Welcome to the ART-TREES-demo-repository.git, a training resource for submitting a complete data package for an ART TREES verification audit. Here, we document some best practices for using version control to ensure perfect reproducibility of your calculations.

As you navigate this repository, keep the following Data Integrity concepts in mind, as these are fundamental to how auditors evaluate your submission. For a deeper dive into these principles, see Repository Guidelines section below.

• Data Traceability: Every key figure must be traceable back to its original source data and the methodology used to derive it.
• Data Completeness: All information required to justify your GHG assertion must be included, with nothing significant missing.
• Data Curation: A logical folder structure, descriptive file names, and clear documentation allow auditors to quickly find what they need.
• Data Reproducibility: Package management and version control implemented to ensure replication of computational environment and runtime indexing.

---

The Practical Exercise: Mock Audit {#the-practical-exercise-mock-audit}

Step 1. Clone the Repository

Before starting, please ensure Git and R are installed, and an internet connection is possible (see Appendix IV for installation guides).

Open your command-line tool (or GitHub Desktop) and clone this repository to your local computer. This step is crucial for working with precise, version-controlled data.

git clone https://github.com/seamusrobertmurphy/TREES-demo-repository.git

---

Step 2. Replicate the Script¹

The analysis script and its data are located in the /02_Carbon_Data/ directory. Simply open the ART-TREES-TMR-Replication-Demo.Rmd file in your R environment and run it. The script will automatically perform a simple carbon stock calculation and output the final result.

• Open the Script: Launch RStudio and open the 02_Carbon_Data/ART-TREES-TMR-Replication-Demo.Rmd file.
• Inspect the Code: Before running, review the code. You’ll see that it’s broken down into logical chunks:
  • Loading the required R package (library(dplyr)).
  • Defining the dataset directly within the script (hypothetical forest plot data).
  • Performing a simple calculation to sum the total carbon stock.
  • Outputting the final calculated value in tCO₂e.
• Run the Script: Execute the entire R Markdown file. You can do this by clicking the “Run All Chunks” button in RStudio or by using the knitr function. The script will process the data and display the final result in the console.

The script’s output will display a single, final calculated value in tCO₂e. Compare this result to the figure saved in markdown text. They should match exactly.

• If the results match: You have successfully demonstrated data reproducibility. The combination of the version-controlled data and script in this repository has produced the same result as the official submission. This is a critical success for any audit.
• If the results do not match: This is a key learning opportunity. It shows how even small discrepancies, a different software version, a missing package, or an altered data file, can lead to different results. This is a common and serious finding in a verification audit, and it underscores the need for rigorous version control and a robust QA/QC process.

---

Step 3. Document Runtime Log

To demonstrate data integrity and reproducibility, you must document the exact software environment used for your calculations. This runtime log can help auditors to independently and more quickly verify your results. This step involves generating a log of your R session’s dependencies and committing it to the repository.

• Open your R console and run devtools::session_info().

• Copy the full output and save it as a text file named runtime_log_YYYYMMDD.txt in the /06_QAQC/ folder

• Use Git to commit this file to create a permanent, verifiable link between the code, the data, and the computational environment.

The resulting log serves as a snapshot of your computing system and all the software dependencies at that precise moment in time.

---

Appendix I: Repository Guidelines {#appendix-i-repository-guidelines}

We provided a simplified layout in this github repository, as shown in the list of its trunk folders below. However, this architecture can become highly nested which may not suit everyone’s preferences. Therefore, we welcome any feedback on improved structure that is more appropriate to your project design, and provide additional layout examples from today’s slide for comparison.

---

• 01_Program_Data/

• 02_Carbon_Data/

  • TREES-demo-replication-A.Rmd

• 03_Spatial_Data/

• 04_Uncertainty/

  • TREES-demo-replication-B.Rmd

• 05_Safeguards/

• 06_QAQC/

• Archive

---

---

Repository Principles

These are the fundamental concepts that auditors use to evaluate your submission, which are embedded throughout this repository’s structure.

