Rebel Framework Thrid Person Project Template

Install the Third-Person Project Template:

Open your terminal or command prompt.

Use the following command to install the rbfx.template.thirdperson template package from NuGet:

dotnet new install rbfx.template.thirdperson

This command will download and install the template package. If you want to install a specific version, you can specify it using the format rbfx.template.thirdperson::.

Create a New Solution Using the Installed Template:

Navigate to the directory where you want to create your solution.

Run the following command to generate a new solution based on the installed template:

dotnet new rbfx.thirdperson -n MyAwesomeGame

Replace MyAwesomeGame with your desired solution name.

This command will create a new solution with the necessary project structure and files based on the Third-Person template.

Explore and Customize:

Inside the newly created solution folder (MyAwesomeGame in this example), you’ll find project files for the game, character, and other related components.

Customize the project files according to your requirements. You can add more game features, modify existing code, and create additional projects within the solution.

Build and Run:

Build the solution using the following command:

dotnet build

Run your game using:

dotnet run --project MyAwesomeGame.Desktop/MyAwesomeGame.Desktop.csproj

This will compile your solution and execute the game. Remember to adjust the commands and folder names based on your specific setup. Happy coding! 🚀🎮

For more information, you can refer to the official documentation on installing and managing SDK templates.

GitHub Actions Workflow Execution:

Whenever you push changes to the master branch, GitHub Actions will automatically trigger the workflow.

It will build your game, create a GitHub release, and upload the precompiled game artifact.

Verify the Release:

Visit the Releases section of your repository to verify that the release was created successfully.

Optional: itch.io Publishing:

If you want to publish to itch.io setup itch.io token. Go to your GitHub repository. Navigate to Settings > Secrets and variables. Add a new secret named BUTLER_API_KEY and set its value to your itch.io personal access token. Add new variable ITCH_PROJECT to the itch.io project id like rebelfork/rbfx-csharp-thirdperson

That's it! Your GitHub Actions workflow will now build your game and make it available for download via GitHub Releases. Optionally, it can also publish to itch.io if configured.

Optional: Steam Publishing

This action assumes you are registered as a partner with Steam.

One way of publishing the app would be to download zip files for .Desktop. builds and manually upload them to relevant depots. The rest of this readme is dedicated to publish automation via Github Action.

Set STEAM_APPID and STEAM_USERNAME action secret

Set STEAM_USERNAME to the builder's user name.

Set STEAM_APPID to the application or demo id.

Create "prerelease" branch

You need to create a "prerelease" branch in the App Data Admin. Go to SteamPipe/Builds menu and click Create new branch.

The reason for this is that Steam doesn't allow to make default branch live automatically and the Github Action for Steam publication will fail to do so.

Depots

The Github Action deploys into 3 depots:

• Depot 1: Operating System : Windows, Architecture : 64-bit OS Only
• Depot 2: Operating System : Linux + SteamOS, Architecture : 64-bit OS Only
• Depot 3: Operating System : macOS, Architecture : 64-bit OS Only

If either of these depots missing the publish_to_steam job will fail.

Once you are done defining your depots, publish the changes that you have made from the Publish page. If you try to run Github Action before publishing the depots the action will fail to publish binaries.

Create a Steam Build Account

Create a specialised builder account that only has access to Edit App Metadata and Publish App Changes To Steam, and permissions to edit your specific app.

https://partner.steamgames.com/doc/sdk/uploading#Build_Account

Set STEAM_CONFIG_VDF action secret

Deploying to Steam requires using Multi-Factor Authentication (MFA) through Steam Guard unless totp is passed. This means that simply using username and password isn't enough to authenticate with Steam. However, it is possible to go through the MFA process only once by setting up GitHub Secrets for configVdf with these steps:

1. Install Valve's offical steamcmd on your local machine. All following steps will also be done on your local machine. Downloading_SteamCMD
2. Try to login with steamcmd +login <username> <password> +quit, which may prompt for the MFA code. If so, type in the MFA code that was emailed to your builder account's email address.
3. Validate that the MFA process is complete by running steamcmd +login <username> +quit again. It should not ask for the MFA code again.
4. The folder from which you run steamcmd will now contain an updated config/config.vdf file.
   1. Windows: Use certutil to convert config.vdf content to base64 encoded string certutil -encodehex -f config/config.vdf config_base64.txt 0x40000001 1>nul
   2. Linux/MacOS: Use cat config/config.vdf | base64 > config_base64.txt to encode the file.
5. Copy the contents of config_base64.txt to a GitHub Secret STEAM_CONFIG_VDF.
6. If: when running the action you recieve another MFA code via email, run steamcmd +set_steam_guard_code <code> on your local machine and repeat the config.vdf encoding and replace secret STEAM_CONFIG_VDF with its contents.

