MapLibre Native + Slint Reference Implementation

This repository is a working reference for using MapLibre Native inside Slint applications.

The important thing here is not packaging polish. The important thing is that the combination actually works today across desktop platforms, with a reusable Slint component surface in src/.

What This Repository Is

• A reusable Slint component library centered on src/maplibre.slint
• A reusable C++ backend library target (maplibre-native-slint::mbgl-slint) you can link from your own CMake app
• A canonical C++ backend integration that works on Linux, Windows, and macOS
• A practical reference for people who want to build their own Slint + MapLibre app
• A place to validate backend choices such as WebGPU (wgpu-native) and Metal/OpenGL fallbacks

What This Repository Is Not

• Not yet a polished end-user SDK
• Not yet an installable, versioned package (no find_package / system install yet) — you consume it via FetchContent / add_subdirectory, see Use It In Your Own App
• Not a "everything is magically wired for you" drop-in — you still write the small MMapAdapter wiring in your own main (see cpp/main.cpp)

Today, the most honest way to describe this repository is:

If you want to build a Slint application that embeds MapLibre, this repository shows a real cross-platform way to do it.

Current Recommendation

If you want something that works today, use the C++ path as the reference implementation.

• The reusable Slint API lives in src/
• The authoritative backend wiring lives in cpp/main.cpp
• The demo shell lives in cpp/map_window.slint

The Rust demo exists to mirror the same Slint component contract, but it depends on maplibre-native-rs and its current 0.8.x API surface. It is still only practical on Linux today. Treat it as an experimental companion, not the primary integration path.

Quick Start

Platform-specific build guides:

• Linux: Ubuntu 24.04 Build Guide
• Windows: Windows 11 Build Guide
• macOS: macOS Apple Silicon Build Guide

Typical Linux build:

git clone https://github.com/maplibre/maplibre-native-slint.git
cd maplibre-native-slint
git submodule update --init --recursive

cmake -B build -DCMAKE_BUILD_TYPE=Release
cmake --build build

./build/cpp/maplibre-slint-example

The default build prefers the WebGPU backend with wgpu-native when available.

For Windows and macOS specifics, use the platform guides above.

Reusable Slint Surface

The public Slint entrypoint is src/maplibre.slint:

import { MMapView, MMapAdapter } from "@maplibre-native-slint/maplibre.slint";

The key exported symbols are:

• MMapView: the reusable visual map component
• MMapAdapter: the global bridge between the Slint UI and a native backend

Minimal UI usage looks like this:

import { MMapView } from "@maplibre-native-slint/maplibre.slint";

export component App inherits Window {
    preferred-width: 800px;
    preferred-height: 600px;

    map := MMapView {
        style-url: "https://demotiles.maplibre.org/style.json";
        center-lat: 35.6895;
        center-lon: 139.6917;
        zoom: 10;
    }
}

That is the reusable UI layer.

What still needs to be provided by the host application is the native backend wiring for MMapAdapter. The canonical example of that wiring is cpp/main.cpp.

Use It In Your Own App

The repository is consumable directly from another CMake project — no system install needed. Fetch it and link the reusable backend target maplibre-native-slint::mbgl-slint, which publicly propagates MapLibre Native, Slint, cpr, the GL/WebGPU libraries, and the backend headers:

include(FetchContent)
FetchContent_Declare(
  maplibre-native-slint
  GIT_REPOSITORY https://github.com/maplibre/maplibre-native-slint.git
  GIT_TAG <pin-a-commit>
)
FetchContent_MakeAvailable(maplibre-native-slint)

add_executable(my-app main.cpp)

# Import the reusable Slint components via the @maplibre-native-slint alias.
slint_target_sources(my-app my.slint
  LIBRARY_PATHS maplibre-native-slint=${maplibre-native-slint_SOURCE_DIR}/src)

target_link_libraries(my-app PRIVATE maplibre-native-slint::mbgl-slint)

Your main.cpp wires the Slint MMapAdapter callbacks to a SlintMapLibre instance (from slint_maplibre_headless.hpp, provided by the target). Copy cpp/main.cpp as the starting point.

Backend selection

The default build uses WebGPU (wgpu-native). To use OpenGL instead, disable WebGPU and select a backend explicitly — a bare -DMLN_WITH_WEBGPU=OFF fails fast with a message telling you to pick one:

cmake -B build -DMLN_WITH_WEBGPU=OFF -DMLN_WITH_OPENGL=ON

Slint provisioning

A system-installed Slint is used if found, otherwise Slint is built from source. A system Slint built against a foreign Qt/ICU can bake its RUNPATH into your binary and break portability, so force a self-contained build with:

cmake -B build -DMLN_SLINT_USE_SYSTEM=OFF

For a fully self-contained, no-Qt result (kiosk / embedded), combine it with the winit + FemtoVG Slint backend:

cmake -B build \
  -DMLN_WITH_WEBGPU=OFF -DMLN_WITH_OPENGL=ON \
  -DMLN_SLINT_USE_SYSTEM=OFF \
  -DSLINT_FEATURE_BACKEND_QT=OFF \
  -DSLINT_FEATURE_BACKEND_WINIT=ON \
  -DSLINT_FEATURE_RENDERER_FEMTOVG=ON

