This repository contains a selection of proejcts from Applied Digital Logic Exercises Using FPGAs by Kurt Wick.
The toolchain used for this project is Vivado 2018.1 -- you can download the free (Webpack) version here: https://www.xilinx.com/products/design-tools/vivado/vivado-webpack.html
Each project folder contains a bitfile (.bit) which you can directly program onto compatible Xilinx FPGAs.
For development, I used a Digilent Basys3 development board, but the examples are generally hardware-agnostic as long as you provide your own constraints file and your board has the required hardware components:
- A seven-segment display
- DIP switches
- A USB interface
- At least one available PMOD connector
Additionally, some of the other examples require external hardware components like:
- External flash
- External audio amplifier
- Half-adder
- Full-adder
- 8-bit adder
- 4-bit ripple counter
- A 44.1 KHz audio "clock"
- A PWM Audio player
- FSM frequency counter
- FSM frequency counter, that uses a soft-core processor and communicates with PC via UART.