More documentation on steam publishing could be found at https://github.com/game-ci/steam-deploy

Optional: Windows Store Publishing (XBOX via UWP)

Detailed instruction can be found here.

Prerequisites

• You must have an Azure AD directory, and you must have global administrator permission for the directory. You can create a new Azure AD from Dev Center.

• You must associate your Azure AD directory with your Dev Center account to obtain the credentials to allow this extension to access your account and perform actions on your behalf.

• The app you want to publish must already exist: this extension can only publish updates to existing applications. You can create your app in Dev Center.

• You must have already created at least one submission for your app before you can use the Publish task provided by this extension. If you have not created a submission, the task will fail.

GitHub Action Secrets

Application ID (string, required) - The identification for the app. Depending on your selection, this should be either the app ID (visible in the URL of the app's page on Dev Center) or the app primary name (visible on the app's page on Dev Center). Set it to WINDOWS_STORE_APP_ID secret value.

In the partner's account settings associate your account to Microsoft Entra ID.

From manage users page, click the name of your Azure AD application to go to the application settings, and copy the Tenant ID to AZURE_AD_TENANT_ID secret and Client ID to AZURE_AD_APPLICATION_CLIENT_ID.

Click Add new key. On the following screen, copy the Key value to AZURE_AD_APPLICATION_SECRET secret.

Optional: Google Play Publishing

To publish app to Google Play directly from the GitHub Action you need to define several secrets in the pipeline.

PLAY_KEYSTORE, PLAY_KEYSTORE_ALIAS and PLAY_KEYSTORE_PASS

First you need to generate Java Key Store file by running the following command:

keytool -v -genkey -v -keystore googleplay.jks -alias someKindOfName -keyalg RSA -validity 10000

Don't user quotes " as part of the password, it may mess up the GitHub action scripts!

Replace alias with a name related to you. Store the alias into PLAY_KEYSTORE_ALIAS secret of the GitHub pipeline. The password you set to the keystore should go into PLAY_KEYSTORE_PASS secret.

Also you need to store the whole content of the googleplay.jks file into the PLAY_KEYSTORE secret. The easy way of doing that is to encode the file content into base64 string and store the string value into the secret by running the following command on windows:

certutil -encodehex -f googleplay.jks googleplay.txt 0x40000001 1>nul

or using openssl elsewhere:

openssl base64 < googleplay.jks | tr -d '\n' | tee googleplay.txt

Upload the content of googleplay.txt to PLAY_KEYSTORE variable.

Dont' forget to delete googleplay.txt and keep the googleplay.jks in a safe place locally!

More on this: https://thewissen.io/making-maui-cd-pipeline/

PLAYSTORE_SERVICE_ACC

Configure access via service account

This step use https://github.com/r0adkll/upload-google-play for the publishing. Here is what you need to do:

1. Enable the Google Play Android Developer API.
   1. Go to https://console.cloud.google.com/apis/library/androidpublisher.googleapis.com.
   2. Click on Enable.
2. Create a new service account in Google Cloud Platform (docs).
   1. Navigate to https://cloud.google.com/gcp.
   2. Open Console > IAM & Admin > Credentials > Manage service accounts > Create service account.
   3. Pick a name for the new account. Do not grant the account any permissions.
   4. To use it from the GitHub Action use either:
      • Account key in GitHub secrets (simpler):
        1. Open the newly created service account, click on keys tab and add a new key, JSON type.
        2. When successful, a JSON file will be automatically downloaded on your machine.
        3. Store the content of this file to your GitHub secrets, e.g. PLAYSTORE_SERVICE_ACC.
3. Add the service account to Google Play Console.
   1. Open https://play.google.com/console and pick your developer account.
   2. Open Users and permissions.
   3. Click invite new user and add the email of the service account created in the previous step.
   4. Grant permissions to the app that you want the service account to deploy in app permissions.
4. Create new application via Google Play Console
   1. Open https://play.google.com/console and pick your developer account.
   2. Press Create App and create new application using the same ApplicationId as in your c# project
   3. Make sure you upload an apk or aab manually first by creating a release through the play console.

