M5Burner

A utility used to flash M5 Stack devices with M5Stack's own firmware (some require an account to download them) or community firmware made by others.

Changes in this version:

• Newer Electron build (16.0.7 -> 37.2.4)
• Newer version of esptool.py (4.7-dev -> 5.0.1, on Mac OS it's 4.8.1)
• Migrate to newer node-usb library from the legacy node-usb-detection and node-usb-native libraries

Note for Mac OS users:

Due to Mac OS enforcing code signing since Mac OS Sequoia you will need to either build your own version yourself to skip this check (see Compile instructions below) or manually approve the app in Settings.

To do this, open the app as usual until you see this message:

Then go to Settings --> Privacy and Security and scroll down until you see the m5burner app being listed as ""m5burner" was blocked to protect your Mac." like here below:

Click on the Run Anyway button near it and confirm again (Mac OS really wants to convince you to not run any unsigned apps)

After this, you should be able to open M5Burner.

Compile instructions:

1. Clone this repo (+ submodules) and install dependencies

git clone --recurse-submodules https://github.com/matu6968/m5burner.git
# --recurse-submodules is needed to clone esp-idf-nvs-partition-gen submodule
# if you forgot to do so, run git submodule update --init after cloning
cd m5burner
yarn install
pip install pyinstaller rich_click
# To install libnotify dependencies for Linux launcher to build depending on distro
sudo apt install libnotify-dev # on Ubuntu/Debian systems
sudo pacman -S libnotify # on Arch Linux systems
sudo dnf install libnotify # on Fedora systems
sudo zypper install libnotify # on openSUSE systems
# for other distros, refer to your distro's package manager for libnotify equivalent

2. Recompile native dependencies

yarn postpackage

3. Test the app if it works (this checks if node modules are properly compiled)

yarn test

If you are on a 32 bit ARM system and getting a no native build was found error, you need to rebuild the native modules for the ARMv7l architecture using the following command:

yarn rebuild-native-modules-arm

4. (Only on systems running Python <3.10) Downgrade esptool before it dropped Python <3.10 support:

# This is already done in Mac OS builds since these have a consistent out of date built in version of Python
yarn update-esptool --support-below-py3.10

5. Compile the additional dependencies and package the app

yarn package

Other flags are supported for the build process that can be mixed with eachother:

--new-release - builds a new release then packages into a archive file depending on the platform

--pi-apps - builds a version of the app for Pi-Apps by building the launcher to use the install paths oriented for Pi-Apps (ideally use the --new-release flag when using this so that you have a new release for uploading on release page if you are a maintainer for updating the app on Pi-Apps)

--time-sync - delays the time present on appVersion.info by the next hour interval (for example, if the build started at 12:27, it will have file output it as 12:00)

--legacy-release specify a Electron version to use for the release for this build only by it's major version (for example, --legacy-release 22 will use Electron 22.x.x, ideal for older systems that don't support the latest Electron version, though this will lack any security updates for Electron if the Electron version selected is EOL)

License

Due to the client having independent changes from the official version, it is under the MIT license.

⚠️ Warning: This does not cover images and icons used within this repository which are still M5Stack property.

For 3rd party libraries: see LICENSE-3rd-party

USB Device Access Setup

Due to the migration of the client to use the node-usb library, several system changes may be required to use the new client depending on your system:

Linux

Add the following udev rules to /etc/udev/rules.d/99-usb-serial.rules:

CP210x devices

SUBSYSTEM=="usb", ATTRS{idVendor}=="10c4", ATTRS{idProduct}=="ea60", MODE="0666"

CH340/CH341 devices

SUBSYSTEM=="usb", ATTRS{idVendor}=="1a86", ATTRS{idProduct}=="7523", MODE="0666"

CH342 devices

SUBSYSTEM=="usb", ATTRS{idVendor}=="1a86", ATTRS{idProduct}=="55D2", MODE="0666"

CH343 devices

SUBSYSTEM=="usb", ATTRS{idVendor}=="1a86", ATTRS{idProduct}=="55D3", MODE="0666"

CH9102 devices

SUBSYSTEM=="usb", ATTRS{idVendor}=="1a86", ATTRS{idProduct}=="55D4", MODE="0666"

FTDI devices

SUBSYSTEM=="usb", ATTRS{idVendor}=="0403", MODE="0666"

ESP32-S3/-C6 devices with internal USB-CDC adapters

SUBSYSTEM=="usb", ATTRS{idVendor}=="303a", MODE="0666"

Then reload the rules:

sudo udevadm control --reload-rules
sudo udevadm trigger

Windows

No additional setup required, but users need to have the appropriate USB-Serial drivers installed for the specific serial chipset on the device:

CH340, CH341 drivers: https://www.wch-ic.com/downloads/CH341SER_EXE.html (most common on ESP based devices)

CP2102 drivers: https://www.silabs.com/developers/usb-to-uart-bridge-vcp-drivers

CH342, CH343, CH9102 drivers: https://www.wch.cn/downloads/CH343SER_ZIP.html

FTDI drivers: https://ftdichip.com/drivers/vcp-drivers/

ESP32-S3/-C6 USB-CDC driver setup (guide to use with libusb): https://docs.espressif.com/projects/esp-idf/en/v5.4/esp32s3/api-guides/dfu.html?#api-guide-dfu-flash-win

macOS

No additional setup required.

esptool dependencies:

Due to commit https://github.com/espressif/esptool/commit/d40fefa275dc4da28fdc747d2909a9ec29687ae8 on esptool, rich_click is now a required dependency when using esptool. To not add any further dependencies to the deps folder, this will require the user to install it. For Mac OS or Windows users running a prebuilt package, this does not apply otherwaise install it via pip:

pip install rich_click