• Data Traceability: We demonstrate this through clear file naming conventions, a folder for QA/QC procedures, and a structure that links report claims to specific evidence files. Every key figure in a report, such as X hectares deforested, must be traceable back to its raw data source and the methodology used to derive it.
• Data Completeness: This repository is organized to align directly with the ART TREES requirements. This provides a clear framework for you to check if you have all the necessary data for every required category, such as deforestation areas, emission factors, and safeguards information. The repository also includes a place to document any methodological changes made over time.
• Data Curation: A well-organized data package allows auditors to quickly find what they need. Our layout, for example, separates Calculations & Analysis from Spatial Data and SOPs & Procedures. This logical grouping helps auditors instinctively navigate your submission. A top-level README and descriptive filenames are also key curation practices.
• Data Reproducibility: Independent verification requires identical computational outcomes. This standard demands that any auditor can execute the same analysis and achieve matching results using the provided code, data, and environment specifications. Package management tools like renv (Appendix III) combined with git version control (Appendix IV) deliver perfect reproducibility through:
  • Permanent Records: Immutable tracking of all modifications prevents manipulation while ensuring verification integrity.
  • Environment Capture: Precise control of scripts, dependencies, and runtime conditions enables exact replication of carbon stock calculations
  • Change Documentation: Systematic tracking supports robust QA/QC processes required for GHG verification audits.

---

Repository Governance

We offer a shortlist of default community health files that may be adapted to include SOPs and documentation of workbook updates, always aiming to build trust in the auditor:

• CODE_OF_CONDUCT.md: A CODE_OF_CONDUCT file defines standards for how to engage in a community.
• CONTRIBUTING.md: A CONTRIBUTING file communicates how people should contribute to your project. Discussion category forms can also be added to help customize priority templates issued to stakeholder or partners, or community members for opening new discussions in your repository..
• FUNDING.yml: A FUNDING file displays a sponsor button in your repository to increase the visibility of funding options for your open source project.
• GOVERNANCE.md: A GOVERNANCE file lets people know about how your project is governed. For example, it might discuss project roles and how decisions are made.
• Pull request & config.yml: Issue and pull request templates help standardize the information you’d like contributors to include when they open issues and pull requests in your repository.
• SECURITY.md: A SECURITY file gives instructions on how to report a security vulnerability in your project and description that hyperlinks the file. For more information, see Adding a security policy to your repository.
• SUPPORT.md: A SUPPORT file lets people know about ways to get help with your project. For more information, see Adding support resources to your project.

---

Appendix II: ISO Guidelines {#appendix-ii-iso-guidelines}

The data management principles of traceability, integrity, and reproducibility are key to GHG audits. These principles are supported by a range of ISO standards. This appendix provides an overview of those ISO standards relevant to data governance and quality, and provides additional resources for debugging and validating geospatial operations across platform using the liblwgeom library.

The liblwgeom library was derived according to the OpenGIS Simple Features Access (SFA) geometry rules (ISO 19125) and was purposely built for unbiased unit testing. This TopGeometry model drew on open-source or platform-neutral architecture to allow access to base geometric objects including Points, Curves, Surfaces, and Geometry Collections sfc.

• The liblwgeom library uses the CUnit test framework for unit testing, which provides lightweight method to debug spatial operations.
• The make check command runs a set of regression tests for the entire PostGIS system, which helps verify the integrity of the installation and its dependencies, such as PROJ4in cartographic projections and GEOS for topological tests.

---

• ISO 27001 & ISO 8000: Two widely discussed ISO standards for data governance are ISO 27001 and ISO 8000. ISO 27001 is a standard for Information Security Management Systems (ISMS), while ISO 8000 focuses on data quality management. Implementing the ISO 27001 standard is a deliverable of information security management under the IT governance program and not solely a data governance deliverable. However, data governance maturity is crucial for complying with ISO 27001 and ensuring data security, confidentiality, and integrity in information management practices. ISO 8000 aims to ensure that data used in various contexts, such as business processes, analytics, and decision-making, meets certain quality standards. It covers all the key elements of data—Syntax, Provenance, Completion, Accuracy, and Certification—providing a standard to measure and certify data quality.
• ISO 38505-1: This is a standard for data governance that provides a set of guidelines for the governance of data within an organization. It considers data governance as a subset of IT governance, which in turn is a subset of organizational governance, and defines clear responsibilities for the governing body and oversight mechanisms. At its core, it provides a model for evaluating, directing, and monitoring the handling and usage of data in an organization.
• ISO 22745: This standard focuses on master data exchange between organizations. It specifies data requirements for messages containing master data, including syntax, semantic encoding, and portability. It is often used in conjunction with ISO 8000 to realize the benefits of assessing and improving data quality.
• ISO 3166: This standard defines codes for country names, which can be utilized for consistent external reference data in business applications to reduce time and effort in data integration and analytic tasks.
• ISO 11179: This metadata registry (MDR) standard provides a framework for representing metadata for an organization to make data understandable and transferable. It provides guidance to software developers building metadata repositories.
• ISO 27701: This standard serves as a data privacy extension to ISO 27001, providing a framework for organizations to establish systems that facilitate compliance with data privacy regulations like GDPR.

