Check out the interactive demo hosted on Hugging Face Spaces: https://huggingface.co/spaces/thearn/Game-of-life

Fast Python implementation of Conway's game of life and other cellular automata

Running

First, install the required dependencies:

pip install -r requirements.txt

To run the main interactive application using Gradio:

python app.py

This will launch a web interface (usually at http://127.0.0.1:7860).

Gradio App Controls:

• Predefined Rulesets: Select from a list of common cellular automata rules (e.g., "Conway's Game of Life", "HighLife"). Selecting a ruleset automatically updates the "Ruleset String" textbox.
• Ruleset String: Enter a custom ruleset in the standard "B/S" notation (e.g., "B3/S23"). This defines the number of neighbors required for a dead cell to become alive (Birth) and for a live cell to survive (Survival).
• Board Size (N x N): Set the dimensions of the square simulation grid. Press Enter after changing the value. Note: Changing the size while a simulation is paused will cause the board to reset upon restarting.
• Boundary Condition: Choose how the edges of the grid are handled:
  • Periodic (wrap): The grid wraps around (top connects to bottom, left connects to right).
  • Zero-Padding (fill): The grid is surrounded by dead cells.
• Start: Begins the simulation with the current settings and board state. If the simulation was paused, it resumes from the last frame using the potentially updated ruleset and boundary conditions.
• Pause: Stops the simulation, preserving the current board state.
• Restart: Stops any running simulation and generates a completely new random board based on the current size setting.

You can pause a running simulation, change the ruleset or boundary conditions, and then click "Start" again to continue the simulation from the paused state but applying the new rules.

To see a basic example of running a simulation directly with Matplotlib for visualization:

python example.py

You can modify example.py to experiment with different rules and initial states outside the Gradio app.

End command-line programs like example.py using a keyboard interrupt (Ctrl+C). The Gradio app can be stopped by closing the terminal where it's running.

How it's written

The game grid is encoded as a simple m by n array (default 100x100 in the code) of zeros and ones. In each program, a state transition is determined for each pixel by looking at the 8 pixel values all around it, and counting how many of them are "alive", then applying some rules based that number. Since the "alive" or "dead" states are just encoded as 1 or 0, this is equivalent to summing up the values of all 8 neighbors.

If you want to do this for all pixels in a single shot, this is equivalent to computing the 2D convolution between the game state array and a kernel matrix (e.g., [[1,1,1],[1,0,1],[1,1,1]] for counting neighbors). Convolution applies this kernel as a "stencil" across the grid to sum neighbor values. This implementation uses scipy.signal.convolve2d for this calculation.

An important aspect of convolution is how edges are handled. This application supports two common boundary conditions, which can be selected in the Gradio interface (app.py):

• Periodic ('wrap'): The grid wraps around itself, connecting the top edge to the bottom and the left edge to the right (like in Pac-Man).
• Zero-Padding ('fill'): The grid is assumed to be surrounded by zeros (dead cells) beyond its boundaries.

Goals

Ultimately, I'd like to study automata patterns with rule sets that depend on information beyond only the immediate 8 neighbors to a cell. For this code, this basically comes down to finding interesting behavior that results from using different convolution kernels.
