)
DEFAULT_RECIPIENT	(empty)	Default recipient phone number for webhooks & GET sends (optional)

4. Run the Server

# Development (with auto-reload)
npm run start:dev

# Production
npm run build
npm run start:prod

5. Scan the QR Code

Once the server is running:

1. Open your browser and go to → http://localhost:3000
2. Or view the QR code in the terminal
3. Open WhatsApp on your phone → Linked Devices → Link a Device
4. Scan the QR code
5. Status changes to Connected ✅

Note: The session is saved in the sessions/ folder. As long as this folder is not deleted, you do not need to scan the QR code again after restarting the server.

---

📡 API Reference

Base URL: http://localhost:3000

Check Connection Status

GET /api/whatsapp/status

Response:

{
  "status": "CONNECTED",
  "isLoggedIn": true
}

Possible statuses: CONNECTED, CONNECTING, DISCONNECTED, SCAN_QR

---

Send Message (POST)

POST /api/whatsapp/send
Content-Type: application/json

Body:

{
  "to": "628123456789",
  "message": "Hello from WA-Notify! 🚀"
}

Response:

{
  "success": true,
  "message": "Message queued/sent successfully",
  "data": {
    "id": "ABCDEF123456",
    "to": "628123456789@s.whatsapp.net",
    "status": "SENT"
  }
}

---

Send Message (GET)

GET /api/whatsapp/send?to=628123456789&message=Hello+World

Suitable for simple integrations, browser redirects, or webhooks without a body.

Parameter	Required	Description
to	No*	Recipient number. If empty, uses DEFAULT_RECIPIENT from .env
message or msg	Yes	Message body

---

Webhook Receiver

POST /api/whatsapp/webhook?to=628123456789
Content-Type: application/json

This endpoint automatically parses payloads from various monitoring systems. Supports the following body keys:

• message, msg, text, body, content — for message content
• to, phone, number — for recipient number
• title — combined with the message if present

If to is not found in either the body or the query, it falls back to DEFAULT_RECIPIENT.

Example: Uptime Kuma

{
  "msg": "🔴 Server Production DOWN!",
  "to": "628123456789"
}

Example: Grafana Alert

{
  "title": "High CPU Usage",
  "message": "CPU usage exceeded 90% on server-01"
}

---

Retrieve QR Code

GET /api/whatsapp/qr

Response (when status is SCAN_QR):

{
}

---

Logout / Disconnect

POST /api/whatsapp/logout

Clears the session and restarts the connection flow (a new QR code will be generated).

---

🖥️ Web Dashboard

Access the dashboard at http://localhost:3000 after the server starts.

Tab	Function
Dashboard	Real-time connection status, QR code display, session metrics, disconnect button
Test Console	Form to send test messages with an activity log
API Reference	Complete endpoint documentation with payload examples

The dashboard uses a dark theme with auto-polling (status every 3 seconds, QR every 5 seconds).

---

📂 Project Structure

WhatsappNotify-API/
├── public/
│   └── index.html            # Web dashboard (single-page)
├── sessions/                  # WhatsApp session data (auto-generated, gitignored)
├── src/
│   ├── main.ts                # Application entry point
│   ├── app.module.ts          # Root module (config, static files, whatsapp)
│   ├── app.controller.ts      # Root controller
│   ├── app.service.ts         # Root service
│   └── whatsapp/
│       ├── whatsapp.module.ts     # WhatsApp feature module
│       ├── whatsapp.controller.ts # REST API endpoints & DTO validation
│       └── whatsapp.service.ts    # Baileys connection, QR, send logic
├── test/                      # E2e test files
├── .env                       # Environment variables (gitignored)
├── .gitignore
├── .prettierrc
├── CHANGELOG.md
├── eslint.config.mjs
├── nest-cli.json
├── package.json
├── tsconfig.json
└── tsconfig.build.json

---

📜 Scripts

Command	Description
npm run start	Start the server
npm run start:dev	Start the server with auto-reload (watch mode)
npm run start:debug	Start the server in debug mode
npm run start:prod	Run the compiled production build
npm run build	Compile TypeScript to JavaScript
npm run lint	Run ESLint
npm run format	Format code with Prettier
npm run test	Run unit tests
npm run test:e2e	Run end-to-end tests
npm run test:cov	Run tests and generate coverage report

---

🤝 Integration

WA-Notify is designed to be easily integrated with various systems:

• Uptime Kuma — Add a "Webhook" notification type with URL http://server:3000/api/whatsapp/webhook?to=628xxx
• Grafana — Use a "Webhook" contact point pointing to the webhook endpoint
• Netdata — Configure alarm notifications via webhook
• Cron Job — Call the GET endpoint from a crontab: curl "http://localhost:3000/api/whatsapp/send?to=628xxx&msg=Backup+completed"
• Custom App — Send an HTTP POST to /api/whatsapp/send from any programming language

---

⚠️ Disclaimer

This project uses an unofficial library to communicate with WhatsApp. Any usage beyond WhatsApp's Terms of Service is the user's responsibility. It is recommended to use a dedicated WhatsApp account specifically for notifications.