---

Appendix III: Replication in renv {#appendix-iii-replication-in-renv}

renv profiles allow for managing different sets of package dependencies for various project contexts, such as separate environments for development, production, or demonstrations. To activate a specific renv profile, you have two primary options:

Step 1. Set a project profile

To make a profile the default for future R sessions, run renv::activate() function. Upon restarting R, you will find lockfile path assigned to new project renv folder ( renv/profiles/demo-repo/).

---

Step 2. Activate a temporary profile:

To activate a profile for the current R session without making it the default, you can set the RENV_PROFILE environment variable.

---

Step 3. Check package dependencies

Use the package dotfiles and environment fields found in Config/renv/profiles/<profile_name>/dependencies and Config/renv/profiles/<profile_name>/remotes to check list of required packages and assign locations of remote repositories for specific package builds. These environment fields can be also declared in the DESCRIPTION file specific to that renv profile.

---

Step 4. Manage package dependencies

• To capture all packages currently installed in the runtime, while overlooking packages listed in existing environment variables, then run renv::settings$snapshot.type("all").
• Alternatively, you can exclude certain packages from the installation using the renv::settings$ignored.packages("lwgeom") function. This proves useful with many debugging and version control issues among new users.
• There is also option to manually load and test an explicit customized snapshot that overlooks default environment fields previously written into the runtime.

# Activate 'demo-repo' profile and set as default for the project
renv::activate(profile = "demo-repo")

# To activate a 'dev' profile for a single session only
Sys.setenv(RENV_PROFILE = "dev")

# Defining dependencies in DESCRIPTION index
#Config/renv/profiles/shiny/dependencies: shiny, tidyverse
#Config/renv/profiles/shiny/remotes: rstudio/shiny, tidyverse/tidyverse

# Enable 'explicit' snapshot function for the project
renv::settings$snapshot.type("explicit")

# Exclude package from current environment
renv::settings$ignored.packages("lwgeom")

# deactivate the currently-activated project
renv::deactivate()

---

Appendix IV: Replication in git {#appendix-iv-replication-in-git}

Step 1: Install Git

Windows

# Option A: Direct download
# Download Git for Windows: https://git-for-windows.github.io/
# During install: select "Git from command line and 3rd-party software"

# Option B: Via Chocolatey package manager
choco install git.install

# Verify installation
git --version

Unix

# Option A: Trigger Xcode command line tools
git --version
# Accept installation prompt

# Option B: Via Homebrew
brew install git

# Option C: Direct download from git-scm.com/downloads

# Verify installation
git --version

Linux

Ubuntu/Debian
sudo apt-get install git

# Fedora/RedHat
sudo dnf install git

# Verify installation
git --version

Step 2: Setup Command Line Interface

Windows

# Git Bash (installed with Git for Windows) - Recommended
# Access via: Start Menu → Git Bash

# Alternative: Windows Subsystem for Linux (WSL)
wsl --install
# Restart computer, then install Ubuntu from Microsoft Store

# PowerShell (built-in)
# Access via: Start Menu → PowerShell

# Command Prompt (legacy, not recommended)
# Access via: Start Menu → cmd

Unix

# Terminal (built-in) - Recommended
# Access via: Applications → Utilities → Terminal
# Or: Cmd+Space → type "terminal"

# iTerm2 (enhanced alternative)
# Download from: iterm2.com
brew install --cask iterm2

# Set up better shell (optional)
# Install zsh with oh-my-zsh
sh -c "$(curl -fsSL https://raw.github.com/ohmyzsh/ohmyzsh/master/tools/install.sh)"

Linux

# Most distributions include terminal by default
# Common terminals: gnome-terminal, konsole, xterm

# Ubuntu/Debian: Install additional shells
sudo apt-get install zsh fish

# Set zsh as default shell
chsh -s $(which zsh)

# Install oh-my-zsh for enhanced experience
sh -c "$(curl -fsSL https://raw.github.com/ohmyzsh/ohmyzsh/master/tools/install.sh)"

Step 3: Setup GitHub Account

• Register at github.com
• Choose username & verify email
• Configure Git Identity.

