📌 About RentGo

RentGo is a vehicle rental REST API designed to offer a simple, fast, and secure car rental experience.

The platform allows users to browse available vehicles, create accounts, manage rentals, add accessories, register payments and rate the service — all through a well-structured and documented API.

🎓 This system was created as the final project of the CodeRDIversity Program — a diversity-focused technology bootcamp.

---

⚙️ Features

Module	Features
🚗 Vehicles	Register, update, remove, search by status and list available with pagination
📋 Rentals	Create, search, cancel, return and update rental dates
🔧 Accessories	Register accessories and link / unlink them from rentals with automatic value calculation
💳 Payments	Register partial or total payments via PIX, credit card, debit card, bank slip or cash
👤 Users	Create and search users with rental history
⭐ Ratings	Submit rating and comment when ending a rental
📄 Reports	Export detailed rental report in TXT or CSV

---

🏗 Architecture

The project follows the Layered Architecture pattern with clear separation of responsibilities across layers:

HTTP Client
     │
 Controllers   ← receives requests, validates ModelState, returns HTTP codes
     │
  Services     ← business rules, validations, DTO ↔ entity mappings
     │
Repositories   ← data access via EF Core, no business rules
     │
PostgresContext ← schema: sistema_locacao (PostgreSQL)

All dependencies are registered as Scoped via dependency injection — controllers and services depend only on interfaces, never on concrete implementations.

📐 View full architecture documentation →

---

🛠️ Technologies

Technology	Version	Usage
.NET	8.0	Base runtime and framework
ASP.NET Core Web API	8.0	HTTP layer
Entity Framework Core	8.0	ORM
Npgsql	8.0.0	PostgreSQL provider
Swashbuckle (Swagger)	6.4.0	Interactive documentation
NUnit + xUnit	3.13 / 2.9	Automated tests
Moq	4.20	Test mocks
Coverlet	6.0.4	Code coverage

---

📘 Documentation

All technical documentation is available in Portuguese and English:

Document	Description	PT-BR	EN
🏗 Architecture	Layers, data model, DI, business flows and testing strategy	architecture.md	architecture.en.md
🔌 Endpoints	All 24 endpoints with routes, parameters, body and responses	endpoints.md	endpoints.en.md
🧪 Tests	Complete report of 135 tests by layer and module	tests.md	tests.en.md
🔬 API Tests	Insomnia collection with all endpoints pre-configured by module	Insomnia.yaml	—
🗄 Database	DDL script for creating the sistema_locacao schema and 7 tables	scriptSQLcreate.sql	—
🌱 Test Data	Seed script with 3 vehicles, 3 users, 3 accessories and 1 complete rental	scriptTestData.sql	—

---

🚀 How to Run

Clone the repository

git clone https://github.com/luiizaferreirafonseca/VehicleRentalSystem.git
cd VehicleRentalSystem

Configure the database

Create a local PostgreSQL server using DBeaver or PGAdmin.

📥 Recommended option — import the script directly

Download the docs/scriptSQLcreate.sql file and import it directly into your tool:

• DBeaver: right-click the database → SQL Editor → Open SQL Script → select the file
• PGAdmin: right-click the database → Query Tool → open the file via File > Open

Then, execute the script in the following order, as tables respect foreign key dependencies:

Block 1 — Create the schema:

CREATE SCHEMA IF NOT EXISTS sistema_locacao;

Block 2 — Independent tables (no foreign keys):

CREATE TABLE sistema_locacao.tb_user      ( ... );  -- Users
CREATE TABLE sistema_locacao.tb_vehicles  ( ... );  -- Vehicles
CREATE TABLE sistema_locacao.tb_accessory ( ... );  -- Accessories

Block 3 — Dependent tables (require the blocks above):

CREATE TABLE sistema_locacao.tb_rental            ( ... );  -- Rentals
CREATE TABLE sistema_locacao.tb_rental_accessory  ( ... );  -- Rental Accessories
CREATE TABLE sistema_locacao.tb_payment           ( ... );  -- Payments
CREATE TABLE sistema_locacao.tb_rating            ( ... );  -- Ratings

⚠️ Execute each block separately to identify errors easily.

🌱 Seed the database with initial data

After creating the tables, run the docs/scriptTestData.sql script to validate the schema creation and insert the first test records:

• 3 vehicles (2 available, 1 maintenance)
• 3 users
• 3 accessories (GPS, Child Seat, Extra Insurance)
• 1 active rental with a linked accessory, payment and rating registered

✅ At the end of each script block there is a SELECT to confirm data was inserted correctly.

Configure the Connection String

In VehicleSystem/appsettings.json, adjust the values according to your server:

{
  "ConnectionStrings": {
    "DefaultConnection": "Host=localhost;Port=5432;Database=vehicle_rental;Username=postgres;Password=postgres"
  }
}

Run the API

dotnet run --project VehicleSystem

Test the endpoints

📄 Swagger — automatically generated by .NET

Access the interactive documentation directly in your browser:

http://localhost:{port}/swagger

Swagger is automatically enabled in the development environment and allows you to view and execute all API endpoints.

🔬 Insomnia — complete pre-configured collection

Download the docs/Insomnia.yaml file and import it into Insomnia:

• Insomnia: File → Import → select the Insomnia.yaml file

The collection contains all endpoints organized by module (Rentals, Payments, Accessories, Vehicles, Ratings, Users, Reports) with body examples and parameters ready to use.

Run the tests

# All tests
dotnet test VehicleSystem.Tests

# With code coverage
dotnet test --collect:"XPlat Code Coverage"

📊 Coverage report — automated script

The project includes the VehicleSystem.Tests/coverage.ps1 script that automates the entire coverage workflow:

1. Runs the tests with --collect:"XPlat Code Coverage"
2. Locates the latest result directory inside TestResults/
3. Generates a full HTML report via reportgenerator
4. Automatically opens the report in the browser

# From the project root
.\VehicleSystem.Tests\coverage.ps1

⚠️ Requires ReportGenerator installed as a global tool:

dotnet tool install -g dotnet-reportgenerator-globaltool

---

👩‍💻 Contributors

Developed with dedication by our team 💙

Alessandra Batista

Luiza Ferreira

Priscilla Trevizan