Optional: iOS Publishing

Enroll in the Apple Developer Program

If you don't have one, go to Apple ID and sign up.​

Visit Apple Developer Program Enrollment and follow the instructions to enroll as an individual or organization. This process includes identity verification and requires an annual fee. ​

Create an App ID

Log in to your Apple Developer Account.

Navigate to "Certificates, Identifiers & Profiles / Register an App ID". Fill in the required details for the new App Bundle ID.

Navigate to "Apps" and click the "+" button. Select "New App". Fill in the required details, ensuring the Bundle ID matches your application's identifier.

Generate a Signing Certificate

In "Certificates, Identifiers & Profiles," go to "Certificates" and click the "+" button.

Choose "Apple Distribution" and follow the prompts to generate a Certificate Signing Request (CSR) using Keychain Access on your Mac.

Upload the CSR to obtain your distribution certificate, then download and install it.

IOS_CERTIFICATE_BASE64 and IOS_CERTIFICATE_PASS Secrets

Open "Keychain Access" on Apple device and export Apple Distribution certificate with password to a IOS_CERTIFICATE.p12 file.

Open terminal and apply BASE64 encoding to the p12 file

openssl base64 < IOS_CERTIFICATE.p12 | tr -d '\n' | tee IOS_CERTIFICATE_BASE64.txt

Set IOS_CERTIFICATE_BASE64.txt content to IOS_CERTIFICATE_BASE64 GitHub secret. Set .p12 file password to IOS_CERTIFICATE_PASS github secret.

Create a Provisioning Profile

Still in "Certificates, Identifiers & Profiles," select "Profiles" and click the "+" button.

Choose "Ad Hoc" under Distribution. Select the App ID, your distribution certificate, and the devices for internal testing.

Download and install the provisioning profile.

IOS_PROVISIONING_PROFILE_BASE64 Secret

Convert downloaded provisioning profile to base64 encoded text.

openssl base64 < ProvisioningProfileName.mobileprovision | tr -d '\n' | tee IOS_PROVISIONING_PROFILE_BASE64.txt

Replace ProvisioningProfileName.mobileprovision with your profile file name.

Set IOS_PROVISIONING_PROFILE_BASE64.txt content to IOS_PROVISIONING_PROFILE_BASE64 GitHub secret.

Deploying to App Store

Navigate to App Store Connect and sign in with your Apple Developer account credentials.

Once logged in, click on the Users and Access section.​

Within the Users and Access page, select the Integrations tab.​

Here, you'll find the Issuer ID displayed near the top of the page. Copy and store it into APPSTORE_ISSUER_ID GitHub secret.

Permission is required to access the App Store Connect API. You can request access on behalf of your organization by pressing "Request Access" if necessary.

In the Integrations tab, click the "+" button to create a new API key.​

Enter a name for the key to help you identify its purpose.​

Assign an access level to the key. For tasks such as uploading builds or managing app metadata, the App Manager role is typically sufficient. However, ensure the role aligns with the permissions required for your specific use case.​

Click Generate to create the key.

After generating the key, it will appear in the list of active keys.​

Click Download API Key to download the .p8 file. Important: This file can only be downloaded once, so store it securely. If lost, you'll need to revoke the key and create a new one.​ You can have a maximum of 50 active keys at a time.

Store the content of the downloaded .p8 file into APPSTORE_PRIVATE_KEY GitHub secret.

In the list of active keys, locate the newly created key. The Key ID is displayed alongside the key's name. Note this Key ID for future reference. Store it into APPSTORE_KEY_ID GitHub secret.

And the last bit of information the GitHub Action needs is your Apple account email. Store it into APPSTORE_USER_EMAIL GitHub secret.