# Set your identity (use your real name and GitHub email)
git config --global user.name "Your Full Name"
git config --global user.email "[email protected]"

# Set default branch name to 'main'
git config --global init.defaultBranch main

# Set preferred text editor
git config --global core.editor "nano"  # or vim, emacs

# Verify all settings
git config --global --list

Step 4: Setup Github Authentication

Option A: HTTPS with Personal Access Token (Beginner)

1. GitHub => Settings => Developer settings => Personal access tokens => Tokens (classic)
2. Click “Generate new token (classic)”
3. Set expiration: 90+ days
4. Select scopes: repo, workflow, gist, user:email
5. Copy token immediately

# Clone test repository
git clone https://github.com/seamusrobertmurphy/TREES-demo-repository
cd TREES-demo-repository

# When prompted for password, use your Personal Access Token (not GitHub password)
# Username: your-github-username
# Password: ghp_xxxxxxxxxxxxxxxxxxxx (your token)

# Optional: Store credentials to avoid repeated prompts
git config --global credential.helper store

Test Authentication:

# Clone test repository
git clone https://github.com/YOUR-USERNAME/test-repo.git
cd test-repo

# When prompted for password, use your Personal Access Token (not GitHub password)
# Username: your-github-username
# Password: ghp_xxxxxxxxxxxxxxxxxxxx (your token)

# Optional: Store credentials to avoid repeated prompts
git config --global credential.helper store

Option B: SSH Keys (Advanced Users)

Generate SSH Key:

# Create SSH key pair
ssh-keygen -t ed25519 -C "[email protected]"
# Press Enter for default location (~/.ssh/id_ed25519)
# Optional: set passphrase for extra security

# Start ssh-agent and add key
eval "$(ssh-agent -s)"
ssh-add ~/.ssh/id_ed25519

Copy Public Key to GitHub:

# Copy public key to clipboard
# macOS:
pbcopy < ~/.ssh/id_ed25519.pub

# Linux:
xclip -sel clip < ~/.ssh/id_ed25519.pub

# Windows Git Bash:
clip < ~/.ssh/id_ed25519.pub

# Manual copy:
cat ~/.ssh/id_ed25519.pub
# Copy the output manually

Add to GitHub:

1. GitHub => Settings => SSH and GPG keys => New SSH key

2. Paste public key, add descriptive title

3. Test connection: ssh -T [email protected]

Step 5: Install R and RStudio

# Download and install:
# 1. R from https://www.r-project.org/
# 2. RStudio from https://www.rstudio.com/products/rstudio/download/

# Verify RStudio can find Git:
# Open RStudio → Tools → Global Options → Git/SVN
# Check "Git executable" path is populated
# If not, browse to Git location:
#   Windows: C:/Program Files/Git/bin/git.exe
#   macOS: /usr/bin/git or /usr/local/bin/git
#   Linux: /usr/bin/git

Step 6: Complete Audit Training Exercise

We offer two types of exercises below that were considered potentially useful for trainee participants and their audit development.

Type 1: Clone Repository from GitHub

# Clone the demo repository
git clone https://github.com/seamusrobertmurphy/TREES-demo-repository.git
cd TREES-demo-repository

# Check repository status and history
git status
git log --oneline
git remote -v

# Make a test change
echo "Test line added from CLI" >> README.md

# The 4-step commit process:
# 1. Check what changed
git status

# 2. Stage changes
git add README.md
# Or stage all changes: git add .

# 3. Commit with message
git commit -m "Add test line from command line"

# 4. Push to GitHub
git push origin main

# Verify on GitHub web interface that changes appear

Type 2: Create Local Repository & Push to GitHub

# Create new project directory
mkdir my-new-project
cd my-new-project

# Initialize Git repository
git init

# Create initial files
echo "# My New Project" > README.md
echo "print('Hello World')" > script.py

# Stage and commit initial files
git add .
git commit -m "Initial commit with README and script"

# Create repository on GitHub (via web interface):
# 1. Go to github.com → New repository
# 2. Name it "my-new-project"
# 3. DON'T initialize with README (we already have one)
# 4. Copy the HTTPS URL

