Chen

Chen is the WebDB connection component of JumpServer, supporting multiple database protocols.

Chen is implemented in Java, and its name is derived from the Dota hero Chen.

UI Showcase

Supported Features

• Security Authentication
• SQL Filtering
• SQL Recording
• SQL Blocking

Supported Databases

• MySQL 5.7/8.0+
• MariaDB
• PostgreSQL (X-Pack)
• SQL Server (X-Pack)
• Oracle (X-Pack)
• DB2 (X-Pack)

Develop with Wisp

The default Chen image contains a released Wisp binary. The development override separates Wisp into its own service, starts Chen's Java process directly, and connects Chen to wisp:9090 over the Compose network.

Use a Wisp image

make run defaults to ghcr.io/jumpserver/wisp:<chen-branch>. The branch is resolved from the current branch's tracking branch first, then from the local branch. JumpServer-style branches such as pr@new_terminal@feat_ai resolve to their base branch (new_terminal), and characters that cannot appear in a Docker tag are replaced with -. A detached checkout falls back to latest.

Check the result without starting containers:

make dev-wisp-image

The matching tag must have been published in the Wisp container registry. If it is not available, select a known tag with WISP_TAG, use WISP_SOURCE as described below, or set WISP_IMAGE to a private-registry or locally built image:

make run WISP_TAG=latest

make run \
  WISP_IMAGE=registry.example.com/wisp:my-branch \
  WISP_PULL_POLICY=always

Use WISP_BRANCH to resolve a tag from a branch other than the checked-out Chen branch. WISP_IMAGE_REPOSITORY changes only the registry/repository while retaining automatic tag selection. For an image already built locally, set WISP_PULL_POLICY=never.

Calling docker compose directly (without the Makefile) retains the Compose file's ghcr.io/jumpserver/wisp:latest fallback.

Build from Wisp source

Add docker-compose.wisp-source.yml and set WISP_SOURCE to any local checkout path. It does not need to be ../wisp:

make run WISP_SOURCE=/absolute/path/to/wisp

WISP_SOURCE is a BuildKit named context, so it may also be a Git context URL when the changes have been pushed to a branch. Uncommitted changes require a local directory.

After a Go-only Wisp change, rebuild just Wisp; the Java container can stay up and its gRPC channel will reconnect:

make dev-wisp WISP_SOURCE=/absolute/path/to/wisp

If a Wisp .proto file changes, regenerate both Go and Java outputs in Wisp, then synchronize the Java output before rebuilding Chen:

make -C /absolute/path/to/wisp proto-go proto-java
make proto-sync WISP_SOURCE=/absolute/path/to/wisp
make dev-up WISP_SOURCE=/absolute/path/to/wisp

With JDK 21 and Maven installed, use make dev to build and start Chen directly on the host. Use make run to build and start Chen and Wisp together with Compose. Use make dev-up for detached Compose startup, make dev-logs to follow both service logs, and make dev-down to stop the environment. Run make help for all development commands.

The build and runtime limits can be adjusted with WISP_BUILD_PROCS, WISP_BUILD_MEMORY, WISP_CPUS, WISP_MEMORY_LIMIT, CHEN_CPUS, and CHEN_MEMORY_LIMIT.