Architecture

UI contract

• src/m-map-view.slint defines the reusable map component
• src/m-map-adapter.slint defines the backend bridge contract
• src/maplibre.slint is the public entrypoint

Canonical backend

• cpp/src/slint_maplibre_headless.cpp holds the current production-grade backend logic
• It is packaged as the mbgl-slint library target (alias maplibre-native-slint::mbgl-slint) so apps and tests link it instead of recompiling the sources
• cpp/main.cpp wires MMapAdapter to that backend
• cpp/map_window.slint is a demo shell showing how to use the reusable component

Experimental backend

• rust/main.slint mirrors the same Slint component contract as the C++ demo
• rust/src/maplibre.rs wires MMapAdapter to maplibre-native-rs
• This path is useful for experimentation on Linux, but it is not the repository's primary story today

Platform Status

Reusable Slint component + C++ backend

Platform	Status	Notes
Linux x86_64	Good	Regularly exercised; best-supported development path
Windows x64	Good	Working desktop path
macOS Apple Silicon	Good	Working desktop path

Reusable Slint component + Rust backend

Platform	Status	Notes
Linux x86_64	Experimental	Tracks maplibre-native-rs 0.8.x; best place to validate the Rust path
Windows x64	Not practical	Blocked by maplibre-native-rs maturity
macOS Apple Silicon	Not practical	Blocked by maplibre-native-rs maturity

This is why the C++ backend remains the canonical reference implementation in this repository.

Rendering Pipeline

The current implementation uses a GPU-to-CPU readback pipeline:

1. MapLibre Native renders into its headless frontend using the selected backend
2. The rendered frame is read back into CPU memory as mbgl::PremultipliedImage
3. Pixels are copied into a slint::SharedPixelBuffer
4. MMapAdapter.frame is updated
5. MMapView displays that frame and forwards interactions back to the backend

This is not the final ideal architecture, but it is robust and cross-platform enough to serve as a practical reference.

Build Backends

Current desktop backend preferences:

• Linux: WebGPU (wgpu-native) by default
• Windows: WebGPU (wgpu-native) by default
• macOS: WebGPU (wgpu-native) by default, with Metal still useful as a comparison/fallback path

Examples:

# Default desktop build
cmake -B build -DCMAKE_BUILD_TYPE=Release

# Explicit WebGPU / wgpu-native
cmake -B build -DCMAKE_BUILD_TYPE=Release -DMLN_WITH_WEBGPU=ON -DMLN_WEBGPU_IMPL_WGPU=ON

# macOS Metal fallback / comparison
cmake -B build -DCMAKE_BUILD_TYPE=Release -DMLN_WITH_METAL=ON -DMLN_WITH_OPENGL=OFF -G Xcode

# Explicit OpenGL fallback
cmake -B build -DCMAKE_BUILD_TYPE=Release -DMLN_WITH_WEBGPU=OFF -DMLN_WITH_OPENGL=ON

Project Structure

• src/ - reusable Slint component API
• cpp/ - canonical C++ backend integration and demo app
• rust/ - Linux-oriented experimental Rust backend integration
• vendor/ - MapLibre Native and other vendored dependencies
• docs/build_guides/ - platform-specific build guides
• docs/testing.md - testing instructions

Testing

Relevant test/documentation entrypoints:

• Testing Guide
• Testing Overview

For the Rust backend specifically:

• use Rust 1.90 or newer (maplibre-native-rs 0.8.x requires it)
• on Linux, the default backend is OpenGL and cargo test builds maplibre-native from source through maplibre-native-rs
• renderer integration tests are opt-in via MAPLIBRE_NATIVE_SLINT_RUN_RENDERER_TESTS=1 so CI can stay headless by default

For day-to-day validation, the most important checks are:

• the C++ demo builds and launches on Linux, Windows, and macOS
• the reusable Slint contract in src/ stays compatible with both demo shells
• the Rust demo remains aligned with the same MMapView / MMapAdapter contract on Linux

Roadmap

Near-term goals:

• Keep the reusable Slint API in src/ and the mbgl-slint target stable enough for direct consumption
• Keep the C++ backend as the authoritative cross-platform reference

Longer-term possibilities:

• an installable/exported package (find_package(maplibre-native-slint)) so downstream apps do not need FetchContent
• better packaging so users do not need to think about the C++ toolchain
• a lower-overhead rendering path that avoids GPU-to-CPU readback

These are goals, not promises. The current value of this repository is that it already demonstrates a real working integration.

Troubleshooting

Build issues

• Run git submodule update --init --recursive
• Follow the platform-specific build guide for your OS
• On Linux and Windows with WebGPU, make sure LLVM/libclang is available for bindgen

Runtime issues

• Make sure your machine has network access for style and tile loading
• On Linux, ensure a graphical session is available if you are launching the desktop demo directly

Community

• MapLibre Native Slack: #maplibre-native
• OSM US Slack invite: slack.openstreetmap.us
• MapLibre website: maplibre.org

License

Copyright (c) 2025 MapLibre contributors.

This project is licensed under the BSD 2-Clause License. See LICENSE.

This repository integrates multiple components with their own licenses:

• MapLibre Native: BSD
• Slint: GPL-3.0-only OR LicenseRef-Slint-Royalty-free-2.0 OR LicenseRef-Slint-Software-3.0