# Add remote connection to GitHub
git remote add origin https://github.com/YOUR-USERNAME/my-new-project.git

# Verify remote was added
git remote -v

# Push to GitHub
git push -u origin main
# The -u flag sets upstream tracking for future pushes

Git Cheatsheets

# Repository management
git init                           # Initialize new repository
git clone <url>                    # Download repository from GitHub
git remote -v                      # Show remote connections
git remote add origin <url>        # Connect local repo to GitHub

# Daily workflow commands
git status                         # Check current state
git add <filename>                 # Stage specific file
git add .                          # Stage all changes
git commit -m "description"        # Save changes with message
git push                          # Send to GitHub
git pull                          # Get updates from GitHub

# Viewing history and changes
git log                           # Full commit history
git log --oneline                 # Compact history
git diff                          # Show unstaged changes
git diff --staged                 # Show staged changes

# Branch operations
git branch                        # List branches
git branch feature-name           # Create new branch
git checkout branch-name          # Switch to branch
git checkout -b new-branch        # Create and switch to branch
git merge branch-name             # Merge branch into current

# Useful shortcuts
git commit -am "message"          # Stage and commit in one step
git push -u origin main           # Push and set upstream tracking
git pull --ff-only               # Pull without merge conflicts

• Cheatsheet by hectorsector accessed 2025-08 here
• Cheatsheet by Hostinger accessed 2025-08 here

Git Troubleshooting

# Git not found
which git                         # Check if Git is installed
echo $PATH                        # Verify PATH includes Git

# Authentication failures
git config --global --unset credential.helper  # Clear stored credentials
git push                          # Re-enter credentials

# Permission denied (SSH)
ssh -T [email protected]             # Test SSH connection
ssh-add -l                        # List SSH keys in agent

# Repository not found
git remote -v                     # Check remote URL
git remote set-url origin <correct-url>  # Fix remote URL

# Escape from vim editor (if accidentally opened)
:q                                # Quit without saving
:wq                               # Save and quit

# Merge conflicts
git status                        # See conflicted files
# Edit files to resolve conflicts, then:
git add <resolved-file>
git commit                        # Complete the merge

# Undo last commit (keep changes)
git reset HEAD^                   # Soft reset
git reset --hard HEAD^            # Hard reset (loses changes)

Git CLI vs Github Website

When to use GitHub website editing tools:

• Creating new repositories
• Managing repository settings
• Reviewing pull requests
• Browsing code and history
• Managing issues and projects

When to use command line editing tools:

• Daily commit/push/pull workflow
• Complex Git operations (rebasing, cherry-picking)
• Scripting and automation
• Working with multiple repositories
• Advanced branch management

---

Runtime Log

devtools::session_info()

─ Session info ──────────────────────────────────────────────────────────────────────────────────────────
 setting  value
 version  R version 4.4.3 (2025-02-28)
 os       Fedora Linux 40 (Workstation Edition)
 system   x86_64, linux-gnu
 ui       RStudio
 language (EN)
 collate  en_CA.UTF-8
 ctype    en_CA.UTF-8
 tz       America/Vancouver
 date     2025-08-10
 rstudio  2025.05.0+496 Mariposa Orchid (desktop)
 pandoc   3.1.3 @ /usr/bin/pandoc
 quarto   1.7.31 @ /usr/bin/quarto

─ Packages ──────────────────────────────────────────────────────────────────────────────────────────────
 package     * version date (UTC) lib source
 cachem        1.1.0   2024-05-16 [2] CRAN (R 4.4.0)
 cli           3.6.5   2025-04-23 [2] CRAN (R 4.4.3)
 CoprManager   0.5.7   2025-04-26 [4] local
 devtools      2.4.5   2022-10-11 [2] CRAN (R 4.4.0)
 digest        0.6.37  2024-08-19 [2] CRAN (R 4.4.1)
 ellipsis      0.3.2   2021-04-29 [2] CRAN (R 4.4.0)
 fastmap       1.2.0   2024-05-15 [2] CRAN (R 4.4.0)
 fs            1.6.6   2025-04-12 [2] CRAN (R 4.4.3)
 glue          1.8.0   2024-09-30 [2] CRAN (R 4.4.1)
 htmltools     0.5.8.1 2024-04-04 [2] CRAN (R 4.4.0)
 htmlwidgets   1.6.4   2023-12-06 [2] CRAN (R 4.4.0)
 httpuv        1.6.16  2025-04-16 [2] CRAN (R 4.4.3)
 later         1.4.2   2025-04-08 [2] CRAN (R 4.4.3)
 lifecycle     1.0.4   2023-11-07 [2] CRAN (R 4.4.0)
 magrittr      2.0.3   2022-03-30 [2] CRAN (R 4.4.0)
 memoise       2.0.1   2021-11-26 [2] CRAN (R 4.4.0)
 mime          0.13    2025-03-17 [2] CRAN (R 4.4.3)
 miniUI        0.1.2   2025-04-17 [2] CRAN (R 4.4.3)
 pkgbuild      1.4.7   2025-03-24 [2] CRAN (R 4.4.3)
 pkgload       1.4.0   2024-06-28 [2] CRAN (R 4.4.1)
 profvis       0.4.0   2024-09-20 [2] CRAN (R 4.4.1)
 promises      1.3.2   2024-11-28 [2] CRAN (R 4.4.2)
 purrr         1.0.4   2025-02-05 [2] CRAN (R 4.4.2)
 R6            2.6.1   2025-02-15 [2] CRAN (R 4.4.2)
 Rcpp          1.0.14  2025-01-12 [2] CRAN (R 4.4.2)
 remotes       2.5.0   2024-03-17 [2] CRAN (R 4.4.0)
 rlang         1.1.6   2025-04-11 [2] CRAN (R 4.4.3)
 rstudioapi    0.17.1  2024-10-22 [2] CRAN (R 4.4.1)
 sessioninfo   1.2.3   2025-02-05 [2] CRAN (R 4.4.2)
 shiny         1.10.0  2024-12-14 [2] CRAN (R 4.4.2)
 urlchecker    1.0.1   2021-11-30 [2] CRAN (R 4.4.0)
 usethis       3.1.0   2024-11-26 [2] CRAN (R 4.4.2)
 vctrs         0.6.5   2023-12-01 [2] CRAN (R 4.4.0)
 xtable        1.8-4   2019-04-21 [2] CRAN (R 4.4.0)

 [1] /home/seamus/R/x86_64-redhat-linux-gnu-library/4.4
 [2] /usr/local/lib/R/library
 [3] /usr/lib64/R/library
 [4] /usr/share/R/library

#Sys.getenv()

---

Versión en Español

Paso 1. Clonar el Repositorio

Antes de comenzar, asegúrese de que Git, R y RStudio estén instalados y que sea posible una conexión a internet (consulte el Apéndice IV para las guías de instalación).

Abra su herramienta de línea de comandos (o GitHub Desktop) y clone este repositorio en su computadora local. Este paso es crucial para trabajar con datos precisos y controlados por versiones.

git clone https://github.com/seamusrobertmurphy/TREES-demo-repository.git`

Paso 2. Replicar el Script

El script de análisis y sus datos se encuentran en el directorio /02_Carbon_Data/. Simplemente abra el archivo ART-TREES-TMR-Replication-Demo.Rmd en su entorno R y ejecútelo. El script realizará automáticamente un cálculo simple de reservas de carbono y generará el resultado final.

• Abrir el Script: Inicie RStudio y abra el archivo 02_Carbon_Data/ART-TREES-TMR-Replication-Demo.Rmd.
• Inspeccionar el Código: Antes de ejecutar, revise el código. Verá que está dividido en fragmentos lógicos:
  • Cargar el paquete R requerido (library(dplyr)).
  • Definir el conjunto de datos directamente dentro del script (datos hipotéticos de parcelas forestales).
  • Realizar un cálculo simple para sumar las reservas totales de carbono.
  • Generar el valor final calculado en tCO₂e.
• Ejecutar el Script: Ejecute todo el archivo R Markdown. Puede hacer esto haciendo clic en el botón "Run All Chunks" en RStudio o usando la función knitr. El script procesará los datos y mostrará el resultado final en la consola.

La salida del script mostrará un único valor final calculado en tCO₂e. Compare este resultado con la cifra reportada en la Tabla 16 del TMR. Deben coincidir exactamente.

• Si los resultados coinciden: Ha demostrado exitosamente la reproducibilidad de datos. La combinación de los datos controlados por versiones y el script en este repositorio ha producido el mismo resultado que la presentación oficial. Este es un éxito crítico para cualquier auditoría.
• Si los resultados no coinciden: Esta es una oportunidad clave de aprendizaje. Muestra cómo incluso pequeñas discrepancias, una versión diferente de software, un paquete faltante o un archivo de datos alterado, pueden llevar a resultados diferentes. Este es un hallazgo común y serio en una auditoría de verificación, y subraya la necesidad de un control de versiones riguroso y un proceso robusto de QA/QC.

Paso 3. Documentar el Registro de Tiempo de Ejecución

Para demostrar integridad de datos y reproducibilidad, debe documentar el entorno de software exacto utilizado para sus cálculos. Un auditor requerirá este registro de tiempo de ejecución para verificar independientemente sus resultados. Este paso involucra generar un registro de las dependencias de su sesión R y confirmarlo en el repositorio.

• Abra su consola R y ejecute devtools::session_info().

• Copie la salida completa y guárdela como un archivo de texto llamado runtime_log_YYYYMMDD.txt en la carpeta /06_QAQC/

• Use Git para confirmar este archivo y crear un enlace permanente y verificable entre el código, los datos y el entorno computacional.

El registro resultante sirve como una instantánea de su sistema de cómputo y todas las dependencias de software en ese momento preciso en el tiempo.

Apéndice III: Replicación en renv

Los perfiles de renv permiten administrar diferentes conjuntos de dependencias de paquetes para varios contextos de proyecto, como entornos separados para desarrollo, producción o demostraciones. Para activar un perfil específico de renv, tiene dos opciones principales:

Paso 1. Establecer un perfil de proyecto

Para hacer que un perfil sea el predeterminado para futuras sesiones R, ejecute la función renv::activate(). Al reiniciar R, encontrará la ruta del lockfile asignada a la nueva carpeta renv del proyecto (renv/profiles/demo-repo/).

Paso 2. Activar un perfil temporal:

Para activar un perfil para la sesión R actual sin hacerlo predeterminado, puede establecer la variable de entorno RENV_PROFILE.

Paso 3. Verificar dependencias de paquetes

Use los archivos de puntos de paquetes y campos de entorno encontrados en Config/renv/profiles/<profile_name>/dependencies y Config/renv/profiles/<profile_name>/remotes para verificar la lista de paquetes requeridos y asignar ubicaciones de repositorios remotos para construcciones específicas de paquetes. Estos campos de entorno también pueden declararse en el archivo DESCRIPTION específico para ese perfil renv.

Paso 4. Administrar dependencias de paquetes

• Para capturar todos los paquetes actualmente instalados en el tiempo de ejecución, mientras se pasan por alto los paquetes listados en variables de entorno existentes, entonces ejecute renv::settings$snapshot.type("all").
• Alternativamente, puede excluir ciertos paquetes de la instalación usando la función renv::settings$ignored.packages("lwgeom"). Esto resulta útil con muchos problemas de depuración y control de versiones entre nuevos usuarios.
• También existe la opción de cargar y probar manualmente una instantánea personalizada explicit que pasa por alto los campos de entorno predeterminados previamente escritos en el tiempo de ejecución.

# Activar perfil 'demo-repo' y establecer como predeterminado para el proyecto
renv::activate(profile = "demo-repo")

# Para activar un perfil 'dev' solo para una sesión
Sys.setenv(RENV_PROFILE = "dev")

# Definir dependencias en el índice DESCRIPTION
#Config/renv/profiles/shiny/dependencies: shiny, tidyverse
#Config/renv/profiles/shiny/remotes: rstudio/shiny, tidyverse/tidyverse

# Habilitar función de instantánea 'explicit' para el proyecto
renv::settings$snapshot.type("explicit")

# Excluir paquete del entorno actual
renv::settings$ignored.packages("lwgeom")

# desactivar el proyecto actualmente activado
renv::deactivate()

Registro de Tiempo de Ejecución

devtools::session_info()

Footnotes

1. Please note that this public repository is for demonstration purposes. To review Winrock’s active audit repository used to replicate previous submissions of your program’s GHG assertions and emissions calculations, you may request access through the following link: https://github.com/seamusrobertmurphy/TREES-ecuador-repository.git ↩
